  • Page 1 Ross Video Limited TSI-100 Transport Stream Identifier User Manual Product Name: TSI-100...
  • Page 2 The information contained in this User Manual is subject to change without notice or obligation. Copyright © 2010 Ross Video Limited. All rights reserved. Contents of this publication may not be reproduced in any form without the written permission of Ross Video Limited. Reproduction or reverse engineering of copyrighted software is prohibited. Notice The material in this manual is furnished for informational use only.
  • Page 3: Symbol Meanings

    Important Regulatory and Safety Notices Before using this product and any associated equipment, refer to the “Important Safety Instructions” listed below so as to avoid personnel injury and to prevent product damage. Products may require specific equipment, and/or that installation procedures be carried out to satisfy certain regulatory compliance requirements.
  • Page 4 Operation of this equipment in a residential area is likely to cause harmful interference in which case users will be required to correct the interference at their own expense. Changes or modifications to this equipment not expressly approved by Ross Video Limited could void the user’s authority to operate this equipment.
  • Page 5: Environmental Information

    Environmental Information The TSI-100 complies with the European Union's RoHS Directive. This stands for "the restriction of the use of certain hazardous substances in electrical and electronic equipment". This Directive bans the placing on the EU market of new electrical and electronic equipment containing more than agreed levels of lead, cadmium, mercury, hexavalent chromium, polybrominated biphenyl (PBB) and polybrominated diphenyl ether (PBDE) flame retardants.
  • Page 7: Table Of Contents

    Contents Introduction     In This Chapter ........................1-1   A Word of Thanks ....................1-1   Overview ........................1-2   Features ........................1-2   Functional Block Diagrams ..................1-3   Documentation Terms ....................1-4   Frame and Rear Module Compatibility ..............1-4  ...
  • Page 8 Using the On-screen Menus     In This Chapter ........................6-1   Layout and Navigation .................... 6-2   Using the Menus ...................... 6-3 Specifications     In This Chapter ........................7-1 Service Information     In This Chapter ........................8-1  ...
  • Page 9: Introduction

    Documentation Terms A Word of Thanks Congratulations on choosing the openGear TSI-100 Transport Stream Identifier. The TSI-100 is part of a full line of Digital Products within the openGear Terminal Equipment family of products. You will be pleased at how easily your new TSI-100 fits into your overall working environment. Equally pleasing is the product quality, reliability and functionality.
  • Page 10: Overview

    Fits openGear DFR-8300 series frames. • Compatible with the openGear frame’s SNMP option, allowing monitoring with third-party SNMP software systems. For more information, contact Ross Technical Support. • On screen display for setup so that no LAN or PC is required.
  • Page 11: Functional Block Diagrams

    Functional Block Diagrams Figure 1. Simplified Block Diagrams of TSI-100 Functions Introduction • 1-3 TSI-100 User Manual (Iss. 02)
  • Page 12: Documentation Terms

    Documentation Terms The following terms are used throughout this guide: • “Frame” refers to the frame that houses the TSI-100 card. • “Operator” and “User” refer to the person who uses the TSI-100. • “Board” and “Card” refer to the TSI-100 card itself, including all components and switches. •...
  • Page 13: Quick Start

    2. Install DashBoard on a computer connected to the LAN. The DashBoard Control System™ software and user manual are available from the Ross Video website. 3. Install a rear modules in the frame, as described in the section “Rear Module Installation” of this manual.
  • Page 14 1-6 • Introduction TSI-100 User Manual (Iss. 02)
  • Page 15: Installation And Setup

    Unpack each TSI-100 you received from the shipping container, and check the contents against the packing list to ensure that all items are included. If any items are missing or damaged, contact your sales representative or Ross Video Limited directly. Installation and Setup • 2-1...
  • Page 16: Rear Module Installation

    Rear Module Installation The TSI-100 requires a Ross Video Rear I/O Module with GPIO jacks. You will need to install the I/O module in your openGear frame before you can install the TSI-100 in the frame, or connect cables to the slot you have chosen for the TSI-100.
  • Page 17: Board Installation

    Note — Video bypass is available with the ONG-MDL-R01,R21 and R23 rear modules. A monitor output is available with the ONG-MDL-R02 and R22 modules. Rear modules ONG-MDL-R02 and R22 have isolated GPIO outputs and ONG-MDL-R01,R21 and R23 produce 0-3.3V logic levels. Board Installation Use the following procedure to install the TSI-100 in an openGear distribution frame: Notice —...
  • Page 18: Cable Connections

    Cable Connections This section provides information for connecting cables to the installed rear modules on the frame backplane. Connect the input and output cables according to the following diagram. It is not necessary to terminate unused outputs. Note that the BNCs are numbered 1-10 by convention, even though some may not be installed.
  • Page 19 BNC 1 ASI Input (May be labelled VID IN or SDI IN) This jack accepts an ASI video signal. The TSI-100 requires this input in all cases. For convenience, it routes a reclocked copy of this signal to BNC3. The input signal is internally terminated in 75 ohms when the TSI-100 is installed.
  • Page 20 2-6 • Installation and Setup TSI-100 User Manual (Iss. 02)
  • Page 21: User Controls

    User Controls In This Chapter This chapter contains a description of the TSI-100 user controls: • Switches • LEDs User Controls • 3-1 TSI-100 User Manual (Iss. 02)
  • Page 22: Bypass Switch

    User Controls Figure 4 shows the front edge of the TSI-100. Following the illustration are descriptions of the controls and indicators identified here. Figure 4. Card-edge User Controls Bypass Switch If the TSI-100 is installed in a rear module such as the ONG-MDL-R01 that has a bypass relay, this two-position pushbutton can be used to control the relay.
  • Page 23: Leds

