- Page 1 ELITE MODEL Environmental TV Enclosures STANDARD DIRECT SUN AE4239 AE4239-DS AE5550 AE5550-DS AE6560 AE6560-DS AE7570 AE7570-DS AE8680 AE8680-DS Mastering the Outdoor TV Viewing Experience from the Inside…Out! www.apolloenc.com...
-
Page 2: Customer Service Contacts
Introduction Congratulations on the purchase of your Apollo environmental TV enclosure. Apollo Enclosures (Apollo) developed environmental LED/LCD enclosures as a platform to provide an affordable solution to safely enjoy TV entertainment outdoors in both residential and commercial applications worldwide. With optimized internal capacity, configurability and flexibility; the Apollo environmental enclosure is the ideal solution for protecting your LED/LCD TV for outdoor entertainment applications of today and tomorrow, providing both quality and endurance for years to come. -
Page 3: Product Description
Internal laminated IR film to anti-reflective tempered glass protects the LCD panel from harmful IR and UV • solar rays. • Cross flow fans installed in front cover lower bezel provide streaming airflow between the LCD screen and the front glass. IG23.01.19 43-98 STD - DS Page 3 Copyright 2023 Apollo Enclosures LLC. All rights reserved. -
Page 4: Safety Statements
Safety Complies with Apollo Enclosures are certified to UL/CSA & CE safety standards. UL/CSA 60950-1 UL/CSA 60950-22 Voltage: 110/220V 60 HZ E212615 Amp: 15A Maximum NOTE: Please read entire instruction guide before you start installation and assembly of the Apollo enclosure. -
Page 5: Getting Started
Use the parts list to verify all materials are included. Save the shipping container and all packing inserts until installation is complete. c. Snip wire ties securing two (2) TV swing brackets, which will be required for next step. IG23.01.19 43-98 STD - DS Page 5 Copyright 2023 Apollo Enclosures LLC. All rights reserved. - Page 6 TOP FOR TV DEPTH OF TOP FOR TV DEPTH OF 1.0” – 1.7” 1.4” TO 1.9” USE NYLON ROLLER THRU TOP HOLE FOR TV DEPTH OF 1.0” TO 1.5” IG23.01.19 43-98 STD - DS Page 6 Copyright 2023 Apollo Enclosures LLC. All rights reserved.
- Page 7 HOLE FROM TOP FOR TV DEPTH OF 1.4” TO 1.7” INSTALL EXTENSION BRACKETS AND USE NYLON ROLLER THRU TOP HOLE FOR TV DEPTH OF 1.0” TO 1.3” IG23.01.19 43-98 STD - DS Page 7 Copyright 2023 Apollo Enclosures LLC. All rights reserved.
- Page 8 A AE6560 (60”–65”) For Lower VESA patterns, use notch A AE7570 (70”-76”) For Lower VESA patterns, use notch D AE8680 (80”-86’) Center Line Label IG23.01.19 43-98 STD - DS Page 8 Copyright 2023 Apollo Enclosures LLC. All rights reserved.
- Page 9 Securely tighten brackets in place using metric screws and washers. If screws are too long, use additional washers between bracket and screw head. IG23.01.19 43-98 STD - DS Page 9 Copyright 2023 Apollo Enclosures LLC. All rights reserved.
- Page 10 Repeat for brackets on both sides. Do not place a screw in the bottom VESA hole at this time. IG23.01.19 43-98 STD - DS Page 10 Copyright 2023 Apollo Enclosures LLC. All rights reserved.
- Page 11 For 55”, 65”, 75” TVs with low VESA pattern (from Page 10, 3.1). Attach mount bracket through bottom hole first, then remove temporary screw on top and reattach through bracket, IG23.01.19 43-98 STD - DS Page 11 Copyright 2023 Apollo Enclosures LLC. All rights reserved.
- Page 12 Swing bottom of TV outward; plug TV into 3 outlet A/C power receptacle on rear panel and make appropriate signal connections. IG23.01.19 43-98 STD - DS Page 12 Copyright 2023 Apollo Enclosures LLC. All rights reserved.
- Page 13 Cover should now freely pivot down to close position. Flange on top of rear panel fits into top channel on front cover. IG23.01.19 43-98 STD - DS Page 13 Copyright 2023 Apollo Enclosures LLC. All rights reserved.
- Page 14 IMPORTANT: Tighten with hand tools to secure seal. (Be careful not to overtighten) • Models 43” – 65” utilize 2 flanged nuts. • Models 75” & 86” utilize 3 flanged nuts. IG23.01.19 43-98 STD - DS Page 14 Copyright 2023 Apollo Enclosures LLC. All rights reserved.
-
Page 15: Maintenance And Care
(See Optional Accessories at bottom of page) Cleaning the Glass – Apollo enclosures are equipped with anti-reflective safety glass to ensure the best possible viewing experience. To properly clean the glass, we recommend the use of a soft cotton or microfiber cloth with a standard 70/30 ... -
Page 16: Troubleshooting
You can find more information about Apollo Enclosures at our website, from product specification sheets to Frequently Asked Questions (FAQs), it is all there. Visit us at: www.apolloenc.com Limited Warranty Apollo enclosures and accessories are warrantied for one (1) year in-factory parts and labor from the date of original purchase. Please go to our website at www.apolloenc.com for full details on warranty and return policies.
