TECHNICAL MANUAL
INVERTER WALL MOUNTED TYPE
RESIDENTIAL AIR-CONDITIONERS
(Split system, air to air heat pump type)
DXK09Z6-W
DXK12Z6-W
DXK15Z6-W
DXK18Z6-W
Manual No.'20・DXK-T-321

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DXK12Z6-W and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Heavy Industries DXK12Z6-W

Summary of Contents for Mitsubishi Heavy Industries DXK12Z6-W

  • Page 1 Manual No.'20・DXK-T-321 TECHNICAL MANUAL INVERTER WALL MOUNTED TYPE RESIDENTIAL AIR-CONDITIONERS (Split system, air to air heat pump type) DXK09Z6-W DXK12Z6-W DXK15Z6-W DXK18Z6-W...

  • Page 2: Table Of Contents

    '20 • DXK-T-321 CONTENTS 1. SPECIFICATIONS ..................... 3 2. EXTERIOR DIMENSIONS ................8 (1) Indoor units ....................8 (2) Outdoor units ..................... 9 (3) Wireless remote control ................11 3. ELECTRICAL WIRING ................... 12 (1) Indoor units ....................12 (2) Outdoor units ...................
  • Page 3 '20 • DXK-T-321 (8) Phenomenon observed after short-circuit, wire breakage on sensor ..68 (9) Checking the indoor electrical equioment ..........69 (10) How to make sure of wireless remote control .......... 70 (11) Outdoor unit inspection points ..............71 11.

  • Page 4: Specifications

    '20 • DXK-T-321 1. SPECIFICATIONS Model DXK09Z6-W DXK09Z6-W Model Item Indoor unit DXK09Z6-W Outdoor unit DXC09Z6-W Power source 1 Phase, 220 - 240V, 50Hz Nominal cooling capacity (range) 2.5 ( 0.9 (Min.) - 3.1 (Max.)) Nominal heating capacity (range) 2.8 ( 1.0 (Min.) - 4.1 (Max.)) Heating capacity (H2) Cooling 0.710 ( 0.20 - 1.01 )
  • Page 5 '20 • DXK-T-321 Model DXK12Z6-W DXK12Z6-W Model Item Indoor unit DXK12Z6-W Outdoor unit DXC12Z6-W Power source 1 Phase, 220 - 240V, 50Hz Nominal cooling capacity (range) 3.2 ( 0.9 (Min.) - 3.7 (Max.)) Nominal heating capacity (range) 3.6 ( 1.0 (Min.) - 4.6 (Max.))
  • Page 6 '20 • DXK-T-321 Model DXK15Z6-W DXK15Z6-W Model Item Indoor unit DXK15Z6-W Outdoor unit DXC15Z6-W Power source 1 Phase, 220 - 240V, 50Hz Nominal cooling capacity (range) 4.5 ( 1.3 (Min.) - 4.8 (Max.)) Nominal heating capacity (range) 5.0 ( 1.2 (Min.) - 5.8 (Max.)) Heating capacity (H2) Cooling 1.350 ( 0.29 - 1.71 )
  • Page 7 '20 • DXK-T-321 Model DXK18Z6-W DXK18Z6-W Model Item Indoor unit DXK18Z6-W Outdoor unit DXC18Z6-W Power source 1 Phase, 220 - 240V, 50Hz Nominal cooling capacity (range) 5.0 ( 1.3 (Min.) - 5.2 (Max.)) Nominal heating capacity (range) 5.6 ( 1.2 (Min.) - 5.8 (Max.)) Heating capacity (H2) Cooling 1.740 ( 0.29 - 1.86 )
  • Page 8 Plastic Steel Wood Glass Others weight nium weight styrene Model DXK09Z6-W 0.94 0.64 0.24 0.06 0.00 0.00 0.00 0.00 0.00 DXK12Z6-W 0.94 0.64 0.24 0.06 0.00 0.00 0.00 0.00 0.00 Indoor DXK15Z6-W 0.94 0.64 0.24 0.06 0.00 0.00 0.00 0.00 0.00...

  • Page 9: Exterior Dimensions

    '20 • DXK-T-321 2. EXTERIOR DIMENSIONS (1) Indoor units Models DXK09Z6-W, 12Z6-W, 15Z6-W, 18Z6-W RLC000Z105...

  • Page 10: Outdoor Units

    '20 • DXK-T-321 (2) Outdoor units Models DXC09Z6-W, 12Z6-W RCW000Z007...
  • Page 11 '20 • DXK-T-321 Models DXC15Z6-W, 18Z6-W RCV000Z038...

