ROOFTOP TENT KIT
P/N 2890560
MISSING OR DAMAGED PARTS
Before beginning assembly, inspect the kit and its
component(s) to be sure all parts and tools are
accounted for and not damaged. If missing parts or
parts are damaged, please contact your Selling
Dealer for assistance.
APPLICATION
Verify accessory fitment at www.polaris.com.
On 2-Passenger ADV models, Rooftop Tent Kit is not compatible with Rear Roof Mounted Lights Kit, P/N
On Multi-Passenger XP models, Rooftop Tent Kit is not compatible with Rear Roof Mounted Lights Kit, P/N
INSTALLATION VIDEO
A video of the installation is viewable on mobile devices by scanning the QR code
or by clicking
HERE
if viewing on a PC.
SAFETY
IMPORTANT SAFETY INFORMATION
Improper use and installation can result in loss of
control, serious injury, or death. Read and follow
the safety information and instructions in this
manual.
Load the Vehicle Properly
• Do not install this Rooftop Tent Kit on
non-compatible vehicles. It is exclusively designed
for Polaris Xpedition
®
• Do not exceed maximum weight capacity for this
vehicle; see load capacity label on cargo rack.
• When vehicle is parked, roof rack has a maximum
capacity of 500 lb (226 kg). Tent weight is 146 lb (66
kg). Maximum tent occupant capacity is 354 lb (160
kg).
• When stowing the tent, do not store additional cargo
inside the tent, and do not carry additional cargo on
top of stowed tent.
2889853; 2889730 or with Hi Rise Intake Kit, P/N 2890693.
.
Instr 9941299
If your accessory was purchased online, please
contact POLARIS
1-800-POLARIS (US & Canada only).
IMPORTANT
2889853; 2889730.
Use Extra Care when Driving or Trailering with
Tent Installed
• The weight of riders and cargo changes vehicle
braking, handling, and stability. To avoid loss of
control, turn gradually, operate at slower speeds,
and avoid rougher or steeper terrain.
• Do not exceed 80 mph (128 km/h) while trailering
with tent.
• Avoid overhead impacts. Rooftop tent increases
overall vehicle height when stowed, which reduces
total vehicle clearance.
Use the Tent Properly
• When selecting an area to park the vehicle and
deploy the tent, make sure the surrounding area is
clear of power lines, branches, and other obstacles
that could contact the tent.
• Make sure vehicle is level, gear selector is in PARK,
and wheels are chocked when tent is deployed.
• Prevent vehicle from moving by chocking wheels. A
chock is a wedge or wheel stop that is designed to
keep vehicle from moving forward or backward.
Rev 03 2024-01
Page 1 of 19
®
customer service at

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2890560 and is the answer not in the manual?

Questions and answers

Related Manuals for Polaris 2890560

Summary of Contents for Polaris 2890560

  • Page 1 POLARIS customer service at accounted for and not damaged. If missing parts or 1-800-POLARIS (US & Canada only). parts are damaged, please contact your Selling Dealer for assistance. APPLICATION Verify accessory fitment at www.polaris.com.
  • Page 2 • Keep exits clear. • Never use tent ladder if it is not attached to this • Build campfires downwind and at a safe distance of Polaris ® Rooftop Tent. Dispose of tent ladder when at least 10 ft (3 m) away from a tent.

  • Page 3: Kit Contents

    KIT CONTENTS Instr 9941299 Rev 03 2024-01 Page 3 of 19...

  • Page 4: Part Description

    PART DESCRIPTION P/N AVAILABLE AVAILABLE SERVICE KIT SEPARATELY Tent Assembly Weld Nut Plate 2211757 Tent Mounting Bracket 5274395-458 2211757 Screw, Hex Flange M8 x 1.25 x 60 mm 7521332–60 2211757 Rail Stud M10 x 1.5 x 21 mm 7528236 2211679 Flat Washer M10 x 2.5 mm 7558716 2211679...

