Panasonic FZ-VBRG231 Series Operating Instructions Manual

Thank you for purchasing this product for the Panasonic FZ-G2 computer series*
1
* This product cannot be used for other models.
For more details about the attaching this product, please visit the
following website:
https://askpc.panasonic.co.jp/manual/option/w/
Printed in Taiwan
ENGLISH
„ Supplied accessories
Check and identify the supplied accessories. If you do not find the described ac-
cessories, contact your support office.
� Screw ...................................................................... 4 (spare screw included)
� Operating Instructions (this leaflet) .............................................................. 1
„ Specification
Refer to è
Operating Instructions - Reference Manual.
„ Regulatory Information
LED Light
CAUTION
„ The light from the LED is strong and can injure human eyes.
Do not look directly at the LEDs with naked eyes.
Laser Devices
CAUTION!
THIS PRODUCT UTILIZES A CLASS 2 LASER.
USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF PROCE-
DURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARD-
OUS RADIATION EXPOSURE.
DO NOT DISASSEMBLE OR REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
Complies with 21 CFR 1040.10 and 1040.11 except for conformance with
IEC 60825-1 Ed. 3., as described in Laser Notice No. 56, dated May 8, 2019.
Complies with IEC 60825-1:2014, EN 60825-1:2014+A11:2021, GB 7247.1-2012,
JIS C 6802:2014.
The laser is a "Class 2" laser which is indicated on the label for this product.
Class 2 laser readers use a low power, visible light diode. As with any very bright
light source, such as the sun, the user should avoid staring directly into the light
beam. Looking directly at the laser beam for a long time, it may cause damage to
your eyes.
„ Labeling/Marking
Location of aperture
For U.S.A.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must ac-
cept any interference received, including interference that may cause undesired
operation.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equip-
ment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
� Reorient or relocate the receiving antenna.
� Increase the separation between the equipment and receiver.
� Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
� Consult the Panasonic Service Center or an experienced radio/TV technician
for help.
Responsible Party: Panasonic Corporation of North America
Two Riverfront Plaza
Newark, NJ 07102
Support Contact: https://na.panasonic.com/us/support
Operating Instructions
Barcode Reader
FZ-VBRG231
Model No.
DHQX1960ZA/T1
„ Laser radiation information
Beam Divergence
- Vertical angle: 26.5 degrees
- Horizontal angle: 41 degrees
Wavelength: 650 nm
Radiant Power (Max) : 1 mW
Pulse duration: 16.8 ms
Repetition rate: 60 Hz
For Canada
Canadian ICES-003
CAN ICES-003(B)/NMB-003(B)
For Europe
<Only for model with a "CE" mark on the product>
series
1
.
The declaration of conformity is available at https://www.ptc.panasonic.eu
Manufactured by:
Panasonic Connect Co., Ltd.
4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japan
Importer for EU:
Panasonic Connect Europe GmbH
Hagenauer Strasse 43, 65203 Wiesbaden, Germany
Authorised Representative in EU:
HS0624-0
Panasonic Connect Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Disposal of Old Equipment
Only for European Union and countries with recycling systems
For more information about collection and recycling, please contact your local
authority.
Penalties may be applicable for incorrect disposal of this waste, in accordance
with national legislation.
For UK
<Only for model with a "UKCA" mark on the product>
UK Declaration of Conformity (DoC)
"Hereby, Panasonic declares that this product is in compliance with
the relevant statutory requirements."
The declaration of conformity is available at https://www.ptc.panasonic.eu
57-1-E
Panasonic Connect Co., Ltd.
4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japan
Importer for UK:
Panasonic Connect UK, a branch of Panasonic Connect Europe GmbH
Maxis 2, Western Road, Bracknell, Berkshire, RG12 1RT
For India
Information on hazardous constituents as specified in sub-rule1 of rule16 in elec-
trical and electronic equipment.
Declaration of Conformity with the requirements of the E-Waste (Management)
Rules with the sub-rule1 of rule16 limits with respect to Lead, Mercury, Cadmium,
Hexavalent chromium, Polybrominated biphenyls, Polybrominated diphenyl ethers.
The content of hazardous substance with the exemption of the applications listed
in SCHEDULE II of the E-Waste (Management) Rules:
1. Lead (Pb) - not over 0.1% by weight;
2. Cadmium (Cd) - not over 0.01% by weight;
3. Mercury (Hg) - not over 0.1% by weight;
4. Hexavalent chromium (Cr6+) - not over 0.1% by weight;
5. Polybrominated biphenyls (PBBs) - not over 0.1% by weight;
6. Polybrominated diphenyl ethers (PBDEs) - not over 0.1% by weight.
13-1-E
Website:
https://www.panasonic.com/in/corporate/e-waste-management.html
Customer care number ( Toll free ): 080-6984-1333
No.
All electrical and electronic products
1 are required to be handed over only
to the Authorized recycler.
The product should be handed over
2 only to authorized recycler for dis-
posal.
Keep the product in an isolated area,
after it becomes non-functional/
3
unrepairable so as to prevent its ac-
cidental breakage.
Refer to Operating Instructions for
4 handling of end of life products.
Always dispose of products that have
reached end-of life at Panasonic Life
5 Solutions India Authorized Service
Centre.
6-1-M
Declaration of Conformity (DoC)
"Hereby, Panasonic declares that this product is in compliance
with the essential requirements and other relevant provisions
of EU Council Directives."
This symbol on the products, packaging, and/or accompanying
documents means that used electrical and electronic products
must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products,
please take them to applicable collection points in accordance
with your national legislation.
By disposing of them correctly, you will help to save valuable
resources and prevent any potential negative effects on human
health and the environment.
For the purpose of recycling to facilitate effective utilization of
resources, please return this product to a nearby authorized
collection center, registered dismantler of recycler, or Panasonic
service center when disposing of this product.
Please see the Panasonic website for further information on col-
lection centers, etc., or call the customer care toll-free number
below.
Do's & Don'ts
Do's
The product should not be opened
by the user himself/herself, but only
by authorized service personnel.
The product is not meant for re-sale
to any unauthorized agencies/scrap
dealers/kabariwalas.
The product is not meant for mixing
into household waste stream.
Do not keep any replaced spare
part(s) from the product in an ex-
posed area.
Do not donate old electronic items to
anybody.
Do not dispose of your product in
garbage bins along with municipal
waste that ultimately reaches landfill.
7-1-M
18C-2-E
36B-1-E
99D-1-E
Don'ts
