AG DRONE
Operational Manual
This system utilizes shared connections between tanks and is designed
such that cross contamination between the tanks could occur under
certain circumstances. Care must be taken to ensure the system and
all its liquid pathways are fully and completely flushed of all residual
NOTICE
chemistry prior to changing application formulas.
800.247.1854 • FarmChem.com
1
Advertisement
Related Manuals for FarmChem Ag Drone BatchMate
Summary of Contents for FarmChem Ag Drone BatchMate
- Page 1 Care must be taken to ensure the system and all its liquid pathways are fully and completely flushed of all residual NOTICE chemistry prior to changing application formulas. 800.247.1854 • FarmChem.com...
-
Page 2: Before You Get Started
Introduction The Ag Drone BatchMate is a mixing and delivery system specifically designed for ag drone applications. The system uniquely has two tanks that allows one to be used for active refilling of the drones while the other is utilized to mix another batch of the same chemical composition, ensuring seamless tank change over and continued applications. - Page 3 Next, with the water source valve open on the supply tank, you will open the bleeder valve on the water pump to allow air out and water into the pump. Shut the valve when water starts coming out. FarmChem.com |...
- Page 4 The hose from the unit to the Drone fill area is not included, but components are available from FarmChem.com. Note: When the Drone pump is turned on it will run for a minimum of 15 seconds, even if the switch is shut off.
- Page 5 If this feature is used, either the drone fill line or plumbing branched off of it can be used to fill the tank. Plumbing from the bottom of the tank into the 3-way valve can pull the product directly back to the pump to be distributed to the drone. FarmChem.com |...
- Page 6 Calibrating the Grizzly Included with the system is a stinger that can be connected to the meter for calibration. With all pumps off, release the cam locks at the base of the meter. Connect the stinger and tighten the camlocks. To purge the air from the meter, put the stinger into the 5-gallon calibration container.
- Page 7 Learn more by Scan for the scanning the QR code or by going to FarmChem.com. manual FarmChem.com |...
- Page 8 800.247.1854 • farmchem.com This system utilizes shared connections between tanks and is designed such that cross contamination between the tanks could occur under certain circumstances. Care must be taken to ensure the system and all its liquid pathways are fully and completely flushed of all residual NOTICE chemistry prior to changing application formulas.