  • Page 12: Wireless Remote Control

    '20 • DXK-T-321 (3) Wireless remote control Unit: mm...

  • Page 13: Electrical Wiring

    '20 • DXK-T-321 3. ELECTRICAL WIRING (1) Indoor units Models DXK09Z6-W, 12Z6-W, 15Z6-W, 18Z6-W RLC000Z107...

  • Page 14: Outdoor Units

    '20 • DXK-T-321 (2) Outdoor units Models DXC09Z6-W, 12Z6-W RWC000Z324...
  • Page 15 '20 • DXK-T-321 Models DXC15Z6-W, 18Z6-W, RWC000Z325...

  • Page 16: Noise Level

    '20 • DXK-T-321 4. NOISE LEVEL (1) Sound power level Model DXK09Z6-W (Indoor unit) Model DXK09Z6-W Condition ISO5151 T1/H1 Noise Cooling 57 dB(A) MODE Rated capacity value (Hi) level Heating 57 dB(A) × ..Cooling Heating 70.0 60.0 50.0 40.0 30.0 20.0 10.0...
  • Page 17 '20 • DXK-T-321 Model DXK12Z6-W (Indoor unit) Model DXK12Z6-W Condition ISO5151 T1/H1 Noise Cooling 58 dB(A) MODE Rated capacity value (Hi) level Heating 58 dB(A) × ..Cooling Heating 70.0 60.0 50.0 40.0 30.0 20.0 10.0 1000 2000 4000 8000...
  • Page 18 '20 • DXK-T-321 Model DXK15Z6-W (Indoor unit) Model DXK15Z6-W Condition ISO5151 T1/H1 Cooling 56 dB(A) Noise MODE Rated capacity value (Hi) level Heating 62 dB(A) × ..Cooling Heating 70.0 60.0 50.0 40.0 30.0 20.0 10.0 1000 2000 4000 8000 Mid octave band frequency (Hz) (Outdoor unit) Model...
  • Page 19 '20 • DXK-T-321 Model DXK18Z6-W (Indoor unit) Model DXK18Z6-W Condition ISO5151 T1/H1 Cooling 59 dB(A) Noise MODE Rated capacity value (Hi) level Heating 63 dB(A) × ..Cooling Heating 70.0 60.0 50.0 40.0 30.0 20.0 10.0 1000 2000 4000 8000 Mid octave band frequency (Hz) (Outdoor unit) Model...
  • Page 20 '20 • DXK-T-321 (2) Sound pressure level (a) Rated capacity value Condition ISO5151 T1/H1 Model DXK09Z6-W MODE Rated capacity value (Hi) (Indoor unit) Mike position Model DXK09Z6-W 0.8m Cooling 45 dB(A) Noise Unit Mike position level Heating 43 dB(A) (Center & low points) ×...
  • Page 21 '20 • DXK-T-321 Condition ISO5151 T1/H1 Model DXK12Z6-W MODE Rated capacity value (Hi) (Indoor unit) Mike position Model DXK12Z6-W 0.8m Cooling 45 dB(A) Noise Unit Mike position level Heating 44 dB(A) (Center & low points) × ..Cooling Heating Mike position: at highest noise level in position as mentioned below...
  • Page 22 '20 • DXK-T-321 Condition ISO5151 T1/H1 Model DXK15Z6-W MODE Rated capacity value (Hi) (Indoor unit) Mike position Model DXK15Z6-W 0.8m Cooling 44 dB(A) Noise Unit Mike position level Heating 48 dB(A) (Center & low points) × ..Cooling Heating Mike position: at highest noise level in position as mentioned below Distance from front side 1m 1000 2000...
  • Page 23 '20 • DXK-T-321 Condition ISO5151 T1/H1 Model DXK18Z6-W MODE Rated capacity value (Hi) (Indoor unit) Mike position Model DXK18Z6-W 0.8m Cooling 46 dB(A) Noise Unit Mike position level Heating 48 dB(A) (Center & low points) × ..Cooling Heating Mike position: at highest noise level in position as mentioned below Distance from front side 1m 1000 2000...
  • Page 24 '20 • DXK-T-321 (b) Each fan speed mode Condition ISO5151 T1/H1 MODE (Indoor unit) Mike position Model DXK09Z6-W 0.8m Cooling 34 dB(A) Noise Unit Mike position level Heating 34 dB(A) (Center & low points) × ..Cooling Heating Mike position: at highest noise level in position as mentioned below Distance from front side 1m 1000 2000...
  • Page 25 '20 • DXK-T-321 (Indoor unit) Condition ISO5151 T1/H1 Model DXK12Z6-W MODE Cooling 36 dB(A) Noise Mike position level Heating 36 dB(A) 0.8m Unit Mike position (Center & low points) × ..Cooling Heating Mike position: at highest noise level in position as mentioned below...
  • Page 26 '20 • DXK-T-321 (Indoor unit) Condition ISO5151 T1/H1 Model DXK15Z6-W, 18Z6-W MODE Cooling 39 dB(A) Noise Mike position level Heating 41 dB(A) 0.8m Unit Mike position (Center & low points) × ..Cooling Heating Mike position: at highest noise level in position as mentioned below Distance from front side 1m 1000 2000...

