- Page 1 SY-5EHM/5EH5 ™ Super 7 Motherboard Quick Start Guide Tested To Comply With FCC Standards FOR HOME OR OFFICE USE POST CONSUMER 100% RECYCLED PAPER...
- Page 2 Our customers should ensure that their use of our products does not infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or assist others to infringe upon such rights.
- Page 3 SY-5EHM/5EH5 Quick Start Guide Introduction Congratulations on your purchase of the 5EHM/5EH5 Super 7 ™ Motherboard. This Quick Start Guide describes the steps for installing and setting up your new Motherboard. This guide is designed for all users to provide the basic steps of Motherboard setting and operation.
- Page 4 SY-5EHM/5EH5 Quick Start Guide SY-5EHM/5EH5 Motherboard Layout PS/2 Mouse Connector Connector Flash BIOS AT Power Lithium PRT 1 COM 2 Battery FDC37C669Q ATX Power USB1 JP44 COM 1 AGP Slot PCI Slot #3 PCI Slot #2 PCI Slot #1 IDE 1 IDE 2 ISA Slot #3 ETEQ ETEQ...
-
Page 5: Installation
SY-5EHM/5EH5 Quick Start Guide Installation To avoid damage to your Motherboard, follow these simple rules while handling this equipment: Before handling the Motherboard, ground yourself by grasping an unpainted portion of the system's metal chassis. Remove the Motherboard from its anti-static packaging. Hold it by the edges and avoid touching its components. -
Page 6: Step 1. Install The Cpu
SY-5EHM/5EH5 Quick Start Guide Install the Motherboard Follow the steps below in order to perform the installation of your new 5EHM/5EH5 Super 7 ™ Motherboard. Step 1. Install the CPU To mount the Pentium ® processor that you have purchased separately, follow these instructions. - Page 7 SY-5EHM/5EH5 Quick Start Guide Step 2. Set JP30 for CPU Voltage This Motherboard features the Smart Detect CPU Voltage function which is designed to automatically detect the voltage of the CPU. If you install any of the following CPUs, the ®...
- Page 8 SY-5EHM/5EH5 Quick Start Guide Voltage Setting: JP30 Processor Voltage 9-10 11-12 IDT WinChip C6/2-225 close open open open open close 3.52V IDT WinChip 2-266 IDT WinChip C6/2-200 close open open open close open 3.3 V IDT WinChip 2-233 close open open open open...
- Page 9 SY-5EHM/5EH5 Quick Start Guide Frequency Setting: SW1 CPU Bus Processor Multiplier JP9 JP10 Clock Cyrix 6x86 MX PR 266 2.5x 83MHz 3.5x 66MHz Cyrix MII 300 75MHz 4.0x 66MHz 3.5x 75MHz Cyrix MII 333 83MHz 2.5x 100MHz Cyrix MII 350 100MHz Cyrix MII 366 2.5x...
- Page 10 SY-5EHM/5EH5 Quick Start Guide Note: Use 8ns or faster SDRAM modules (for PC100) when SDRAM is set to run at the frequency of 95/100MHz. Step 4. Select the CPU Burst Mode There are two types of CPU burst modes according to manufacturer design: Interleave Burst (CPU: Intel P54C/P55C, AMD K5/K6/K6-2/K6-III,IDT Ø...
- Page 11 SY-5EHM/5EH5 Quick Start Guide Step 6. Attach Connectors This section tells how to connect internal peripherals and power supply to the Motherboard. Internal peripherals include IDE devices (HDD, CD-ROM), Floppy Disk Drive, Front Panel Devices (Turbo LED, Internal Speaker, Reset Button, IDE LED, and KeyLock Switch.), Wake-On-LAN card, VGA card, Sound Card, and other devices.
-
Page 12: Memory Configuration Table
SY-5EHM/5EH5 Quick Start Guide Step 7. Configure Memory Your board comes with one SIMM Bank (2 modules) and two DIMM sockets, providing support for up to 512MB of main memory using DIMM modules from 8MB to 256MB. For 66MHz host bus CPUs use 12ns or faster DIMM modules; for 83MHz host bus CPUs use 8ns modules. -
Page 13: Quick Bios Setup
SY-5EHM/5EH5 Quick Start Guide Quick BIOS Setup After the hardware installation is complete, turn the power switch on, then press the <DEL> key during the system diagnostic checks to enter the Award BIOS Setup program. The CMOS SETUP UTILITY will display on screen. Then, follow these steps to complete the quick BIOS setup. - Page 14 SY-5EHM/5EH5 Quick Start Guide The SOYO CD Your 5EHM/5EH5 Super 7 ™ Motherboard comes with a CD-ROM labeled "SOYO CD." The SOYO CD contains the user's manual file for your new Motherboard, the drivers software available for installation, and a database in HTML format with information on SOYO Motherboards and other products.
- Page 15 SY-5EHM/5EH5 Quick Start Guide Please note that if the Start Up program was unable to determine which SOYO Motherboard you own, the manual selection menu will pop up, as shown below. Then select the user's manual file that corresponds to your Motherboard model name and click (Manual Selection Menu) The user's manual files included on the SOYO CD are in PDF (Postscript Document) format.
- Page 16 SY-5EHM/5EH5 Quick Start Guide After installation of windows, you will need to install the ETEQ drivers. Follow the instruction below. Ø Click the Install Drivers button to display the list of drivers that can be installed on your Motherboard. The start-up program displays the drivers available for the 5EHM/5EH5 and the Windows version you use.
- Page 17 SY-5EHM/5EH5 Quick Start Guide Step 4. Enter the SOYO CD Click the Enter SOYO CD button to enter the SOYO HTML database. The Start Up program will activate the default HTML browser installed on your system (for example, Internet Explorer or Netscape) to visualize the contents of the SOYO CD. The SOYO CD contains useful information about your Motherboard and other SOYO products available in as many as eleven different languages.
- Page 18 SY-5EHM/5EH5 Quick Start Guide How to contact us: If you are interested in our products, please contact the SOYO sales department in the region you live. If you require Technical Assistance, please contact our Technical Support in the region you live. SOYO prefers Email as communication medium, remember to always add to the email the country that you live in.
- Page 19 SY-5EHM/5EH5 Quick Start Guide E-Mail: support@soyo.co.uk Sales: tel: 852-27109810 SOYO Deutschland GmbH fax: 852-27109078 E-mail: soyo@hkstar.com August-Wilhelm-Kuhnholz-Str. 15 D-26135 Oldenburg Technical Support: Region Covered: Germany, Austria tel: 852-27109810 and Switzerland. (Zustandig fur fax: 852-27109078 Deutschland, Osterreich, Schweiz) E-mail: soyo@hkstar.com Web Site: www.saat.de, www.soyo- saat.com, www.soyo-saat.de...
- Page 20 Edition: July 1999 Version 2.2 SY-5EHM/5EH5 SERIAL...
