INSTRUCTION MANUAL :
EM-LVC50-A1P
INSTRUCTION MANUAL
WARE WASHING
EM-LVC50-A1P
To ensure proper use of this appliance and your safety, please read the following
instructions completely before operating this appliance.
English – Original
L2G SAS 17, AVENUE DU 24 AOÛT 1944
BP90690-69969 CORBAS CEDEX
TÉL. : +33(0)4 72 23 23 98 FAX : +33(0)4 72 23 23 99
Advertisement
Table of Contents
Related Manuals for BM L2G saro EM-LVC50-A1P
Summary of Contents for BM L2G saro EM-LVC50-A1P
- Page 1 INSTRUCTION MANUAL : EM-LVC50-A1P INSTRUCTION MANUAL WARE WASHING EM-LVC50-A1P To ensure proper use of this appliance and your safety, please read the following instructions completely before operating this appliance. English – Original L2G SAS 17, AVENUE DU 24 AOÛT 1944 BP90690-69969 CORBAS CEDEX TÉL.
- Page 2 INSTRUCTION MANUAL : EM-LVC50-A1P Index 1. Installation instructions 1.1 Introduction 1.2 Advantages 1.2.1 Legal provisions / Requirements 1.3 Installation 1.3.1 Installation suggestions 1.4 Connection to the water supply 1.4.1 Drainage connection 1.5 Electrical Network connection 1.5.1 Protective duct connection and voltage compensation 2.
-
Page 3: Installation Instructions
INSTRUCTION MANUAL : EM-LVC50-A1P 1. INSTALLATION INSTRUCTIONS 1.1 INTRODUCTION This appliance complies with the needs of modern and professional cooking. Please read these instructions carefully before operating this appliance. In this manual you will find all significant safety indications, as well as other essential information needed for the regular start-up - and operation itself - of the appliance. -
Page 4: Installation Suggestions
INSTRUCTION MANUAL : EM-LVC50-A1P 1.3 Installation This dishwasher is delivered with water inlet and outlet hoses. According to its construction, the connection of the machine to water and power supply must be performed by an authorized and locally recognized installer by keeping the existing specifications. Before connecting the appliance, check that the connection data on the data plate (voltage and connected load) match the mains electricity supply. - Page 5 INSTRUCTION MANUAL : EM-LVC50-A1P 2. OPERATING INSTRUCTIONS 2.1 Technical data You can find the technical data of each appliance at the adhesive label of the dishwasher. 2.2 Instructions for the dishwasher’s regular operation The appliance is exclusively used to clean dishes, cups, glasses, silverware, etc. following their use during lunches/dinners. You should pay special attention that the items to be washed are suitably placed for dishwashing.
- Page 6 INSTRUCTION MANUAL : EM-LVC50-A1P Do not use caustic products. If you do not follow this indication, you will not be covered by the guarantee. 2.7 Starting the washing program - Filling the boiler • Check that the suction filter, in the tank, has been placed in the correct position. •...
-
Page 7: Daily Works
INSTRUCTION MANUAL : EM-LVC50-A1P except the one anticipated, in case of fault or improper use. The water inside the dishwasher is not potable. Use, maintenance and repair of dishwasher should be performed only by persons familiar with these works and informed for any possible risks. 2.8.2 Daily works •... -
Page 8: Customer Service
INSTRUCTION MANUAL : EM-LVC50-A1P You should take care to move towards the smoothing direction, so that you will not scratch the surface. Finally, rinse with clean water and dry thoroughly. We remind you that corrosion (rust formation) on stainless steel surfaces is not created by itself, but rather due to the use of improper cleaning aid (e.g. -
Page 9: Troubleshooting
INSTRUCTION MANUAL : EM-LVC50-A1P 2.12 Troubleshooting PROBLEM CAUSE SOLUTION The dishwasher does not operate properly Connection interruption Check the connection You have not turned the switch of the appliance ON Turn the switch ON Main switch / or fuse has not been activated / or it Check the main switch / or fuse is faulty The switch of the appliance is faulty... - Page 10 INSTRUCTION MANUAL : EM-LVC50-A1P RATINGS AND EXPECTATIONS INLET WATER MUST NOT EXCEED 55oC BASKET 50X50 cm FOOT TO BODY M10 CONNECTION BOLT 69,50 BASKET 50X50 cm 30,50 30,50 Customer: BUBBLE INFORMATION Order Date: DESCRIPTION NOTE Or Number: Draining pipe (2.0 m Length) Φ45 O.D. Used only for flow, Drainage without pump Series Description: MACHINE PROPERTIES...
- Page 11 INSTRUCTION MANUAL : EM-LVC50-A1P ELECTRICAL DIAGRAM TS 2 TS 3 K4.1 K4.2 TS 1 K4.3 TF 3 TF 1 TF 2 MS : Main switch ORC : Overload's relay breaking contact ELECTRICAL DIAGRAM DS : Door switch OR : Overload relay M1 : Wash pump motor R1 : Booster's heating element EM-LVC-A1P...
-
Page 12: Exploded View And Spare Parts List
INSTRUCTION MANUAL : EM-LVC50-A1P EXPLODED VIEW AND SPARE PARTS LIST ITEM Default/ ITEM PART NUMBER DESCRIPTION PART NUMBER DESCRIPTION QTY. QTY. 002.15.00044 PLASTIC GUIDE D.30 003.00.00346 TAPPING SCREW 4,8X13 001.00.00250 LEVELING FEET 1 3/4 SCALE 1 : 5 SCALE 1 : 5 SCALE 1 : 20 ITEM CODE: ITEM DESCRIPTION: STEEL STRUCTURE... - Page 13 INSTRUCTION MANUAL : EM-LVC50-A1P ITEM NO. PART NUMBER DESCRIPTION QTY. ITEM NO. PART NUMBER DESCRIPTION QTY. 002.00.00223 RUBBER GASKET Φ109 Χ 54 Χ 3 MAGNETIC CONTACTOR 003.00.00056 002.15.00084-1 WASH & RINSE BASE TURBO 1500 003.00.00213 THERMOSTAT 0-90oC 1500mm 002.15.00080 WASH SUPPLY INOX TURBO 1500 003.15.00010 THERMAL OVERLOAD RELAY 2,5 - 4,0 002.15.00086...
-
Page 14: Standards And Directives
INSTRUCTION MANUAL : EM-LVC50-A1P STANDARDS AND DIRECTIVES Meaning of crossed out wheeled dustbin: Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being. - Page 15 INSTRUCTION MANUAL : EM-LVC50-A1P L2G SAS 17, AVENUE DU 24 AOÛT 1944 BP90690-69969 CORBAS CEDEX TÉL. : +33(0)4 72 23 23 98 FAX : +33(0)4 72 23 23 99...
