Model OT-PLC302C-RS2
Power Line Ethernet Extender
OT-PLC302C-RS2 Powerline Ethernet Extender is a high-speed Ethernet signal
transmission device. It can transmit power + Ethernet + RS232 serial data signals
via 2-wire power line up to 600m, maximum physical rate up to 500Mbps.
This device contains the Transmitter unit and the Receiver unit. There is the built-in noise reduction isolation transformer
and isolation frequency crosstalk function. It transmits multiple signals over one 2-wire cable, used for various middle and
short distance Ethernet signal transmission.
IP Video Surveillance
Network Smart Home
Elevator IP Surveillance
Intelligent Network Industry
Page 1 of 6
Advertisement
Related Manuals for Ourten OT-PLC302C-RS2
Summary of Contents for Ourten OT-PLC302C-RS2
- Page 1 Model OT-PLC302C-RS2 Power Line Ethernet Extender OT-PLC302C-RS2 Powerline Ethernet Extender is a high-speed Ethernet signal transmission device. It can transmit power + Ethernet + RS232 serial data signals via 2-wire power line up to 600m, maximum physical rate up to 500Mbps.
- Page 2 ◆ Max transmission distance can reach 600m (RVS 2×1mm2) ◆ Max physical bandwidth can reach 500Mbps ◆ Support power over one cable technology (110 / 220VAC) ◆ Support RS232 serial data transmission ◆ Built-in ESD protection circuit, effectively prevent electrostatic damage ◆...
- Page 3 Category Description Available Voltage Range 100～240VAC ≤5W / PC Power Consumption Power Power Output Transmitter Unit 100～240VAC ＜10A 220V Output Current ＜1A 12V Output Current Standard Compliance IEEE1901, IEEE802.3 Dial the switch to adjust, support 38400, RS232 Port Rate 56000, 57600,115200 Transmission / Rate Up Down Agreement CSMA/CA...
- Page 4 Transmitter (Slave) Step Installation Instruction Step Installation Instruction Network equipment is connected to RJ45 port of Connect front-end serial data to RS232 terminal transmitter unit (1) 220V power output/input L and N terminal (2) 12VDC power output (10) Grounding terminal of power cable (3) Dial switch of rate setup (11) Connect terminal transmission 220V power line L ①...
- Page 5 RS232 serial cable according to the actual connection situation between the two devices. When you use OT-PLC302C-RS2, please follow the below tips as a reference, in order to reduce the fault in the process of using and the inspection work.
- Page 6 Attentions: Specifications are subject to change without notice. Thank you for choosing us. For more details, www.ourten.com please visit our website: Shaoxing Ourten Electronics Co., Ltd. 3rd Floor # 7, No. 1732 Yanhua industrial park, West Renmin Road, Shangyu, Zhejiang, China Tel: +86-21-5888 9980 (+86-575-8213 7256) Fax: +86-575-8212 7256 www.ourten.com...
