Summary of Contents for Haier PBFS21 Series

Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Haier PBFS21EDBP Owner's Manual Shop genuine replacement parts for Haier PBFS21EDBP Find Your Haier Refrigerator Parts - Select From 1148 Models -------- Manual continues below --------...
Page 2: Table Of Contents
Household Refrigerator Model: PBFS21**** Table of Contents Safety Precautions------------------------------------------------------------------------------------------------------------- 1-2 Location------------------------------------------------------------------------------------------------------------------- 3 Featured functions----------------------------------------------------------------------------------------------------- 3 Parts & Components--------------------------------------------------------------------------------------------------- 4 Door Removal and Replacement----------------------------------------------------------------------------------- 5-6 Connecting Water Supply-------------------------------------------------------------------------------------------- 7-8 Preparation before Usage-------------------------------------------------------------------------------------------- 9 Start Using------------------------------------------------------------------------------------------ 9 Functions---------------------------------------------------------------------------------------------------------------- 10-14 About Refrigerator compartment----------------------------------------------------------------------------------------- 15-16 Precautions when Refrigerating Food----------------------------------------------------------------------------- 16 Tips &...
Page 3: Safety Precautions
Safety Precautions Before operating the appliance, please read through this manual carefully and retain it for future reference. Because we offer a variety of models, the characteristics of your refrigerator may differ slightly from those described in this manual. The appliance is not intended for use by children or infirm persons without adult supervision. WARNING Children should be supervised to ensure that they do not play with the appliance.
Page 4 Safety Precautions Do not put dangerous materials such as Do not put drugs, vaccines and other Do not risk storing or using flammable flammable, explosive matters, high chemical agents in your refrigerator which materials such as gasoline near the corrosive acid and alkali in your is designed for household usage only and refrigerator which may lead to fire hazard.
Page 5: Location
Location Keep your refrigerator away from heat Keep your refrigerator away from humid Sit the refrigerator at a well ventilated source or direct sunlight which may reduce places and where it’s easily get spilled. place, where portable water source is the cooling performance of the refrigerator.
Page 6: Parts & Components
Parts & Components There’re a variety of different optional accessories for this refrigerator, hence the figures shown in this manual may not be identical with your refrigerator. NOTE - 4 -...
Page 7: Door Removal And Replacement
Door Removal and Replacement To avoid injury and property loss, damage to the refrigerator, before removal and replacement of door(s), make sure to remove all food from shelves, then, remove bottle bin(s), unplug the refrigerator, shut off water supply. NOTE Have 2 or more friends for help if possible.
Page 8 Door Removal and Replacement Replace the door in a reversal sequence to the Remove the middle hinge if necessary. above steps. Take care to prevent the door from falling onto you when lifting the hinges to remove the door. NOTE Ice storage drawer removal and replacement: Hold the release buckles on the slide rail in a Pull the ice storage open to the most, and...
Page 9: Connecting Water Supply
Connecting Water Supply Connect the refrigerator to nearest shutoff valve on a water line in use. Turn off the main water supply. Turn ON nearest faucet long enough to clear line of water. Locate a proper installation position for the shutoff valve: Find a convenient position on a vertical pipe.
Page 10 Connecting Water Supply Route the tubing: Route the tubing between the cold water line and the refrigerator. Route the tubing through a hole drilled in the wall or floor (behind the refrigerator or adjacent to its base cabinet) as close to the wall as possible.
Page 11: Preparation Before Usage
Preparation before Usage Remove the packing Check accessories and documents: Remove the foam support and all adhesive tapes Check accessories and documents according to the used to retain accessories. packing list. Call the dealer if anything’s left out. Install bottom trim kit: Install your refrigerator in proper Take the bottom trim kit out from the refrigerator location:...
Page 12: Functions
Functions Door controls with display A…….Hour key; B…….Minute key; C…….Lock key; D…….Clock display. Cabinet controls with display (Only applicable to PBFS21**** series) (Only applicable to PBFS21**** series) E…….Fast deep freezing of freezer compartment; F, G……Temperature adjustment key of freezer compartment; H…….Temperature indicator of freezer compartment;...
Page 13 Functions Lock and unlock: Press C key, the LOCK key will light up, the refrigerator will turn to lock mode. Press C key again to release lock mode, and the LOCK key will go off. Temperature adjustment of refrigerator compartment (Only applicable to PBFS21**** series) (Only applicable to PBFS21**** series) Press key J or K once, temperature indicator ‘I’...
Page 14 Functions Temperature adjustment of freezer compartment (Only applicable to PBFS21**** series) (Only applicable to PBFS21**** series) Press key G or F once, temperature indicator ‘H’ of freezer compartment will blink, the refrigerator will turn to freezer compartment temperature adjustment mode. Temperature range of the refrigerator compartment is -5ºF- -9ºF. Upon each G key operation, temperature setting will increase one level, from 1 till 7;...
