- Page 1 Debris Loader Owner’s manual covers models: LSDL-13GX390 & LSDL-18VGDE 555 Goodrich Rd Bellevue, OH 44811 419-483-9918 419-483-8128 fax www.selbro.com Salesinfo@selbro.com IM-1060...
- Page 2 CONTENTS SPECIFICATIONS____________________________3 INSTRUCTION LABELS_______________________4 SHIPPING CHECKLIST_______________________5 ILLUSTRATED PARTS DIAGRAM_______________6 PARTS LIST________________________________7 ASSEMBLY_________________________________8 SAFETY INSTRUCTIONS - DO NOT DO__________9 SAFETY INSTRUCTIONS - DO_________________10 We would like to thank you for your purchase of our professional grade LandShark 18Hp debris loader. All our products are fabricated and assembled using quality parts and heavy gauge steal materials in our Bellevue, Ohio facility.
-
Page 3: Specifications
Specifications Model Number LSDL-13GX390 LSDL-18VGDE Engine: HP 13 (9.69kW) 18 (13.4kW) Engine Model GX390U1QA2 3564470011F1 Honda Briggs & Stratton Mounting Skid Mount Skid Mount Fuel Type Engine: Fuel Capacity 6.9 qt (6.5L) 9.0 qt (8.52L) Engine: Oil Capacity 1.16 qt (1.1L) 1.75 qt (1.66L) Loader total Weight 244lbs / 537.9kg... - Page 4 INSTRUCTION / SAFETY LABELS AND SYMBOLS The labels shown here have been installed in various locations on the LandShark Debris loader. It is important to maintain these labels in good condition and replace them when necessary. The part numbers are included in the Illustrated parts List. READ IM-1060...
- Page 5 Loose Parts Check List The LandShark Debris Loader is shipped fully assembled except for a few components: Discharge Chute, Nozzle, Floating Collar, Hose Support Collar, Hose Support Boom, Hose Clamps and Miscellaneous Hardware. Loose Hardware Contents Discharge Flap Hose Boom (2) Bridge Clamps #12399 / #12451 Assembly...
- Page 6 Assembly Most of the components should already be assembled for you but in the event they are not, here are the instructions for complete assembly. Attach the handles to the side or top of the base using six 3/8-16 x 1.25” bolts, nuts and washers.
- Page 7 Safety Instructions - DO NOT DO NOT OPERATE THIS UNIT FREESTANDING. IT MUST BE SECURED USING ONE OF THE SPECIFIED MOUNTING OPTIONS. DO NOT operate this equipment with ANY safety features or guards removed. DO NOT run this equipment indoors or in any poorly ventilated area. Refuel outdoors only.
- Page 8 Safety Instructions – DO ALWAYS remove the spark plug when performing any type of maintenance and servicing. ALWAYS check fuel lines and fittings for wear, cracks and leaks. Replace as necessary. ALWAYS keep hands and feet away from moving or rotating parts. ALWAYS store fuel in approved safety containers.
-
Page 9: Parts Illustration
Parts Illustration IM-1060... -
Page 10: Parts List
Parts List Item Qty Part No Part No 18Hp Description 13Hp/Both 12386 12467 Nozzle, Hose 12387 12469 Floating Handle 12388 12471 Support Collar 12411-01 12411-02 Support Chain 12389 12454 Safety Flange, Hose 12391 12453 Safety Plate 12390 12452 Intake Assembly, Housing 12370 Interlock Switch 8”... - Page 11 For questions and technical information, contact your LandShark Team at: 1-800-973-5276 555 Goodrich Rd, Bellevue, Ohio 44811 IM-1060...