  • Page 27: Piping System

    Room exchanger temperature temperature sensor sensor Heat exchanger Heat exchanger temperature sensor DXK09Z6-W Capillary tube only Strainer DXK12Z6-W Capillary tube only Models DXK15Z6-W, 18Z6-W Outdoor air temperature sensor Discharge pipe temperature sensor Heat Room exchanger temperature temperature sensor sensor Heat...

  • Page 28: Range Of Usage & Limitations

    '18 • LMK-DB-257 '20 • DXK-T-321 6. RANGE OF USAGE & LIMITATIONS 6. RANGE OF USAGE & LIMITATIONS DXK09Z6-W, 12Z6-W DXK15Z6-W, 18Z6-W Net capacity = Capacity shown on specification Correction factors as follows (1) Coefficient of cooling and heating capacity in relation to temperatures Cooling Heating Applicable range...
  • Page 29 (3) Correction relative to frosting on outdoor heat exchanger during heating Air inlet temperature of 5 or more outdoor unit in °C WB Adjustment coefficient 0.95 0.95 0.94 0.93 0.91 0.88 0.86 0.87 0.92 1.00 How to obtain the cooling and heating capacity DXK12Z6-W 3.1kW ≒ DXK12Z6-W...

  • Page 30: Capacity Tables

    1.90 1.81 2.03 1.93 2.25 2.14 2.35 2.23 2.41 2.22 2.58 2.37 2.70 2.33 1.79 1.70 1.92 1.83 2.15 2.04 2.26 2.15 2.32 2.19 2.49 2.34 2.61 2.31 1.68 1.59 1.81 1.72 2.05 1.95 2.16 2.05 2.22 2.11 2.40 2.28 2.53 2.28 Model DXK12Z6-W Cooling Mode (kW)
  • Page 31 '20 • DXK-T-321 Model DXK18Z6-W Cooling Mode (kW) Heating Mode (HC) (kW) Indoor air temperature Outdoor Indoor air temperature Outdoor Air flow ℃DB ℃DB ℃DB ℃DB ℃DB ℃DB ℃DB temperature Air flow temperature 16℃ DB 18℃ DB 20℃ DB 22℃ DB 24℃ DB ℃WB ℃WB ℃WB...

  • Page 32: Application Data

    '20 • DXK-T-321 8. APPLICATION DATA Models DXK09Z6-W, 12Z6-W, 15Z6-W, 18Z6-W...
  • Page 33 '20 • DXK-T-321...
  • Page 34 '20 • DXK-T-321...
  • Page 35 '20 • DXK-T-321...
  • Page 36 '20 • DXK-T-321...
  • Page 37 '20 • DXK-T-321...
  • Page 38 '20 • DXK-T-321...
  • Page 39 '20 • DXK-T-321...

  • Page 40: Outline Of Operation Control By Microcomputer

    '20 • DXK-T-321 9. OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER (1) Operation control function by wireless remote control Remote control ◆ Operation section FAN SPEED button OPERATION MODE select button Each time the button is pressed, the fan Each time the button is pressed, the speed changes.

  • Page 41: Unit On/Off Button

    '20 • DXK-T-321 (2) Unit ON/OFF button When the wireless remote control batteries become weak, or if the wireless remote control is lost or malfunctioning, this button may be used to turn the unit on and off. (a) Operation Push the button once to place the unit in the automatic mode. Push it once more to turn the unit off. (b) Details of operation The unit will go into the automatic mode in which it automatically determines, from room temperature (as detected by sensor), whether to go into the COOL, DRY or Heat modes.

