Summary of Contents for BPE PowerDepot M-2.4
- Page 1 V1.0 PowerDepot M-2.4 User Manual...
-
Page 2: Table Of Contents
BPE M-2.4kWh User Manual Content ______________________________________________________________ 1 Statement of Law _____________________________________________________________ 2 Safety Precautions ________________________________________________________________________ 3 Preface _________________________________________________________________ 1 1 Introduction 1.1 Brief Introduction ________________________________________________________________ 1 1.2 Product Properties _______________________________________________________________ 1 1.3 Product identity definition _______________________________________________________ 1 _________________________________________________________ 3 2 Product Specification 2.1 Size and Weight __________________________________________________________________ 3... -
Page 3: Statement Of Law
BPE M-2.4kWh User Manual Statement of Law Copyright of this document belongs to our company. No part of this documentation maybe excerpted, reproduced, translated, annotated or duplicated in any form or by any means without the prior written authorization of our company. All Rights Reserved. -
Page 4: Safety Precautions
BPE M-2.4kWh User Manual Safety Precautions Warning ⚫ Please do not put the battery into water or fire, in case of explosion or any other situation that might endanger your life. ⚫ Please connect wires properly while installation, do not reverse connect. -
Page 5: Preface
Preface Manual declaration BPE M-2.4kWh lithium iron phosphate battery energy storage system can be combined in series or parallel to provide energy storage function for photovoltaic power generation users. Our product can store extra electricity into battery from photovoltaic power generation system in daytime and supply stable power to user’s equipment as power backup at nighttime or any time... -
Page 6: Introduction
BPE M-2.4kWh lithium iron phosphate battery system is a standard battery system unit, customers can choose a certain number of BPE 2.4 kWh according to their needs, by connecting parallel to form a larger capacity battery pack, to meet the user's long-term power supply needs. - Page 7 BPE 2.4kWh Unit User Manual Danger shock hazard Handle the unit with care, as misuse may result in accidents Read the user manual before installation. The scrapped battery cannot be put into the garbage can and must be professionally recycled.
-
Page 8: Product Specification
Weight Voltage Capacity BPE M-2.4kWh ~22 kg 48 VDC 50 Ah 480×360×90mm 2.2 Performance Parameters Table 2-2 BPE M-2.4kWh performance parameters BPE 2.4kWh Parameters Nominal Voltage(V) Work Voltage Range(V) 42~54 Nominal Capacity(Ah) Nominal Energy(kWh) Nominal Power(kW) Max Power(kW) 1S Peak Power(kW) 2.64... -
Page 9: Dip Switch Definition And Description
BPE M-2.4kWh User Manual Table 2-3 Interface Definition Item Name Definition OFF/ON, Power switch must be in the "ON" state when in use Ground Shell ground connection connection point Positive Terminal Battery output positive or parallel positive line Negative Terminal Battery output negative or parallel negative line SW (battery When the "OFF/ON"... - Page 10 BPE M-2.4kWh User Manual 1. If the host is the latest BPE M-2.4kWh battery with 2. If the host is a BPE M-2.4kWh DIP switch: battery module without the DIP (1) The communication cable that communicates with switch: the inverter should use the correct one.
- Page 11 BPE M-2.4kWh User Manual Caution ： The DIP switch mode in case (5),1001&0001 is only for ICC(a special commnunication device of some no-communication inverter), it’s a specia firmware in battery BMS,different from general firmware,so if customers want to use that,please contact us to confirm.
