  • Page 1 INFINITE 12’X24’ INSTRUCTION MA N UA L...
  • Page 2 THANK YOU FOR PURCHASING OUR MIRADOR INFINITE PERGOLA! This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your pergola, to ensure it brings you many years of use and enjoyment.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS - Before Assembling Your Pergola - Important Safety Advice - List of Parts - Assembly - Operating Your Pergola - Problem Solving, Care & Maintenance - Warranty & Complaints Procedure - Disassembly & Disposal of the Product - Certification Information...

  • Page 4: Before Assembling Your Pergola

    BEFORE ASSEMBLING YOUR PERGOLA WARNING: Improtant safety instructions. Follow all instructions, since incorrect assembly can lead to severe injury. Make sure you have all the tools required for assembling your pergola: In order to assemble your pergola safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided.
  • Page 5 Check to ensure there are no missing parts: Before you begin assembly, please check that you have all the parts required to assemble your pergola. Please also carefully check that the quantity of parts match with that of the model you have purchased. If any parts are missing, please refer Warranty &...

  • Page 6: Important Safety Advice

    IMPORTANT SAFETY ADVICE For the safety of all persons installing and using the pergola, it is important to follow the safety guidelines below. If using power tools or The pergola must be Always wear appropriate Work well away from power Make sure the pergola a ladder, always follow positioned and fixed on flat...
  • Page 7 Installation of non-Mirador Put the louvers into the After prolonged use we branded accessories will void Do not attempt to assemble vertical position during recommend you check all Please recycle packaging the product warranty and the product if you are tired, or...

  • Page 8: List Of Parts

    LIST OF PARTS Please carefully check that the quantity of parts matches with that of the model you have purchased. PLEASE NOTE that the anchor bolts provided may not be suitable for your chosen installation location. Please check before proceeding. DO NOT USE AN IMPACT CORDLESS SCREW DRIVER TO ASSEMBLE THE PERGOLA.
  • Page 9 Part Name BOX Ref. Louvers Louver 46 pcs I & II Frame Connecting strip 2 pcs I & II Frame Crank 2 pcs I & II Frame Foot plate cover 6 pcs I & II Frame Foot plate 6 pcs I &...
  • Page 10 Part Name BOX Ref. Frame Screw ST5.65x45mm 36+3 pcs I & II Frame Screw M5x12mm 184+10 pcs I & II Frame Screw 4.2x25mm 184+10 pcs I & II Frame Screw 5.5x19mm 16+3 pcs I & II Frame Cotter pin 46+6 pcs I &...

