Vixen Air VXK3914C Installation Manual

BEFORE BEGINNING YOUR INSTALLATION
Read through the whole instruction guide before getting started with the installation. Professional installation is
recommended for this product.
CONTENTS
 3/8" NPT Air Line Filter 250 PSI Silver
 1/2" OD Nylon Hose 4 FT
 3/8" NPT Male PTC Fitting for 1/2" OD Hose
 1/4" NPT Male PTC Fitting for 1/2" OD Hose
 3/8" NPT Male to 1/4" NPT Female Thread Reducer
 Hose Cutter
SAFETY INSTRUCTIONS
 Intended for use by adults only.
 Do not use the device for purposes for which it is not intended.
 Always make sure that the air line is in good condition.
 Hose and connection should be inspected to avoid any leakage before use.
 Ensure that your air system has no pressure before starting the installation or draining the filter.
 It is important that all connections and air lines are rated for the required pressure and air flows.
This filter is rated 250 PSI maximum pressure. Do not over pressurize. Over pressuring may cause harm to you and
others.
PAGE 1 of 2
VXK3914C
INSTALLATION GUIDE
