Model OT-PLC302C-RS4
Power Line Ethernet Extender
OT-PLC302C-RS4 Power Line Ethernet Extender is a high-speed Ethernet signal
transmission device. It can transmit power + Ethernet + RS485 data signals via 2-wire
power line up to 600m, maximum physical rate up to 500Mbps.
This device contains the Transmitter unit and the Receiver unit. There is the built-in noise reduction isolation transformer
and isolation frequency crosstalk function. It transmits multiple signals over one 2-wire cable, used for various middle and
short distance Ethernet signal transmission.
IP Video Surveillance
Network Smart Home
Elevator IP Surveillance
Intelligent Network Industry
Page 1 of 6
Advertisement
Related Manuals for Ourten OT-PLC302C-RS4
Summary of Contents for Ourten OT-PLC302C-RS4
- Page 1 Model OT-PLC302C-RS4 Power Line Ethernet Extender OT-PLC302C-RS4 Power Line Ethernet Extender is a high-speed Ethernet signal transmission device. It can transmit power + Ethernet + RS485 data signals via 2-wire power line up to 600m, maximum physical rate up to 500Mbps.
- Page 2 ◆ Max transmission distance can reach 600m (RVS 2×1mm2) ◆ Max physical bandwidth can reach 500Mbps ◆ Support power over one cable technology (110 / 220VAC) ◆ Support RS485 data transmission ◆ Built-in ESD protection circuit, effectively prevent electrostatic damage ◆...
- Page 3 Category Description Available Voltage Range 100～240VAC ≤5W / PC Power Consumption Power Power Output Transmitter Unit 100～240VAC ＜10A 220V Output Current ＜1A 12V Output Current Standard Compliance IEEE1901, IEEE802.3 Dial the switch to adjust, support 38400, RS485 Port Rate 56000, 57600,115200 Transmission / Rate Up Down Agreement CSMA/CA...
- Page 4 Transmitter (Slave) Step Installation Instruction Step Installation Instruction Network equipment is connected to RJ45 port of Reserved RS232 terminal (9) transmitter unit (1) 220V power output/input L and N terminal (2) 12VDC power output(10) Grounding terminal of power cable (3) Dial switch of rate setup (11) Connect terminal transmission 220V power line L ①...
- Page 5 56000 38400 When you use OT-PLC302C-RS4, please follow the below tips as a reference, in order to reduce the fault in the process of using and the inspection work. 1. Each transmission unit contains one transmitter unit and one receiver unit, when installation, please install receiver unit at the side of the power supply cabinet, and install transmitter unit at the side of loading equipment.
- Page 6 Attentions: Specifications are subject to change without notice. Thank you for choosing us. For more details, www.ourten.com please visit our website: Shaoxing Ourten Electronics Co., Ltd. 3rd Floor # 7, No. 1732 Yanhua industrial park, West Renmin Road, Shangyu, Zhejiang, China Tel: +86-21-5888 9980 (+86-575-8213 7256) Fax: +86-575-8212 7256 www.ourten.com...