  • Page 11: Assembly

    ASSEMBLY 1. Set up the pillars Assembly Video Slide the foot plate cover with its wide opening facing outwards on the straight end of the pillar ( & A&A1 A&A1 Push the foot plate against the straight end of the pillar ( &...
  • Page 12 2. Connect the side beams to the corner pillars Remove the spacer sleeve, socket screw, and washer. Discard the washer and retain the remaining parts. Slot connecting pipe into side beam with gearbox , connect them by inserting spacer sleeves and screwing in socket screws, but do not fully tighten.
  • Page 13 Slide the end of side beam into the other one until the end piece is no longer visible. Connect the 2 side beams by inserting spacer sleeves and screwing in socket screws, but do not fully tighten. Then loosen the top 4 built-in screws counter clockwise where the side beams meet in the middle.
  • Page 14 Slightly loosen the 8 built-in screws counter clockwise at the corner ends of the side beams (4 on each side). Align the newly connected side beams with the corresponding pillars &...
  • Page 15 Slide the side beams into the grooves of the pillars ( & ) in such a way that the slot nuts of the side beams interlock with the slots in the pillars.
  • Page 16 Tighten all 16 screws clockwise. Repeat steps to connect the beams without gearbox with the remaining pillars ( &...
  • Page 17 3. Assemble end beams This phase requires six persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. 6 PEOPLE REQUIRED Only use ladders suitable for this kind of assembly work. Gearbox Stand the two structures built during steps 2 and 3 in an upright position, and place them at one end beam length away from one another.
  • Page 18 Slide the slot nuts of the end beams from above into the slots of the corner pillars Once the beam is in the correct position, tighten the 8 built-in screws clockwise on both ends. Install the other end beam repeating steps...
  • Page 19 4. Check the alignment of the frame and the distance between the corner pillars You are now almost done installing the main frame of the pergola. Please double check to ensure all beams and pillars have been installed and fitted correctly. You may have to unscrew certain bolts during this step.
  • Page 20 Measure the diagonal distance between the opposite corner pillars. Adjust the other corner pillars accordingly until both diagonal distances are equal. You may have to repeat the above steps after completing the remaining steps. = 480cm / 189 inches = 770cm / 303.1 inches Check that all corner pillars are straight and level using a leveler.
  • Page 21 5. Assemble cranks Gearbox Locate the gearboxes on the side beams Unscrew and remove the small screw from the crank connectors. Insert the crank couplers into the crank connectors and re-insert and tighten the small screw.
  • Page 22 Insert the end of the cranks into the crank couplers , and turn until the crank locks firmly in place.
  • Page 23 6. Assemble louvers Prepare 2 driving louvers: select 2 louvers to be the driving louver. Attach the louver end cap with control to one end of the driving louver, and attach an louver end cap to the other end of the driving louver. Use 2 screws on each side, and fix them firmly using a cordless screwdriver.
  • Page 24 Loosen the screw and washer already attached to the beam. Then fix the connecting rod of the driving louver to the side beam with gearbox , by firmly tightening the same screw and washer, using the hexagon socket key Place the louvers on the corresponding louver shaft support on both side beams (...
  • Page 25 Install the supporting louvers between side beams ( & Place 4 supporting louvers to the beams onto the shaft support brackets with cover plate on both sides. Shaft support bracket with cover plate Shaft support bracket...
  • Page 26 Place the rest of the louvers onto the remaining shaft support brackets. Secure the louvers in the shaft support brackets by fixing a shaft support cover onto the shaft support brackets on both ends of each louver . Use 2 screws each and secure them with a cordless screwdriver.
  • Page 27 Attach the connecting strip to each louver by fitting each of the holes onto the corresponding bolts of the louvers. Secure every bolt with a cotter pin inserting it through the small bolt hole. Repeat this step for all cotter pins. x 46...
  • Page 28 7. Secure pillar covers Fix the pillar cover to the top of N/N' each corner pillar with 3 screws N/N' each by using a cordless screwdriver. x 12 N’ Fix the middle pillar cover to the top of each middle pillar with 2 screws each by using a cordless screwdriver.
  • Page 29 8. Secure the pillars to the ground The pergola must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your pergola”. To ensure the correct installation of the subsequent fittings, check the frame alignment and pillar distance by repeating steps To fix the pillars( &...
  • Page 30 9. End of assembly...

  • Page 31: Operating Your Pergola

    OPERATING YOUR PERGOLA When opening/closing the louvers, please ensure the crank remains in a vertical position next to the pillar. Do not move the crank too far away from the pillar. To open the louvers, turn the crank handle clockwise; To close the louvers, turn the crank handle counter clockwise.

  • Page 32: Problem Solving, Care & Maintenance

    PROBLEM SOLVING, CARE & MAINTENANCE Issue Explanation or action to take Check if any of the louvers are deformed. If this is the case, replace them. If the Abnormal noise occurs during the rotation of the louvers. louvers are not deformed but they are colliding with one another, replace the beam.

  • Page 33: Periodic Inspection

    GENERAL CARE & MAINTENANCE Dust and dirt will collect on the Use a water/detergent mixture For more soiled areas, rinse the Air dry or wipe with a soft clean pergola and will require periodic and a soft clean cloth to clean surface with clean water from top cloth.

  • Page 34: Warranty & Complaints Procedure

    COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.com or contact your local Mirador sales representative. Complaints procedure: • The complaint must include an order number or transaction number. Goods without an order number or transaction number are not covered under the warranty.

  • Page 35: Disassembly & Disposal Of The Product

    DISASSEMBLY & DISPOSAL OF THE PRODUCT Incorrect disassembly of the pergola may lead to serious injury and product damage. Disassembly should be assigned to qualified personnel with adequate training within the scope of occupational health and safety and knowledge within the scope of recycling.

  • Page 36: Certification Information

    Declaration of performance (DOP) Reference no. DOP0001 Product name and type Mirador Pergola and Mirador Wall Pergola/ pergola awning Model name/ Unique identification code of the product: 111 Deluxe AxBm, 111 Deluxe e AxBm, 111 Deluxe e-Motion RC AxBm, 111 Deluxe e-Motion AxBm,...