  • Page 5: Tools Required

    PART DESCRIPTION P/N AVAILABLE AVAILABLE SEPARATELY SERVICE KIT Battery to 12 V Socket Adapter 2211764 Bungee Cords Open End Wrench 10 mm Double Ended Open End Wrench 8/10 mm Zipper Lubricant (Not Shown) 2208916 Rainfly (Not Shown) 2211761 Tent Canopy (Not Shown) 2211760 Mattress Cover (Not Shown) 2211762...
  • Page 6 3. Pull up on four straps to detach hook and loop 6. Unzip and open panel. fastener. Remove straps from D-rings. 7. Remove ladder , cover , rods , boot bags 4. Lift top half of tent assembly and open tent. cargo net , and other hardware from tent.
  • Page 7 9. Unzip panel on upper half of tent assembly. 12. Install bracket and two locking nuts DO NOT torque fasteners at this time. 10. Find two sets of ladder mounting holes on inside of tent. 13. Align ladder with brackets NOTICE Make sure that labels on ladder are facing upward.
  • Page 8 14. Assemble ladder to each bracket with screw 16. Install straps through D-rings. Pull straps tight and locking nut , washer , and spacer . Torque fasten with hook and loop fastener. nuts to specification. TORQUE Nuts 88 in-lbs (10 N·m) 15.
  • Page 9 18. Set tent assembly on top of platform rack. 20. Slide rail stud into slot on mounting bracket. NOTICE WARNING Stud should be pushed fully into slot until making Use at least two people to help set tent assembly on contact with base of slot.
  • Page 10 23. Torque nuts to specification. 25. Unfold travel cover . Remove zipper half from travel cover. TORQUE Nuts 30 ft-lbs (40 N·m) NOTE Torquing these nuts will require use of crowfoot wrench. When applying final torque, crowfoot wrench will need to be at a right angle to head of torque wrench, as shown in illustration.
  • Page 11 29. Open ladder strap. 32. Use ladder to tilt up upper half of tent assembly WARNING Before opening tent assembly, make sure that surrounding area is clear of power lines, branches, or other obstacles that may come into contact with tent.
  • Page 12 34. Each of top seven rungs on ladder has a pair of 36. Collapse top rungs of ladder until ladder is black buttons on underside of rung. Pressing both approximately vertical. black buttons allows rung to be individually WARNING collapsed. Make sure that when ladder is positioned, base of WARNING tent is level with top of roof rack.
  • Page 13 38. Remove tent rods from bag. 41. Install straight end of tent rod into hole in tent frame. 39. Remove toggles from corners of rain fly. 42. Install hook end of rods into grommets in rain fly. 40. Install tent rods .
  • Page 14 44. Unzip flap above ladder. Roll up flap and hold flap 47. Close flap over power cord slot. with toggles at top of tent opening. 45. Attach LED power cord to LED strip in tent. 46. Route remaining end of power cord through slot at base of tent.
  • Page 15 48. Install five hooks on cargo net to loops on 49. Install top edge of boot bag into slot at the edge bottom of tent base. of tent base. Slide boot bag into slot until top of boot bag is fully engaged. Instr 9941299 Rev 03 2024-01 Page 15 of 19...
  • Page 16 STOWING TENT 2. Disconnect LED power cord from LED strip in tent. Store LED power cord inside tent. 1. Install four bungee cords inside tent. Attach loops on one side of tent to corresponding loops on opposite side of tent. NOTICE After first-time setup, bungee cords should be removed while tent is in use.
  • Page 17 5. Store tent rods inside zippered pouch inside tent 9. Use ladder to push tent base up until it folds over entrance. the vehicle. 6. Use toggles to attach corners of rain fly to tent. 10. After tent is folded over, fully collapse ladder. 7.
  • Page 18 12. Tuck in any fabric sticking out from front, rear, or 15. Attach and tighten straps. side of tent assembly. Attach and tighten straps on front side and rear side of vehicle. WARNING Do not carry any additional cargo on top of tent 13.

  • Page 19: Operation

    OPERATION LED LIGHT STRIP Use of this location to obtain power does not require ignition switch to be ON. LED strip power cord can be plugged in at two locations. The first location is 12 V socket in center NOTICE console of vehicle.
