SpeedTech Lights K-Force Micro Tow Series Operation Manual And Instructions

60" linear maxgen led light bar
Hide thumbs

Advertisement

Quick Links

Download this manual
Phone 800.757.2581
STL K-Force
Congratulations, you are the owner of a STL K-Force
equipped with the latest technology and features at the best value found industry wide,
GUARANTEED. In addition to that, your purchase comes with the STL 5 Year Warranty against
any manufacture defects that may occur with your bar. So please read this document carefully
and call Customer Service at 800-757-2581 Monday - Friday 8:30 AM - 4:30 PM central time if
you need assistance. We are available and happy to help!
This document must be delivered to and read by the end user and installer as it serves to
provide you with the required information for proper and safe use of your STL product. Before
operating this or any STL products the user and installer must read this manual all the way
through. You will find important information in this manual that could prevent property damage
and/or serious injury to the user and installer.
STL products are intended to alert pedestrians and other operators of the presence of
personnel, the operation of emergency vehicles, an emergency site, and any warning needs. This
does not ensure that pedestrians or drivers will react, heed, or observe emergency warning
signals. Nor does the use of emergency signals grant or ensure you the right of way. It is your
responsibility to make sure you can proceed safely before driving against traffic, entering an
intersection, responding at a high rate of speed, or walking on or around traffic lanes.
Your STL emergency vehicle devices should be tested daily to insure the device and all its
functions are operating correctly. If you experience a malfunction contact STL's Customer
Service immediately for troubleshooting options, or a warranty or service claim. You must
ensure sure that the projection of the visual and audible signal is not blocked by vehicle
components (i.e.: open trunks, visors, compartment doors), vehicles, other obstructions, or
people.
This is professional grade equipment and is intended for strict use by authorized personnel only.
It is the user's responsibility to understand and obey all laws regarding emergency warning
devices. You must know and be familiar with all applicable city, state, and federal laws and
regulations prior to the use of emergency vehicle warning devices.
218 Trademark Dr
•
Fax 844.894.2652
Micro 60" Linear Tow MaxGen™ (U.S. Patent No. D652,753)
®
Operation Manual and Instructions
Warnings and Notices for Users and Installers
•
Buda
•
Texas •78610
•
Email customerservice@speedtechlights.com
Micro Tow Series Light bar! Your bar is
®
1
(c) 2016 SpeedTech Lights, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the K-Force Micro Tow Series and is the answer not in the manual?

Questions and answers

Related Manuals for SpeedTech Lights K-Force Micro Tow Series

Summary of Contents for SpeedTech Lights K-Force Micro Tow Series

  • Page 1 It is the user's responsibility to understand and obey all laws regarding emergency warning devices. You must know and be familiar with all applicable city, state, and federal laws and regulations prior to the use of emergency vehicle warning devices. (c) 2016 SpeedTech Lights, Inc.
  • Page 2 Fax 844.894.2652 Email customerservice@speedtechlights.com SpeedTech Lights, Inc. assumes no liability for any loss resulting from the use of this warning device. Proper installation is vital to the performance of the warning devices and safe operation of the emergency vehicle. Since the operator is under stressful environments the equipment must be properly wired and mounted to ensure effectiveness and safety.
  • Page 3 - Never activate or control your equipment in hazardous driving conditions. (c) 2016 SpeedTech Lights, Inc.
  • Page 4 Don’t be fooled by the compact style of the K-Force Micro 60" Linear LED Full Size Tow Light Bar from SpeedTech Lights. Although only 5” in width, the 60” Linear Tow contains all the power of a full sized light bar with 150 piercing 3-watt MaxGen CREE LEDs and magnifying linear optics.

  • Page 5: Slide Switch

    Off position: All warning functions of the light bar are off 1st position: Powers only the front of the bar plus forward facing 45 warning modules 2nd position: Powers only the back of the bar plus rear facing 45 warning modules (c) 2016 SpeedTech Lights, Inc.
  • Page 6 *These functions can be operated independently of the light bar's warning lights being activated Unpacking your STL Product Unpack your unit to identify all parts including but not limited to: light bar, switch box, brackets, screws, bolts, wiring harness, fuses, etc. (c) 2016 SpeedTech Lights, Inc.
  • Page 7 To protect against short circuits, a fuse is included by STL for all products. Do NOT use a fuse with a higher amp rating than the initial fuse included. (c) 2016 SpeedTech Lights, Inc.
  • Page 8 B-Pillar taking a 90 Degree turn to enter the B-pillar. Wiring: Aux Function This unit will have an Independent Cable Harness for the Aux Function.  The Aux Button is rated for 10 AMPs. Do not exceed 10 AMPs on the Aux.  (c) 2016 SpeedTech Lights, Inc.
  • Page 9 Now that you have pulled the cable into the vehicle attach the connector back to your  light bar's wire harness in the CORRECT positions using the photograph or notation made prior to removal and plug it into your STL Supreme II Control Box. If you do not (c) 2016 SpeedTech Lights, Inc.
  • Page 10 Both Take Down lights will come on simultaneously.  If you are not using the STL Supreme II Control Box you will follow the wiring diagram to  identify the Take Down wires to manually program. When not using the Supreme II (c) 2016 SpeedTech Lights, Inc.

  • Page 11: Maintenance

    Never take any STL Light bars through a car wash, such as a pressure washer, automatic  car wash, brushes that will scratch your equipment or similar car washes or equipment (c) 2016 SpeedTech Lights, Inc.

  • Page 12: Troubleshooting

    Customer Service immediately for assistance at 1-800-757-2581. Problem Scenarios Possible Cause Trouble Shooting Warning LED Are all the LED module has one Diodes out? or all diodes out (c) 2016 SpeedTech Lights, Inc.
  • Page 13 Negative (black), directly to the battery? If grounded incorrectly, an electrical feedback could be the Improper Grounding. culprit. Electrical feedback can cause the PCB not to recognize the command that it is being told to do. (c) 2016 SpeedTech Lights, Inc.
  • Page 14 Stay Safe and Continue Lighting the Way with SpeedTech Lights ® ® We know that Trust is Earned Thank you for giving STL the opportunity to earn your business ®! and trust. Visit www.SpeedTechLights.com for any additional information and services regarding (c) 2016 SpeedTech Lights, Inc.
  • Page 15 .pdf reproduction, or any other means of reproducing all or any part hereof without the express prior written consent of the SpeedTech Lights, Inc., except for non-commercial purposes as permitted by United States copyright law.
