OWNER'S MANUAL & INSTALLATION INSTRUCTIONS
Charleston frame must be installed on the wall as there is no connecting part
between Atchitectural Arms (AA)and Top Bar (TB).
Please read instructions fully before installing.
WARNING: CHOAKING HAZARD – Contains small part, and Sharp metal. CAUTION:
When you are opening the box keep children away. Be extremely cautious around
Models with Valance:
CH22, ECH 23, CH32, CH34, CH43, CH44, ECH2442, ECH12, ECH1836, ECH1230,
ECH1030, ECH24, CH33
Models without Valance:
CH22-NV, ECH 23-NV, CH32-NV, CH34-NV, CH43-NV, CH44-NV, ECH2442-NV, ECH12-NV,
ECH1836-NV, ECH1230-NV, ECH1030-NV, ECH24-NV, CH33-NV
Awning size
3
4
5
6
7
8
9
10
11
OUR AWNINGS ARE DESIGNED 4.5" WIDER THAN STANDARD WINDOW/DOOR
OPENINGS SO THEY ANCHOR TO THE STUDS AROUND THE WINDOW OR DOOR.
EXAMPLE: RR22-5 IS FOR 5'-0" WIDE WINDOW. IT MEASURES 64.5" WIDE, 31" TALL, (24"
1
Charleston Style Awning
Important Installation Information:
Width in inches
40.5
52.5
64.5
76.5
88.5
100.5
112.5
124.5
136.5
PLUS 7" VALANCE AND 24" DEEP (PROJECTION)
children.
Awning Size
12
13
14
15
16
17
18
19
20
Width to Inches
148.5
160.5
172.5
184.5
196.5
208.5
220.5
232.5
244.5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Awntech CH22
Summary of Contents for Awntech CH22
- Page 1 When you are opening the box keep children away. Be extremely cautious around children. Models with Valance: CH22, ECH 23, CH32, CH34, CH43, CH44, ECH2442, ECH12, ECH1836, ECH1230, ECH1030, ECH24, CH33 Models without Valance: CH22-NV, ECH 23-NV, CH32-NV, CH34-NV, CH43-NV, CH44-NV, ECH2442-NV, ECH12-NV,...
- Page 2 There are a variety of building wall surfaces, Awntech does not supply the hardware to install your awning. You will need to purchase installation hardware at your local hardware store. We have advised you on different surface applications below: CONCRETE BLOCK WALLS: (1)1/2” masonry bit with a 3/8” shank, (4-5) 5/16”X3” Masonry anchor bolts, 9/16”...
- Page 3 Charleston frame must be installed on the wall as there is no connecting part between Spear Arm (SA)and Top Bar (TB) STEP 1: Separate all of the parts, so they will be easy to assemble. STEP 2: The Top Bar (TB) must be installed first. Mount Provided Z-Brackets to surface, and insert TB into brackets.
- Page 4 Height between Height Projecti Model TB and incl. Projection Model TB and incl. BP in Valance BP in Valance inches inches CH22 CH22-NV CH32 CH32-NV CH33 CH33-NV CH34 CH34-NV CH43 CH43-NV CH44 CH44-NV ECH2442 ECH2442-NV CH21 CH21-NV ECH1836 ECH1836-NV...
- Page 5 Step 4: Install the Front Bar (FB) to the Architectural arms (AA). Secure with self tapping screws. Velcro will face out. STEP 4: Install the NC (left and right) with arrow facing upwards. Secure them with self tapping screws, The holes on the (FB) and (TB) are pre-drilled. Make sure that the Velcro on NCs are facing outwards.
-
Page 6: Installing The Cover
The Frame for Charleston is complete. Frame 2’-4’ Frame 5’-7’ INSTALLING THE COVER STEP 5: Slide the tubing at the top of the fabric cover into the C-Channel on the top of (TB). -
Page 7: Cleaning & Caring
STEP 6: Pull the remainder of fabric over the fame with the valance hanging down below the (NC) and (FB) bars. Frame 2’-4’ Frame 5’-7’ STEP 7: Once you are satisfied with the position of the cover, Pull the tabs snugly and attach them to the pre-installed Velcro tape on the bars. -
Page 8: Warranty
D. WHAT ARE THE RESPONSIBILITIES OF AWNTECH UNDER THIS WARRANTY? Subject to the terms and conditions set forth herein, Awntech Corporation will furnish replacements for parts found by Awntech Corporation to be defective in design, manufacture or assembly, under each specific component or product warranty as set forth below. - Page 9 (a) Should the purchaser promptly notify Awntech Corporation of such defects within one year (12 months) from the date of the original purchase, the defective component will be replaced at no charge. Awntech reserves the right to ask for the defective part to be returned and/or photos of the defective part.
- Page 10 THROUGH THE WARRANTY PROCESS: E-mail Photos of damaged parts to: customers@awntech.com or mail to: Awntech Corporation, 10950 S. Pipeline Rd., Bldg 1, Euless, TX 76040 Authorized returns should be shipped to: Returns Department: Awntech Corporation, 10950 S. Pipeline Rd., Bldg 1, Euless, TX 76040...