  • Page 42: High Power Operation

    '20 • DXK-T-321 (5) High power operation Pressing the HI POWER/ECONO button intensifies the operating power and initiates powerful cooling and heating operation for 15 minutes continuously. The wireless remote control displays HIGH POWER mark and the FAN SPEED display disappears. (a) During the HIGH POWER operation, the room temperature is not controlled.

  • Page 43: Timer Operation

    Deviation between the room temperature setting correction temperature and the suction air temperature is calculated in accordance with the fuzzy rule, and used for control of the air capacity and the compressor speed. Model DXK09Z6-W DXK12Z6-W DXK15, 18Z6-W Fan speed 20 - 115rps...

  • Page 44: Outline Of Heating Operation

    (9) Outline of heating operation (a) Operation of major functional components in heating mode (a) Operation of major functional components in heating mode Heating Heating Thermostat ON Thermostat OFF Failure '20 • DXK-T-321 Thermostat ON Thermostat OFF Failure Compressor Compressor ON(HOT KEEP)* Indoor fan motor Indoor fan motor...

  • Page 45: Outline Of Cooling Operation

    (i) Fuzzy operation During the fuzzy operation, the air flow and the compressor speed are controlled by calculating the difference between the room temperature setting correction temperature and the suction air temperature. Model DXK09Z6-W DXK12Z6-W DXK15Z6-W DXK18Z6-W Fan speed 15-74rps...

  • Page 46: Protection Control Function

    When the following conditions have been satisfied 1) Humidity is 78% or higher. (ii) Contents of operation Maximum compressor speed 68 rps DXK09Z6-W 73 rps DXK12Z6-W 87 rps DXK15Z6-W 87 rps DXK18Z6-W (iii) Reset condition When either of the following condition is satisfied 1) Humidity is 73% or less.
  • Page 47 '09•SRK-DB-087D '20 • DXK-T-321 (c) Frost prevention control (i) Operating conditions compressor speed (ii) Detail of anti-frost operation Lower limit Indoor heat exchanger temperature 5°C or lower 2.5°C or lower speed Item 22rps (DXK15, 18 : 23 rps) Lower limit of compressor speed 0 rps Indoor fan Indoor heat exchanger...

  • Page 48: Reset Conditions

    '20 • DXK-T-321 Notes (1) When the outdoor heat exchanger temperature is in the range of B-C ºC, the speed is reduced by 8 rps at each 20 seconds. (2) When the temperature is C ºC or higher, the compressor is stopped. (3) When the outdoor heat exchanger temperature is in the range of A-B ºC, if the compressor speed is been maintained and the operation has continued for more than 20 seconds at the same speed, it returns to the normal cooling operation.
  • Page 49 After lapse of 10 sec. or over 4rps 8rps lower limit After lapse of 10 sec. or over speed 30(35) rps 0rps '20 • DXK-T-321 Indoor heat exchanger temperature(°C) speed Temperature list ● Temperature list Models DXK09.12 Models DXK09, 12 Unit : ºC RPSmin <...
  • Page 50 Normal operation '20 • DXK-T-321 Outdoor air temperature(°C) Reset conditions: ( i ) Heating low outdoor temperature protective control (i) Protective control I 1)  Operating conditions   lower 2 (-8) 2)   Detail of operation    changed as shown in the figure below. Models DXK09,12 Models DXK15,18 Lower limit 45(55) rps...
  • Page 51 '20 • DXK-T-321 2) If the temperature of 110ºC is detected by the sensor on the discharge pipe, then the compressor will stop immediately. When the discharge pipe temperature drops and 3 minutes has elapsed, the unit starts again within 1 hour but there is no start at the third time.

  • Page 52: Operating Conditions

    (q ) Outdoor fan motor protection '20 • DXK-T-321 ( r ) Outdoor fan control at low outdoor temperature Cooling 1) Operating conditions 2) Detail of operation Outdoor fan Outdoor temperature > 10˚C Outdoor temperature < = 10˚C 3) Reset conditions (ii) Heating 1) Operating conditions...
  • Page 53 Values in ( ) are for the model DXK12. 3) Reset conditions '20 • DXK-T-321 (models DXK15, 18 : 2 (s ) Refrigeration cycle system protection (i) Starting conditions When 5 minutes have elapsed after the compressor ON or the completion of the defrost operation Other than the defrost operation 3) When, after satisfying the conditions of 1) and 2) above, the compressor speed, indoor air temperature (Th1) and indoor heat exchanger temperature (Th2) have satisfied the conditions in the following table for 10 (DXK15, 18 : 5) minutes:...

