- Page 1 User Manual Wall Mount 4...
-
Page 2: Safety Warning
Alcolizer Technician. Thank you for entrusting Alcolizer Technology. This manual includes installation, operation & troubleshooting for your Wall Mount 4 (WM4) device. Please familiarise yourself with the safety warnings and cautions listed throughout the manual. -
Page 3: Table Of Contents
Wiegand USB device Direct network connection USB input device authorisation Coin mechanism authorisation & coin count FACTORY SERVICING & TROUBLESHOOTING Factory servicing & field servicing Troubleshooting Calibration www.alcolizer.com | 1300 789 908 WM4 User Manual V2 - Alcolizer Technology 3... -
Page 4: Specifications & Pre-Testing Notes
• If the test result is above the operational maximum limit, a plus sign (+) after the result will be displayed. www.alcolizer.com | 1300 789 908 WM4 User Manual V2 - Alcolizer Technology 4... -
Page 5: Installation
INSIDE BACK PLATE Mounting Holes SIDES OF WM4 Male Lift Off Hinge Serving data decal Key Lock Mounting Holes Serial No decal Information decal www.alcolizer.com | 1300 789 908 WM4 User Manual V2 - Alcolizer Technology 5... -
Page 6: Mounting Accessories & Installation
Ensure that the device closes to the back plate and that USB cords are situated within the cut out (to ensure the unit closes correctly). • Accessory has now been installed successfully. www.alcolizer.com | 1300 789 908 WM4 User Manual V2 - Alcolizer Technology 6... -
Page 7: Operating Instructions
If the blow is invalid, cease blowing, wait until the Insert Straw and Blow screen is displayed and then provide another sample. www.alcolizer.com | 1300 789 908 WM4 User Manual V2 - Alcolizer Technology 7... -
Page 8: Owner Servicing
Users should not access the machine and attach a keyboard unless specifically requested to by instructions in this manual or verbally when in contact with your Alcolizer Technology technical representative. Access the USB ports by unlocking the WM4 and swinging open. There are four ports located on the main circuit panel. -
Page 9: User Interface
The Keypad can be positioned on the right side of the wall mount by the customer. Ensure that the keypad on the wall is installed next to the Wall Mount 4 unit (within 100mm) in accordance with local and site regulations. -
Page 10: Network Connections
- the Instrument status can also be assessed by viewing the status LEDs on the main circuit board while the unit is on. Only STAT4 and STAT5 LEDs display status. If any other blinking patterns are noticed, contact your authorised Alcolizer service technician on 1300 789 908. STAT4 - Logs Status indicator. -
Page 11: Authorisation & Authorisation Code Entry
Powering the Instrument On Alcolizer Wall mounted instruments (WM4, Centurion Zero Tolerance and Quantum) will turn themselves on once power is applied to the unit. If the unit is unplugged simply plug it in. If the unit is powered but has been gracefully shut down as below, simply press the OFF button. -
Page 12: Custom Text
USB flash drive is inserted if configured to do so. Alternatively, the records can be exported by inserting a USB flash drive and pressing FN4 on the PCBA. Refer to page 8 to see button location. www.alcolizer.com | 1300 789 908 WM4 User Manual V2 - Alcolizer Technology 12... -
Page 13: Networks
The WM4 keypad + camera + cellular model includes a GSM (Global System for Mobile Communications) modem. The customer must provide their own SIM card to Alcolizer Technology at time of ordering. This model does not require changes to the network configuration since it comes set from the factory. -
Page 14: Instrument Status
The Start Time chosen is on the 29th of September 2013, 12 noon. • The Report Interval is Weekly. • The next email will be sent on the 6th of October 2013, 12 noon. www.alcolizer.com | 1300 789 908 WM4 User Manual V2 - Alcolizer Technology 14... -
Page 15: Relays
EPSOM PRINTER SETUP Alcolizer Technology WM4 ONLY supports the following printers - (1) Epson TM-T82III (2) Epson TM-T20 USB model & (3) Epson TM-T82IIIL. To set up the printer unpack & remove any tape used to secure parts for transport, then fit paper roll. -
Page 16: Accessories Available
If authorisation is enabled, then an agent can send authorisation codes to the wall mount on either serial port. The instrument also supports Wiegand based test authorisation, if enabled in production. www.alcolizer.com | 1300 789 908 WM4 User Manual V2 - Alcolizer Technology 16... -
Page 17: Direct Network Connection
The instrument requires servicing after 365 days of use by an authorized Alcolizer Technology service technician. This can be performed on site or the unit can be returned to Alcolizer Technology facilities. NOTE The next service date is defined by the number of days that a WM4 was left ON and performed auto-calibrations (365 in total). -
Page 18: Troubleshooting
If the machine is to be returned to Alcolizer, prepare it for shipment in accordance with the following procedures: • Turn off the instrument and unplug the power cord. Unlock and open the instrument. • Turn the gas off by turning the valve on the gas cylinder.
