Phone 800.757.2581
STL K-Force
Congratulations, you are the owner of a STL K-Force
equipped with the latest technology and features at the best value found industry wide,
GUARANTEED. In addition to that, your purchase comes with the STL 5 Year Warranty against
any manufacture defects that may occur with your bar. So please read this document carefully
and call Customer Service at 800-757-2581 Monday - Friday 8:30 AM - 4:30 PM central time if
you need assistance. We are available and happy to help!
This document must be delivered to and read by the end user and installer as it serves to
provide you with the required information for proper and safe use of your STL product. Before
operating this or any STL products the user and installer must read this manual all the way
through. You will find important information in this manual that could prevent property damage
and/or serious injury to the user and installer.
STL products are intended to alert pedestrians and other operators of the presence of
personnel, the operation of emergency vehicles, an emergency site, and any warning needs. This
does not ensure that pedestrians or drivers will react, heed, or observe emergency warning
signals. Nor does the use of emergency signals grant or ensure you the right of way. It is your
responsibility to make sure you can proceed safely before driving against traffic, entering an
intersection, responding at a high rate of speed, or walking on or around traffic lanes.
Your STL emergency vehicle devices should be tested daily to insure the device and all its
functions are operating correctly. If you experience a malfunction contact STL's Customer
Service immediately for troubleshooting options, or a warranty or service claim. You must
ensure sure that the projection of the visual and audible signal is not blocked by vehicle
components (i.e.: open trunks, visors, compartment doors), vehicles, other obstructions, or
people.
This is professional grade equipment and is intended for strict use by authorized personnel only.
It is the user's responsibility to understand and obey all laws regarding emergency warning
devices. You must know and be familiar with all applicable city, state, and federal laws and
regulations prior to the use of emergency vehicle warning devices.
218 Trademark Dr
•
Fax 844.894.2652
Micro 60" Linear MaxGen™ (U.S. Patent No. D652,753)
®
Operation Manual and Instructions
Warnings and Notices for Users and Installers
•
Buda
•
Texas •78610
•
Email customerservice@speedtechlights.com
Micro Series Light bar! Your bar is
®
1
(c) 2016 SpeedTech Lights, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the K-Force Micro Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SpeedTech Lights K-Force Micro Series

Summary of Contents for SpeedTech Lights K-Force Micro Series

  • Page 1 It is the user's responsibility to understand and obey all laws regarding emergency warning devices. You must know and be familiar with all applicable city, state, and federal laws and regulations prior to the use of emergency vehicle warning devices. (c) 2016 SpeedTech Lights, Inc.
  • Page 2 Fax 844.894.2652 Email customerservice@speedtechlights.com SpeedTech Lights, Inc. assumes no liability for any loss resulting from the use of this warning device. Proper installation is vital to the performance of the warning devices and safe operation of the emergency vehicle. Since the operator is under stressful environments the equipment must be properly wired and mounted to ensure effectiveness and safety.
  • Page 3 - Never activate or control your equipment in hazardous driving conditions. (c) 2016 SpeedTech Lights, Inc.
  • Page 4 The K-Force Micro 60” Linear LED Light Bar includes mounting brackets, adjustable feet brackets, 13 feet of cable, and an optional Supreme II Control box, giving you everything you need to own the night, all at an affordable price you can only find at SpeedTech Lights. Features: 5 Year Warranty* ...

  • Page 5: Slide Switch

    3rd position: Power bar 360 (all warning) *Take Down Button 1st press: Steady Burn 2nd press: Pulsing Flash 3rd press: Flash in the same sequence/flash pattern as the light bar when the warning lights are activated (c) 2016 SpeedTech Lights, Inc.
  • Page 6 Some products may be packaged inside boxes of other products. Some parts such as Gutter Brackets, may be in the foam protection. Double check that no parts are left within the foam protection or left in the box. Pre-Installation and Testing (c) 2016 SpeedTech Lights, Inc.
  • Page 7 STL for all products. Do NOT use a fuse with a higher amp rating than the initial fuse included. Do NOT use Circuit Breaks with STL Products. Ground terminations should only be made directly to the battery. Mounting with STL Vehicle Specific Bracket or Gutter Mount Bracket (c) 2016 SpeedTech Lights, Inc.
  • Page 8 You will solder, and heat shrink the Negative wire from the cable harness to the Negative  wire of your light unit. Wiring Diagram for Aux power harness with 2 Conductors  (c) 2016 SpeedTech Lights, Inc.
  • Page 9 If you did not purchase the Supreme II Control Box and are using your own switch box or  the STL IntelliSiren, wire the cables accordingly into your control panel by referencing the wiring diagram and instruction manual of your control panel. Wiring: Connecting Extension Cables (c) 2016 SpeedTech Lights, Inc.
  • Page 10 The K-Force series 36" and up will feature two (2) Alleys in 3 Watt LEDs which have three  functions; steady burn, pulsing flash, or flashing in sequence with the light bar's warning pattern when warning mode is activated. Both Alley lights will come on simultaneously.  (c) 2016 SpeedTech Lights, Inc.

  • Page 11: Maintenance

    Use Water (H 0) with a soft cloth to clean your light bar and lenses.  Yellowing of clear lenses may occur over time. Lenses can be purchased by calling STL  Customer Service at 800-757-2581. (c) 2016 SpeedTech Lights, Inc.

  • Page 12: Troubleshooting

    2. Unscrew the two screws that secure the LED module to disconnected from the light bar. Connector or LED. 3. Pull the LED out gently and slowly. 4. You will see red and black wires that lead to a connector. (c) 2016 SpeedTech Lights, Inc.
  • Page 13 Move the ground to proper location and see if this fixes the issue. A New PCB may be required. Pressing buttons Do the back lights of on the Switch the buttons on the (c) 2016 SpeedTech Lights, Inc.
  • Page 14 Visit www.SpeedTechLights.com for any additional information and services regarding STL Warranty, Return Policy, Videos, or any other Customer Service needs you deem necessary. Shop with Confidence with SpeedTech Lights! ® (c) 2016 SpeedTech Lights, Inc. (c) 2016 SpeedTech Lights, Inc.
  • Page 15 .pdf reproduction, or any other means of reproducing all or any part hereof without the express prior written consent of the SpeedTech Lights, Inc., except for non-commercial purposes as permitted by United States copyright law.