    LEDs The front-edge of the card features LEDs that display the status of the input signals. Descriptions are provided in the following table: Table 1. Selection and Status LED Descriptions Color Location Display and Description When off, there is no power. When lit and green the card is running with valid input.
  • Page 24 3-4 • User Controls TSI-100 User Manual (Iss. 02)
  • Page 25: Dashboard And Tsi-100 Status

    In This Chapter This chapter provides a detailed explanation of the functions available when using DashBoard to monitor and control the TSI-100. The program is available for download from the Ross Video website. The following topics are discussed in this chapter: •...
  • Page 26: Layout And Navigation

    Layout and Navigation This section focuses on the use of the DashBoard program to control and monitor a TSI-100. For a more complete description of DashBoard and its capabilities, please refer to the documentation supplied with the program. Selecting a TSI-100 Module Figure 5 shows a typical DashBoard screen.
  • Page 27: Product Status

    Product Status The left side of this figure shows product information that is useful in discussing the operation of the module with Ross Video’s Technical Support staff. Figure 5. Main TSI-100 DashBoard Screen, showing Product Status and Settings DashBoard and TSI-100 Status • 4-3...
  • Page 28: Gpio Status

    GPIO Status Figure 6 shows the status of the GPIO outputs. The TSI-100 controls 2 GPIOs: output GPIO1 it active high (GPIO1 is high when the TSID does not match or no transport stream is present) and GPIO2 is active low. Figure 6.
  • Page 29: Setting Up The Tsi-100

    Setting Up the TSI-100 In This Chapter This chapter explains how to use the user interface to set up the TSI-100. This discussion is based on the use of DashBoard through a network connection, however most of these functions are also available through the local Heads-up Display.
  • Page 30: Settings

    Settings Figure 8 shows the screen that is displayed by clicking the Settings tab. Figure 8. Settings Menu The Card ID field allows you to assign a unique name to a TSI-100 card. This is especially useful if you have more than one TSI-100 in a frame.
  • Page 31: Tsid Setup

    TSID Setup Figure 9 shows the screen that is displayed by clicking the TSID Setup tab. Figure 9. TSID Setup The TSID Value is a 4 digit hex value the user sets. If the incoming signal contains a TSID that doesn’t match this value the GPIOs become active.
  • Page 32: Alarms

    Alarms Figure 10 shows the screen that is displayed by clicking the Alarms tab. Figure 10. Alarm Setup The TSI-100 has several alarms that can affect the overall status of the card. If you wish to disable an individual alarm uncheck the corresponding checkbox. A Note on GPIOs The TSI-100 has two active GPIOs.
  • Page 33: Using The On-Screen Menus

    Using the On-screen Menus In This Chapter This chapter explains how to use the Menu functions available on the Heads-Up Display of the TSI- 100. It does not describe each available menu; for information on these, see the chapters that describe the menus available through DashBoard.
  • Page 34: Layout And Navigation

    Layout and Navigation The Menu Switch is a five-direction square finger joystick located near the front edge of the TSI-100 card. With the card edge facing you, use the following menu switch actions to navigate the menu and configure parameters: •...
  • Page 35: Using The Menus

    Figure 12. Transport Stream Identifier Using the Menus The available screens that can be selected are: Status Setup menus Exit (left column) (centre column) (right column) Product TSID Setup Exit Alarms Alarms GPIO Output Setting The use of the menus to change settings will be illustrated by the following example: 1.
  • Page 36 9. You can repeat steps 7-8 to select all 4 digits for the TSID. 10. Move down to “Apply” and press the Menu Switch In. The TSID is now set. 11. To switch to a different menu, press the Menu Switch Up or Down repeatedly until the selection bar moves to the title (Setup Encoding).
  • Page 37: Specifications

    Specifications In This Chapter This chapter includes the technical specifications for the TSI-100. Note that specifications are subject to change without notice. Specifications • 7-1 TSI-100 User Manual (Iss. 02)
  • Page 38 Category Parameter Specification Number Of Inputs 1 input Input Signal Standard DVB-ASI (EN 50083-9) Accommodated 75Ω terminating in Active mode Serial Digital Impedance Video Inputs Loop-through to Video Output in Bypass mode, via the ONG-MDL-R01, R21 or R23 rear module. Equalization Over 100 m of Belden 1694A cable Return Loss...
  • Page 39: Service Information

    Service Information In This Chapter This chapter contains the following sections: • Troubleshooting Checklist • Power LED Conditions • Bootload Sequence • Warranty and Repair Policy Troubleshooting Checklist Routine maintenance to this openGear product is not required. In the event of problems with your TSI-100, the following basic troubleshooting checklist may help identify the source of the problem.
  • Page 40: Power Led Conditions

    This User Manual provides all pertinent information for the safe installation and operation of your TSI-100. Ross Video policy dictates that all repairs to the TSI-100 are to be conducted only by an authorized Ross Video Limited factory representative. Therefore, any unauthorized attempt to repair this product, by anyone other than an authorized Ross Video Limited factory representative, will automatically void the warranty.
  • Page 41: In Case Of Problems

    Ross Video Limited will be shipped collect. The Ross Video Technical Support Department will continue to provide advice on any product manufactured by Ross Video Limited, beyond the warranty period without charge, for the life of the equipment. Service Information • 8-3...
  • Page 42 Notes: 8-4 • Service Information TSI-100 User Manual (Iss. 02)
  • Page 43 Notes: Service Information • 8-5 TSI-100 User Manual (Iss. 02)
  • Page 44 P.O. Box 880 Ross Video Incorporated Ogdensburg, New York, USA 13669-0880 Visit Us Please visit us at our website for: • Company information • Related products and full product lines • Trade show information • News Ross Part Number: TSI100DR-005-02...