  • Page 54: Maintenance Data

    '20 • DXK-T-321 10. MAINTENANCE DATA (1) Cautions (a) If you are disassembling and checking an air-conditioner, be sure to turn off the power before beginning. When working on indoor units, let the unit sit for about 1 minute after turning off the power before you begin work. When working on an out- door unit, there may be an electrical charge applied to the main circuit (electrolytic condenser), so begin work only after discharging this electrical charge (to DC 10 V or lower).

  • Page 55: Troubleshooting Procedure (If The Air-Conditioner Runs)

    '20 • DXK-T-321 (4) Troubleshooting procedure (If the air-conditioner runs) Confirm the contents of the customer complaint. The cause of the trouble can be specifically identified. Check the self-diagnosis display. Eliminate the cause of the trouble and perform an operation check. See page 55.

  • Page 56: Self-Diagnosis Table

    '20 • DXK-T-321 (5) Self-diagnosis table When this air-conditioner performs an emergency stop, the reason why the emergency stop occurred is displayed by the flash- ing of display lights. If the air-conditioner is operated using the wireless remote control 3 minutes or more after the emergen- cy stop, the trouble display stops and the air-conditioner resumes operation.

  • Page 57: Service Mode (Trouble Mode Access Function)

    '20 • DXK-T-321 (6) Service mode (Trouble mode access function) This air-conditioner is capable of recording error displays and protective stops (service data) which have occurred in the past. If self-diagnosis displays cannot be confirmed, it is possible to get a grasp of the conditions at the time trouble oc- curred by checking these service data.

  • Page 58: Temperature Setting

    '20 • DXK-T-321 *3: To count the number of flashes in the service mode, count the number of flashes after the light lights up for 1.5 second initially (start signal). (The time that the light lights up for 1.5 second (start signal) is not counted in the number of flashes.) •...

  • Page 59: Displayed Data

    '20 • DXK-T-321 ② Stop data Remote control setting Displayed data Operation Fan speed Temperature switching switching setting 21ºC Displays the reason for the stop (stop code) the previous time when the air-conditioner was stopped by protective stop control. 22ºC Displays the reason for the stop (stop code) 2 times previous when the air-conditioner was stopped by protective stop control.
  • Page 60 '09•SRK-DB-087D '20 • DXK-T-321 (c) Error code, stop code table Number of flashes when in service mode Stop coad Error Auto TIMER Error content Cause Occurrence conditions display recovery light Error coad light (10's digit) (1's digit) Normal Power source is faulty. Can not receive signals for 35 When 35 seconds passes without 5 time...
  • Page 61 '20 • DXK-T-321 Notes (1) The number of flashes when in the service mode do not include the 1.5 second period when the lights light up at first (start signal). (See the ex- ample shown below.) • In the case of current cut (example: stop code “42”) The RUN light (10’s digit) flashes 4 times and the TIMER light (1’s digit) flashes 2 times.

  • Page 62: Buzzer Sound

    '20 • DXK-T-321 (e) Room temperature sensor, indoor heat exchanger temperature sensor, outdoor air temperature sen- sor, outdoor heat exchanger temperature sensor table Unit: ºC TIMER light (1’s digit) RUN light (10’s digit) Buzzer sound (sounds for 0.1 second) (does not sound) * If no data are recorded (error code is normal), the display for each sensor becomes as shown below.
  • Page 63 '20 • DXK-T-321 (f) Discharge pipe temperature senson table Unit: ºC TIMER light (1’s digit) RUN light (10’s digit) Buzzer sound (sounds for 0.1 second) (does not sound) * If no data are recorded (error code is normal), the display for sensor becomes as shown below. Sensor value displayed when the error code is normal Sensor name -64ºC...
  • Page 64 '20 • DXK-T-321 Service data record form Model Customer Date of investigation Machine name Content of complaint Display results Remote control settings Display content Content of displayed data Temperature setting Operation switching Fan speed switching Buzzer (Yes/No.) RUN light (Times) TIMER light (Times) Error code on previous occasion Cooling Room temperature sensor temperature on previous occasion...

  • Page 65: Inspection Procedures Corresponding To Detail Of Trouble

    '20 • DXK-T-321 (7) Inspection procedures corresponding to detail of trouble Sensor error Broken sensor wire, connector poor connection Sensor temperature characteristics (Room Discharge pipe temperature sensor characteristics temperature, indoor heat exchanger temperature, outdoor heat exchanger temperature, outdoor air temperature) Temperature (˚C) Temperature (˚C) Indoor fan motor error Defective fan motor, connector poor...

