- Page 1 Kit Instructions Under Counter Mounting Bracket Publication ID: 7199-K100 Publication Issue: C © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 2: Copyright And Trademark Information
Copyright and Trademark Information The product described in this document is a licensed product of NCR Voyix Corporation. NCR Voyix is a registered trademark of NCR Voyix Corporation. Product names mentioned in this publication may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. -
Page 3: Revision Record
Revision Record Issue Date Remarks Nov 2017 First issue May 2023 Converted to Guild template Jul 2024 Converted to Voyix template Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 4: Tools Needed
This kit serves as a mounting bracket for installing the printer under the counter. Tools needed Cordless hand drill Phillips screw driver Screws (4) Note Screws are not included in the kit. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 5: Installation Procedures
To avoid damage to the printer due to liquid spills, the printer edge should not go beyond the counter edge. 1. Prepare the installation site. Use the following dimensions. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 6 3. Connect the cables to their respective ports on the printer. For more information, refer "Connecting the Cables" on page 10. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 7 4. Mount the printer to the mounting bracket. a. Hold the printer on both sides, positioning it to the center of the mounting bracket. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 8 If the printer is not properly installed, remove the printer by pulling the anti-dislodgement plunger at the back of the mounting bracket and then sliding the printer up. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 9 6. Connect the other end of the cables to their respective device or terminal. For more information, refer to "Connecting the Cables" on the next page. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 10: Connecting The Cables
1. Connect the communication cable and the cash drawer cable to their respective connectors on the bottom of the printer. 2. Connect the power cable to its connector on the bottom of the printer. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 11 The image shown above has a Serial Interface Module Cable Connection. For other cable routings, refer to NCR RealPOS 7199 Thermal Receipt Station Printer User Guide (BCC5-0000-5172). Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 12 At this point, the printer receives power. If the On Line LED (green) is on, the printer is online. Otherwise, the printer is not receiving power. Ensure that the host terminal is on or that the power supply is on. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 13: Routing The Cables
This type of cable routing is for USB cable connection, regardless of the type of power cable used. Note Route the cash drawer cable first before the USB cable. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 14 This type of cable routing is for RS-232/Ethernet cable connection that uses a power cable without a ferrite bead. Note Route the cash drawer cable first before the RS-232/Ethernet cable. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 15 This type of cable routing is for RS-232/Ethernet cable connection that uses a power cable with a ferrite bead. Note Route the power cable first before the cash drawer cable. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