Page 15 Functions Fast deep freezing of freezer compartment This function is designed to help you with an optimized food storing, capable of freezing food completely deep to the core within a short period of time. Press key E once, the indicator will start to blink, the freezer will turn to fast deep freezing mode. The freezer will automatically restore normal operation mode after 4 hours’...
Page 16 Functions Controls display: After 30 seconds’ idle, the display will goes off automatically. By pressing any key, or opening any door or operating cold water dispenser, it will light up again. Errors: When there’s malfunction, by pressing any key, there will be no response except the warning tone can be heard.
Page 17: About Refrigerator Compartment
About Refrigerator compartment Temporary storage or frequent foods should be kept in the refrigerator compartment. Although in most areas inside the refrigerator compartment, an average temperature of 36ºF- 48ºF can be obtained through adjusting the temperature settings, this compartment is not intended for long-term fresh keeping.
Page 18: Precautions When Refrigerating Food
About Refrigerator compartment Recommended storage area for various food Out of the nature of the cooling air circulation, temperature in different area of the refrigerator will vary slightly. Hence, it is recommended to store different food in different area: Eggs, butter, cheese; Tined drinks, food, spices;...
Page 19: Tips & Hints For Using Refrigerator Compartment
Tips & Hints for Using Refrigerator compartment Remove leaves of carrots Thaw frozen food in the For food which can obtain Fruits such as rice melon, and radishes before adding refrigerator compartment, freshness under ambient Chinese quince, sweet them to the refrigerator, this will help cooling food in temperature storage, such melon, banana and pine...
Page 20: Precaution When Freezing Food
Contact your local Haier after service center or the dealer from whom you purchased your refrigerator for information on water filter replacement. After the replacement is made, press the water alert reset key. During new installation, service personnel will be responsible for the installation of the water filter.
Page 21: Operation Of Ice Maker
Operation of Ice Maker Operation of ice maker: The ice maker can produce 7 cubes at a time. Total daily quantity depends on ambient temperature, number of door openings, pressure of water supply and temperature within the freezer compartment. Please arrange ice cubes in order, thus to make sure the storage bin can store more ice cubes. The ice maker can produce 7 cubes at a time, it’s normal if several cubes stick to each other.
Page 22: Precaution When Using Cold Water Dispenser
Precaution when Using Cold Water Dispenser Do not use glasses or paper cup that are too After disposal of water in the shelf, please wipe the deep, too thin, too soft or whose walls are too spilled water on the lower end of dispenser. thin.
Page 23: Water Filter
Water Filter Water filter indicator lights up This is a signal showing that you might need to replace your old water filter. It is recommended that after 6 month’s operation, or when the ice production declines greatly, new water filter shall be installed. Please observe actual usage conditions, and the local portable water quality, you may need new water filters more often then above mentioned.
Page 24 NOTE information concerning Haier appliances. 1. Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Systems certified for cyst reduction may be used on disinfected waters that may contain filterable cysts.
Page 25: Stopping
Stopping Handling power failure Food can be stored well after several hours of power failure even if it is in summer. You should inquire how long it will last by calling your electric company. After power fail, do not add food to the refrigerator, open door as little as possible.
Page 26: Troubleshooting
Troubleshooting Before calling for service, please read through the information listed below, this may save you time and energy. Most common problems are listed hereunder, not including defects of workmanship and materials used in the production of this refrigerator. Problem observed Possible cause Solution Running of refrigerator...
Page 27 It is normal for ice crystals to form due to the moisture content of meat.) Digital temperature Electronic control system Call your Haier service personnel for information display blinks has detected an operation concerning the error code displayed. problem. Temperature too high Temperature too high in Too much door openings.
Page 28 Troubleshooting Problem observed Possible cause Solution Automatic ice maker Ice maker does not work. Ice level sensing lever is in Put down the lever, or reset it to ‘ON’ position. upper or ‘OFF’ position. Water line shut off, or Turn on the water supply, or refer to ‘Temperature freezer not cold enough.
Page 29 Troubleshooting Problem observed Possible cause Solution Water dispenser problems Low water pressure Cut-off and cut-on pressure Have someone turn up the cut-off/cut-on pressure too low (for well system on the water pump system. only) reverse osmosis system in It normal to have pressure under 30psi when regenerative phase reverse osmosis system is in regenerative phase.
Page 30: Limited Warranty
Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you. This warranty gives you specific legal rights, and you may have other rights, which vary, from state to state. Haier America New York, NY 10018 - 28 -...