-
Page 12: Battery Management System(Bms)
BPE M-2.4kWh User Manual Table 2-5 LED status indicators Battery LED1 LED2 LED3 LED4 Status Shutdown ● ● ● ● 75%≤SOC≤100% Flashing ● ● ● 50%≤SOC＜75% Flashing ● ● Flashing 25%≤SOC＜50% Standby ● Flashing 5%＜SOC＜25% ● 0%＜SOC≤5% Flashing Flashing Flashing/... -
Page 13: Temperature Protection
BPE M-2.4kWh User Manual Caution: The buzzer sound alarm setting can be manually turned off on the background software, and the factory default is on. 2.4.3 Temperature Protection Low/Over temperature protection in charging： When battery’s temperature is beyond range of 0 ℃ ~+55 ℃ during charging, temperature protection is activated, device stops charging. -
Page 14: Environmental Requirements
BPE M-2.4kWh User Manual 3.1.1 Environmental requirements Working temperature: -20 °C ~ +55 °C • Charging temperature range is 0 °C~+55 °C, Discharging temperature range is -20 °C ~+55 °C • Storage temperature: -10 °C ~ +35 °C Relative humidity: 5% ~ 85%RH... -
Page 15: Unpacking Inspection
BPE M-2.4kWh User Manual The security check ⚫ Firefighting equipment should be provided near the product, such as portable dry powder fire extinguisher. ⚫ Automatic fire fighting system shall be provided for the case where necessary. ⚫ No flammable, explosive and other dangerous product are placed beside the battery. -
Page 16: Engineering Coordination
BPE M-2.4kWh User Manual Black Communication L2000 mm /Double cable-to inverter RJ45 plug Ground wire L500 mm,4 mm² Combination screws Screw M6*14 3.1.5 Engineering coordination Attention should be paid to the following items before construction: ⚫ Power line specification. The power line specification shall meet the requirements of maximum discharge current for each product. -
Page 17: Equipment Installation
3.2.1 Installation preparation 1. Prepare equipment and tools for installation. 2. Check the BPE 2.4 kWH unit and confirm that the ON/OFF switch is in the "OFF" state to ensure the device is shut off.. 3.2.2 Mechanical installation Installation method 1: With Cabinet installation 1. - Page 18 Installation method 2: With Simple bracket installation 1. Place a pair of brackets in the workspace as shown in the figure 3-4. Figure3-4 2. Insert the BPE M-2.4kWh into the bracket as figure 3-5. Secure the battery to the brackets with four screws. Figure3-5 3.
-
Page 19: Electrical Installation
BPE M-2.4kWh User Manual 5. Stack the required number of battery and bracket combinations as described above, and fasten the upper and lower buckles. Shown as Figure 3-8. Figure3-8 3.2.3 Electrical installation Before connecting the power cables, using AVO meter to measure cable continuity, short circuit, confirm positive and negative, and accurately mark the cable labels. - Page 20 BPE M-2.4kWh User Manual Inverter Circuit breaker Communication cable-to inverter Power cable- negative Power cable- positive Parallel cable- negative Parallel cable- positive Communication parallel cable No.1 No.2 No.3 No.4 No.5 No.6 Figure3-8 Note: 1.After the whole system connection,set the master DIP mode according to the inverter model firstly,then start the battery.
-
Page 21: Battery Parameter Settings On The Inverter
Absorption Voltage: 53 V Float Voltage: 52.5 V Shut Down(cut off) Voltage: 47 V Shut Down(cut off) SOC: 20% Restart Voltage: 49 V Max Charge Current: : 25 A*battery QTY Max Discharge Current: : 25 A*battery QTY Capacity: 1*BPE M-2.4kWh=50 Ah... -
Page 22: Use, Maintenance And Troubleshooting
BPE M-2.4kWh User Manual 4 Use, maintenance and troubleshooting 4.1 Battery system usage and operation instructions After completing the electrical installation, follow these steps to start the battery system. Refer to the description of the DIP switch of 2.3.1 to prepare the battery module before starting up, then press the ON/OFF button to the ON position, next press and hold the SW button for 3 seconds. -
Page 23: Alarm Description And Processing
4.2 Alarm description and processing When protection mode is activated or system failure occurred, the alarm signal will be given through the working status indicator on the front panel of the BPE M-2.4kWh. The network management can query the specific alarm categories. -
Page 24: Analysis And Treatment Of Common Faults
BPE M-2.4kWh User Manual 4.3 Analysis and treatment of common faults Analysis and treatment of common faults in the Table 4-3: Table 4-3 Analysis and treatment of common faults Fault phenomenon Reason analysis Solution The indicator does not Total voltage...
