INSTRUCTION MANUAL :
EM-LV50-SP
INSTRUCTION MANUAL
WARE WASHING
EM-LV50-SP
To ensure proper use of this appliance and your safety, please read the following
instructions completely before operating this appliance.
English – Original
L2G SAS 17, AVENUE DU 24 AOÛT 1944
BP90690-69969 CORBAS CEDEX
TÉL. : +33(0)4 72 23 23 98 FAX : +33(0)4 72 23 23 99
Advertisement
Table of Contents
Related Manuals for BM L2G saro EM-LV50-SP
Summary of Contents for BM L2G saro EM-LV50-SP
- Page 1 INSTRUCTION MANUAL : EM-LV50-SP INSTRUCTION MANUAL WARE WASHING EM-LV50-SP To ensure proper use of this appliance and your safety, please read the following instructions completely before operating this appliance. English – Original L2G SAS 17, AVENUE DU 24 AOÛT 1944 BP90690-69969 CORBAS CEDEX TÉL.
- Page 2 INSTRUCTION MANUAL : EM-LV50-SP Index 1. Installation instructions 1.1 Introduction 1.2 Advantages 1.2.1 Legal provisions / Requirements 1.3 Installation 1.3.1 Installation suggestions 1.4 Connection to the water supply 1.4.1 Drainage connection 1.5 Electrical Network connection 1.5.1 Protective duct connection and voltage compensation 2.
-
Page 3: Installation Instructions
INSTRUCTION MANUAL : EM-LV50-SP 1. INSTALLATION INSTRUCTIONS 1.1 INTRODUCTION This appliance complies with the needs of modern and professional cooking. Please read these instructions carefully before operating this appliance. In this manual you will find all significant safety indications, as well as other essential information needed for the regular start-up - and operation itself - of the appliance. -
Page 4: Installation Suggestions
INSTRUCTION MANUAL : EM-LV50-SP 1.3 Installation This dishwasher is delivered with water inlet and outlet hoses. According to its construction, the connection of the machine to water and power supply must be performed by an authorized and locally recognized installer by keeping the existing specifications. Before connecting the appliance, check that the connection data on the data plate (voltage and connected load) match the mains electricity supply. - Page 5 INSTRUCTION MANUAL : EM-LV50-SP 2. OPERATING INSTRUCTIONS 2.1 Technical data You can find the technical data of each appliance at the adhesive label of the dishwasher. 2.2 Instructions for the dishwasher’s regular operation The appliance is exclusively used to clean dishes, cups, glasses, silverware, etc. following their use during lunches/dinners. You should pay special attention that the items to be washed are suitably placed for dishwashing.
- Page 6 INSTRUCTION MANUAL : EM-LV50-SP Do not use caustic products. If you do not follow this indication, you will not be covered by the guarantee. 2.7 Starting the washing program - Filling the boiler • Check that the suction filter, in the tank, has been placed in the correct position. •...
-
Page 7: Daily Works
INSTRUCTION MANUAL : EM-LV50-SP except the one anticipated, in case of fault or improper use. The water inside the dishwasher is not potable. Use, maintenance and repair of dishwasher should be performed only by persons familiar with these works and informed for any possible risks. 2.8.2 Daily works •... -
Page 8: Customer Service
INSTRUCTION MANUAL : EM-LV50-SP You should take care to move towards the smoothing direction, so that you will not scratch the surface. Finally, rinse with clean water and dry thoroughly. We remind you that corrosion (rust formation) on stainless steel surfaces is not created by itself, but rather due to the use of improper cleaning aid (e.g. -
Page 9: Troubleshooting
INSTRUCTION MANUAL : EM-LV50-SP 2.12 Troubleshooting PROBLEM CAUSE SOLUTION The dishwasher does not operate properly Connection interruption Check the connection You have not turned the switch of the appliance ON Turn the switch ON Main switch / or fuse has not been activated / or it Check the main switch / or fuse is faulty The switch of the appliance is faulty... - Page 10 INSTRUCTION MANUAL : EM-LV50-SP RATINGS AND EXPECTATIONS 50x50 cm BASKET INLET WATER MUST NOT EXCEED 55oC 25,50 Φ40/Μ10 FOOT DETAIL A SCALE 1 : 3 DETAIL B SCALE 1 : 3 ALL PIPES, CABLES AND HOSES WRITTEN AT DESCRIPTION TAB ARE PROVIDED BY CONSTRUCTOR Customer: BUBBLE INFORMATION Order Date:...
-
Page 11: Electrical Diagram
INSTRUCTION MANUAL : EM-LV50-SP ELECTRICAL DIAGRAM TS 1 TS 2 K1.1 K1.2 K1.3 TF 2 TF 1 S 1 : Main switch M 1 : Wash pump motor ELECTRICAL DIAGRAM S 2 : Start switch M 2 : Timers motor S 3 : Doors cut off switch M 3 : Drainage pump motor EM-LV50... -
Page 12: Exploded View And Spare Parts List
INSTRUCTION MANUAL : EM-LV50-SP EXPLODED VIEW AND SPARE PARTS LIST /QTY. ITEM ITEM NO. PART NUMBER DESCRIPTION QTY. PART NUMBER DESCRIPTION 001.50.00011 BACK PART OF THE DOOR V-K 001.50.00048 FRONT COVER INOX V50 001.50.00027 FRONT PART OF THE DOOR V-K 001.50.00046 DOOR COMPLETE V50 - K50 001.00.00045... - Page 13 INSTRUCTION MANUAL : EM-LV50-SP VERGINA/QTY. VERGINA/QTY. ITEM NO. PART NUMBER DESCRIPTION ITEM NO. PART NUMBER DESCRIPTION 002.50.00036 WASHING BASE DOWN V-K COMPLETE BASE INOX FOR THE ELECTRICAL 003.00.00077 DOOR SWITCH GALVANIZED LOCK WASHER 001.00.00204 6,4x11x0,7 003.00.00065 GALV. HEX. BOLT M3X16 003.00.00041 NUT M6 GALVANISED 003.00.00069...
- Page 14 INSTRUCTION MANUAL : EM-LV50-SP VERGINA/ VERGINA ITEM ITEM NO. PART NUMBER DESCRIPTION PART NUMBER DESCRIPTION 230V/QTY QTY. 003.00.00516 WASHER STEEL Φ6X18 001.50.00017 BOILER V500 Φ140Χ400 GALVANIZED LOCK WASHER 001.00.00204 6,4x11x0,7 002.50.00001 OUTLET BASE BOILER V500 003.00.00041 NUT M6 GALVANISED 002.00.00076 BOILER DRAIN THREADED CAP 003.00.00268 HYDRAULIC RINSE AID PUMP...
-
Page 15: Standards And Directives
INSTRUCTION MANUAL : EM-LV50-SP STANDARDS AND DIRECTIVES Meaning of crossed out wheeled dustbin: Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being. - Page 16 INSTRUCTION MANUAL : EM-LV50-SP L2G SAS 17, AVENUE DU 24 AOÛT 1944 BP90690-69969 CORBAS CEDEX TÉL. : +33(0)4 72 23 23 98 FAX : +33(0)4 72 23 23 99...