  • Page 66: Current Cut

    '09•SRK-DB-087D '20 • DXK-T-321 Current cut Compressor lock, Compressor wiring short-circuit, Compressor output is open phase, Outdoor unit PCB is faulty, Service valve is closed, EEV is faulty, Compressor faulty. unit ＊   unit ＊ unit Check resistance between terminals . DXC09, 12 : 4.428Ω...
  • Page 67 '09•SRK-DB-087D '20 • DXK-T-321 Over heat of compressor Gas shortage, defective discharge pipe temperature sensor Is discharge pipe temperature. sensor temperature sensor unit Error of signal transmission Wiring error including power cable, defective indoor/ outdoor unit PCB ② ③ unit ②...

  • Page 68: Outdoor Fan Motor Error

    '09•SRK-DB-087D '20 • DXK-T-321 Trouble of outdoor unit Insufficient refregerant amount, Faulty power transistor, Broken compressor wire Service valve close, Defective EEV, Defective outdoor unit PCB source source source source unit ◆  unit (1)      operation   Notes (1) unit Check resistance between terminals, see page 65.

  • Page 69: Rotor Lock

    '20 • DXK-T-321 Rotor lock Defective compressor, defective outdoor unit PCB unit Check resistance between terminals. See page 65. (8) Phenomenon observed after short-circuit, wire breakage on sensor (a) Indoor unit Phenomenon Operation Sensor mode Short-circuit Disconnected wire Cooling Room temperature sensor Heating Cooling...
  • Page 70 Cooling Heat exchanger temperature sensor operation Defrost operation is performed for 10 minutes at approx. 35 (model LMC12:45) minutes. Heating Cooling Ourdoor air '20 • DXK-T-321 temperature sensor operation Defrost operation is performed for 10 minutes at approx. 35 (model LMC12:45) minutes. Heating Discharge pipe All modes...

  • Page 71: How To Make Sure Of Wireless Remote Control

    '20 • DXK-T-321 (c) Power transistor inspection procedure [Use a tester with a needle indicator for the inspection. (Do not use a digital tester. Check in the AC 300 volt range.)] (1) If there is a self-diagnosis display, inspect the compressor system (burns, wiring mistakes, etc.) If no problems are found, check the output of the power transistor.

  • Page 72: Outdoor Unit Inspection Points

    '20 • DXK-T-321 (11) Outdoor unit inspection points Models DXC09Z6-W, 12Z6-W...
  • Page 73 '20 • DXK-T-321 Models DXC15Z6-W, 18Z6-W...
  • Page 74 '20 • DXK-T-321 (a) Inspection of electronic expansion valve Electronic expansion valve operates for approx. 10 seconds after the power on, in order to determine its aperture. Check the operating sound and voltage during the period of time. (Voltage cannot be checked during operation in which only the aperture change occurs.) (i) If it is heard the sound of operating electronic expansion valve, it is almost normal.

  • Page 75: Technical Information

    '20 • DXK-T-321 11. TECHNICAL INFORMATION Model DXK09Z6-W Information to identify the model(s) to which the information relates to: If function includes heating: Indicate the heating season the Indoor unit model name DXK09Z6-W information relates to. Indicated values should relate to one DXC09Z6-W Outdoor unit model name heating season at a time.
  • Page 76 '20 • DXK-T-321 Model DXK12Z6-W Information to identify the model(s) to which the information relates to: If function includes heating: Indicate the heating season the Indoor unit model name DXK12Z6-W information relates to. Indicated values should relate to one Outdoor unit model name DXC12Z6-W heating season at a time.
  • Page 77 '20 • DXK-T-321 Model DXK15Z6-W Information to identify the model(s) to which the information relates to: If function includes heating: Indicate the heating season the Indoor unit model name DXK15Z6-W information relates to. Indicated values should relate to one Outdoor unit model name DXC15Z6-W heating season at a time.
  • Page 78 '20 • DXK-T-321 Model DXK18Z6-W Information to identify the model(s) to which the information relates to: If function includes heating: Indicate the heating season the Indoor unit model name DXK18Z6-W information relates to. Indicated values should relate to one Outdoor unit model name DXC18Z6-W heating season at a time.
  • Page 79 Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice. Copyright MITSUBISHI HEAVY INDUSTRIES THERMAL SYSTEMS, LTD. Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice.
