User Manual
DXC220
USB carbon dioxide (CO
Model name
USB-DXC220
USB-DXC220t-S
USB-DXC220t-S1
USB-DXC220t-S6
USB-DXC220t-S-CAL
USB-DXC220t-S1-CAL
USB-DXC220t-S6-CAL
VCP-DXC220
VCP-DXC220t-S
VCP-DXC220t-S1
VCP-DXC220t-S6
VCP-DXC220t-S-CAL
VCP-DXC220t-S1-CAL
VCP-DXC220t-S6-CAL
HS code: 9027.10.20.00
) sensor, 20%
2
Part number
Description
USB Water resistant (WR) CO2 20% for harsh environments, without
601028
probe
USB WR CO2 sensor 20%, with temperature and relative humidity
601029
probe (TRH), 12 cm
601096
USB WR CO2 sensor 20%, with TRH probe, 100 cm
601098
USB WR CO2 sensor 20%, with TRH probe, 180 cm
608029
USB WR CO2 sensor 20%, with calibratable TRH probe, 12 cm
608096
USB WR CO2 sensor 20%, with calibratable TRH probe, 100 cm
608098
USB WR CO2 sensor 20%, with calibratable TRH probe, 180 cm
603028
USB WR CO2 sensor 20%, with VCP mode
603029
USB WR CO2 sensor 20%, with TRH probe, 12 cm, with VCP mode
603096
USB WR CO2 sensor 20%, with TRH probe, 100 cm, with VCP mode
603098
USB WR CO2 sensor 20%, with TRH probe, 180 cm, with VCP mode
USB WR CO2 sensor 20%, with calibratable TRH probe, 12 cm, with
605029
VCP mode
USB WR CO2 sensor 20%, with calibratable TRH probe, 100 cm, with
605096
VCP mode
USB WR CO2 sensor 20%, with calibratable TRH probe, 180 cm, with
605098
VCP mode
Advertisement
Table of Contents
Related Manuals for Dracal Technologies DXC220
Summary of Contents for Dracal Technologies DXC220
- Page 1 User Manual DXC220 USB carbon dioxide (CO ) sensor, 20% Model name Part number Description USB Water resistant (WR) CO2 20% for harsh environments, without USB-DXC220 601028 probe USB WR CO2 sensor 20%, with temperature and relative humidity USB-DXC220t-S 601029...
-
Page 2: Table Of Contents
6 Installation and Setup 6 Usage Guidelines and Applications 9 Care, Storage, and Recalibration 9 Troubleshooting Guide and Support 10 Return Process and Warranty Information 10 Accessories and Peripherals 10 Disassembly and Environmental Considerations 11 Document Revision History Dracal Technologies Inc. -
Page 3: Compliance Certification
CE Marking: No RoHS3 Compliance: No REACH Compliance: No Technical Documentation Dracal Technologies holds the technical documentation required by the relevant directives at the following address: compliance@dracal.com. It is available upon request to the relevant authorities. Signed for and on behalf of: ... -
Page 4: Overview
The DXC Series measures the level of carbon dioxide, either in a room or in any environment. The DXC220 is made for harsh environment, where there is up to 20% CO2, higher temperature and humidity. -
Page 5: Product Overview And Specifications
Product Overview and Specifications Product Overview The DXC220 is a USB-connected carbon dioxide (CO2) gas sensor designed for monitoring and data acquisition applications. It incorporates a state-of-the- art non-dispersive infrared (NDIR) CO2 sensor, delivering exceptional accuracy, performance, and stability. The DXC220 automatically compensates CO2 readings for ambient temperature variations, utilizing its built-in precision temperature sensor. -
Page 6: Safety Guidelines
Connect an instrument. Launch DracalView. Verify the instrument appears in the Sources tab. Modify units and decimals in the Configuration tab (Optional). Customize the names of channels to record in the Sources tab (Optional). Visualize data on GraphView. Dracal Technologies Inc. - Page 7 Please refer to the DXC220 page for the complete guide, specifically the “Software & Documentation” tab. Of note, to log data with DracalView, these are the remaining main steps of the Getting Started guide: Initiate the logging task in the Logging tab.
- Page 8 Please note that under Windows, once an instrument is converted to VCP, it is not recognizable by DracalView and the command-line tools. For additional information, please click the relevant link in the Software & Documentation section of the DXC220 page. Calibration “-CAL” suffix: If present, the product is equipped with a 3-point user-calibration mechanism.
-
Page 9: Care, Storage, And Recalibration
Care, Storage, and Recalibration Care Use within the specifications available in the DXC220 datasheet. NOTE: Note that this product is not waterproof and requires protection if con- tact with water is possible. Storage Store within the housing temperature and humidity ranges specified in the DXC220 datasheet. -
Page 10: Return Process And Warranty Information
In most cases, there will be an easy solution. In the rare event of a faulty instrument under warranty, Dracal Technologies will proceed to a replacement upon evaluating the situation. The procedure will be explained through email once the customer advises support@dracal.com. -
Page 11: Document Revision History
Minimize Energy Consumption: Power down or disconnect the USB sensor when not in use to minimize energy consumption. Document Revision History Version 1.0 2024-02-08 Creation of the User Manual. DXC220 – USB carbon dioxide (CO2) sensor, 20%... - Page 12 +1 450.812.8612 Dracal Technologies Inc. A204 - 7900 Taschereau Blvd Brossard (Quebec) J4X 1C2 Canada...
