Perfomance Tool W54294 Owner's Manual

Clear view pistol grip grease gun

Download this manual

CLEAR VIEW PISTOL GRIP

GREASE GUN

PISTOLA PARA GRASA CON EMPUÑADURA

Item Number W54294

OWNER'S MANUAL /

INSTRUCTIVO

SPECIFICATIONS /

CARACTERÍSTICAS

Capacity:................................... Bulk - 16 oz. (473 ml), Cartridge - 14 oz. (414 ml)

Develops up to:..................................................................................... 10,000 PSI

Delivers:....................................................................... 1 oz. / 18 Strokes (29.5 ml)

Hose Type / Length: ............................................................12 in. Flex 1/8 in. NPT

Specifications are subject to change without notice.

WARNING: READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND

WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO MAY

RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL

VOID WARRANTY.

Need help?

Do you have a question about the W54294 and is the answer not in the manual?

Page 1 CLEAR VIEW PISTOL GRIP GREASE GUN PISTOLA PARA GRASA CON EMPUÑADURA Item Number W54294 OWNER'S MANUAL / INSTRUCTIVO SPECIFICATIONS / CARACTERÍSTICAS Capacity:........Bulk - 16 oz. (473 ml), Cartridge - 14 oz. (414 ml) Develops up to:..................10,000 PSI Delivers:............... 1 oz. / 18 Strokes (29.5 ml) Hose Type / Length: ............12 in.
Page 2 GREASE CARTRIDGE LOADING/ PARA LLENAR CARTUCHO DE GRASA NOTE: This is a basic instruction manual which covers various models of grease guns. The illustrations below may not depict exactly your specific gun. 1. Rotating counter clockwise, unscrew Head Cap from gun Barrel. (Fig. 1) NOTA: Este es un manual de instruciones basico que cubre varios modelos de pistolas de grasa.
Page 3 BULK LOADING WITH DISPENSER /RELLENO EN VOLUMEN CON DISPENSADOR NOTE: Used cartridges must be removed prior to bulk loading. 1. Make sure the bulk loading filler valve is compatible with the adapter on the pump. (Figure 5) 2. Attach the filler valve to the adapter by pushing in and rotating slightly. 3.
Page 4 TROUBLE SHOOTING Problem: Possible cause: Solution: Coupler won’t fit or stay on the Grease couplers jaws are The coupler has adjustable jaws. grease fitting ......threaded closed. Twist nose of coupler, this will open and close the 4 internal jaws. When gun is operated grease Either fitting is plugged with Coupler is adjustable, a slight turn...
