Apollo Enclosures ELITE LINE AE9800 Manual

Environmental tv enclosures
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
\
Environmental TV Enclosures – ELITE LINE
STANDARD
DIRECT SUN
AE9800
AE9800-DS
Mastering the Outdoor TV Viewing Experience from the Inside...Out!
www.apolloenc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELITE LINE AE9800 and is the answer not in the manual?

Questions and answers

Related Manuals for Apollo Enclosures ELITE LINE AE9800

Summary of Contents for Apollo Enclosures ELITE LINE AE9800

  • Page 1 Environmental TV Enclosures – ELITE LINE STANDARD DIRECT SUN AE9800 AE9800-DS Mastering the Outdoor TV Viewing Experience from the Inside…Out! www.apolloenc.com...

  • Page 2: Customer Service Contacts

    *The model number and Mfg. Code are on the back bottom right of the rear panel. Retain this installation manual with your sales receipt as a permanent record of your purchase in the event of warranty service. Page 2 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.

  • Page 3: Product Description

    Internal laminated IR film to anti-reflective tempered glass protects the LCD panel from harmful IR and UV • solar rays. • Cross flow fans installed in front cover lower bezel provide streaming airflow between the LCD screen and the front glass. Page 3 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.

  • Page 4: Safety Statements

    Safety Complies with Apollo Enclosures are certified to UL/CSA & CE safety standards. UL/CSA 60950-1 UL/CSA 60950-22 Voltage: 110/220V 60 HZ E212615 Amp: 15A Maximum NOTE: Please read entire instruction guide before you start installation and assembly of the Apollo enclosure.

  • Page 5: Getting Started

    For the TV to be positioned properly in the enclosure relative to the anti-reflective glass, please adjust the brackets as shown below, based on your Apollo enclosure model size and according to the depth of your TV. Page 5 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.
  • Page 6 1.9” TO 1.5” 2.0” TO 1.7” USE TOP HOLE USE TOP HOLE FOR TV DEPTH OF FOR TV DEPTH OF 1.4” TO 1.0” 1.6” TO 1.2” Page 6 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.
  • Page 7 Identify the notch on the TV Swing Bracket based on the size of the TV (see chart below) Enclosure/TV Sizes Center Line Notch Indicator AE9800 (90”-98’) Center Line Notch Label Page 7 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.
  • Page 8 Securely tighten brackets in place using metric screws and washers. If screws are too long, use additional washers between bracket and screw head. Page 8 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.
  • Page 9 (Approximately 32” apart). Apollo enclosure model 98” is designed for standard TV VESA pattern widths of: 600mm (Approx. 24”) 800mm (Approx. 32”) 900mm (Approx. 35”) Page 9 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.
  • Page 10 (provided). Use M6 lock nuts and washers provided to fasten to the right-angle stiffener brackets on the inside. Page 10 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.
  • Page 11 Swing bottom of TV outward; plug TV into 3 outlet A/C power receptacle on rear panel and make appropriate signal connections. Page 11 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.
  • Page 12 Cover should now freely pivot down to close position. Flange on top of rear panel fits into top channel on front cover. Page 12 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.
  • Page 13 Push front cover studs through the tabs in the back cover and secure with flange nuts. IMPORTANT: Tighten with hand tools to secure seal. (Be careful not to overtighten) • 98” Model utilizes 4 flanged nuts. Page 13 IG24.08.07 98 STD - DS Copyright 2024 Apollo Enclosures LLC. All rights reserved.

  • Page 14: Maintenance And Care

    (See Optional Accessories at bottom of page) Cleaning the Glass – Apollo enclosures are equipped with anti-reflective safety glass to ensure the best possible viewing experience.  To properly clean the glass, we recommend the use of a soft cotton or microfiber cloth with a standard 70/30 ...

  • Page 15: Troubleshooting

    You can find more information about Apollo Enclosures at our website, from product specification sheets to Frequently Asked Questions (FAQs), it is all there. Visit us at: www.apolloenc.com Limited Warranty Apollo enclosures and accessories are warrantied for one (1) year in-factory parts and labor from the date of original purchase. Please go to our website at www.apolloenc.com for full details on warranty and return policies.

This manual is also suitable for:

Elite line ae9800-ds
