Mean Well RSDH-150-12 Installation Manual

DC-DC converter（Families：RSDH-150、RSDH-300）
 Type：
 Introduction
A DC-DC converter is a device used to convert a DC source from one voltage level to another. Mean Well's DC-DC
converters equipped with internal EMI filter stage that possess the required EMC performance.
DC-DC Converter,Models:RSDH-150-12,RSDH-150-24,RSDH-150-32,RSDH-150-48,RSDH-300-12,RSDH-300-24,RSDH-
300-32 and RSDH-300-48. Internal permanently connected,models' rating as follows:
Model
INPUT RATINGS:
Maximum input voltage(Vdc)
Range of input operating voltage(Vdc)
Max. input current(A)
OUTPUT RATINGS
Nominal output voltage(Vdc)
Maximum continuous output current(A)
Maximum continuous output power(W)
Nominal operation temperature range
Enclosure Rating Type
Model
INPUT RATINGS:
Maximum input voltage(Vdc)
Range of input operating voltage(Vdc)
Max. input current(A)
OUTPUT RATINGS
Nominal output voltage(Vdc)
Maximum continuous output current(A)
Maximum continuous output power(W)
Nominal operation temperature range
Enclosure Rating Type
 Installation
Before commencing any installation or maintenance work, please disconnect your system from the
（1）
utility. Ensure that it cannot be re-connected inadvertently!
For PCB type, at least 5mm insulation distance around the unit should be kept.
（2）
Allow good ventilation for the unit in use to prevent it from overheating. Also, a 10-15 cm clearance
（3）
must be kept when the adjacent device is a heat source.
Mounting orientations other than standard orientation or operate under high ambient temperature
（4）
may increase the internal component temperature and will require a de-rating in output current.
Please refer to the specification sheets to receive the optimum mounting position and information
about the de-rating curve.
（5）Input and Output terminal
Terminal Screw
Series
RSDH-150
RSDH-300
Installation Manual
RSDH-150-12 RSDH-150-24 RSDH-150-32 RSDH-150-48
1500Vdc
250-1500Vdc
0.7A
12V
10A
120
-40~+50℃
RSDH-300-12 RSDH-300-24 RSDH-300-32 RSDH-300-48
1500Vdc
250-1500Vdc
1.2A
12V
20A
240
-40~+50℃
Input
Screw Size Suggested Torque
M3.5 13.8kgf-cm(12lb-inch)
#6 8kgf-cm(6.9lb-inch)
1500Vdc 1500Vdc
250-1500Vdc 250-1500Vdc
0.7A 0.7A
24V 32V
6.2A 4.68A
150 150
-40~+50℃ -40~+50℃
Type 1
1500Vdc 1500Vdc
250-1500Vdc 250-1500Vdc
1.5A 1.5A
24V 32V
12.5A 9.37A
300 300
-40~+50℃ -40~+50℃
Type 1
Screw Size
#6
#6
1500Vdc
250-1500Vdc
0.7A
48V
3.12A
150
-40~+50℃
1500Vdc
250-1500Vdc
1.5A
48V
6.25A
300
-40~+50℃
Output
Suggested Torque
8kgf-cm(6.9lb-inch)
8kgf-cm(6.9lb-inch)
