Portable car lift 2.25 tonne 750w/230v

Advertisement

Quick Links

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
Read all warnings, safety instructions and other instructions. Failure to follow all the instructions and safety
9
instructions can result in a risk of personal injury and/or material damage.
The lift has to be used only referring to the type of vehicle support specified by the manufacturer.
9
The manufacturer assumes no responsibility for personal injury or damage to property arising from the handling,
9
use or maintenance of the product in any way other than that described in these instructions.
Special training has to be given to the operator and the persons who are permitted to stand under the vehicle during lifting and
9
lowering. Only to be used by operators who have been trained to use it and those who are fully conversant with this manual.
Persons are only permitted to stand under a moving load in extreme circumstances where movements of the load should be kept as
9
short as possible.
WARNING! indicates a dangerous or potentially dangerous situation that could lead to fatal or serious personal injury if the instructions
are not followed.
IMPORTANT! indicates instructions that must be followed in order to prevent damage to property.
Familiarise yourself with the controls on the product and how to use them. Persons who are not trained or familiar, with these
9
instructions must not use the product.
Incorrect use can result in the risk of fatal or serious personal injury and/or material damage.
9
This product is a portable vehicle lift. Use the product only for its intended purpose.
9
Check the product for cracks in weld joints as well as damaged, loose, worn or missing parts each time before use.
9
Keep all body parts away from the product during use.
9
Never modify the product in any way.
9
In the event of oil spillage ensure an oil spill kit is to hand. Consult Sealey website for Materials Safety Data Sheet for characteristics
9
of fluids included with the product.
Firefighting procedure/equipment should be in accordance with the Materials Safety Data Sheet.
9
Only use lifting points recommended by the vehicle manufacturer.
9
After installation the name plate shall remain readily visible.
9
After installation at the user's site check that the vehicle lift and the associated safety and protective devices are correctly installed and
9
function in a proper manner.
Always check the weight of the vehicle before lifting. Never exceed the maximum permitted load for the product.
9
Overloading damages the products and entails a risk of serious personal injury.
9
Never adjust the safety valve.
9
Inspect the product carefully at least once a year. Replace any damaged or worn cables and hoses. Check that the safety and warning
9
labels on the product are intact and legible. Replace any labels that are illegible or have gone missing.
DO NOT use the product until any worn or damaged parts have been replaced.
8
Never attempt to lift loads that are not centred or are poorly balanced. Incorrect loading can damage the product and entails a risk of
8
serious personal injury.
Take steps to ensure that the load cannot move or tip over while being raised or lowered. If the product is being used beside a road,
9
traffic can cause the vehicle to move.
Make sure that nobody is inside the vehicle and apply the parking brake.
9
Secure the load that is to be lifted with wedges or similar, so that it cannot slide or move.
9
Never climb into a raised or supported vehicle and do not start the engine.
9
DO NOT touch hot parts – risk of getting burned.
8
Wear suitable personal protective equipment, such as safety glasses, safety helmet, gloves, etc.
9
The surface the lift is used on, must be dry, flat and able to support a load of 34.4bar.
9
Route the power cord and the hydraulic hoses so that they cannot be trodden on or driven over, so that there is no risk of tripping over
9
them, or of them being put under strain.
DO NOT wear loose-fitting clothing, jewellery, watches, etc., that can get caught in moving parts or conduct electricity.
8
Evacuate the area immediately if the load is threatening to collapse the vehicle lift.
9
Check that both safety lock bars are applied before anyone goes in the vicinity of the raised load.
9
Never open the filler plug on the electric pump when the product is in use.
9
Contact your stockist for technical assistance or repairs. The warranty ceases to apply if the product has been modified in any way,
9
damaged as a result of an accident, negligence or incorrect use, or has been repaired by unauthorised personnel.
Always keep the product clean.
9
Store the product fully lowered when not in use.
9
DO NOT use hydraulic equipment at temperatures above 65°C. High temperatures weaken the hose material and cause seals to
8
soften, which entails a risk of hydraulic fluid leakage and/or other damage to property.
© Jack Sealey Limited
PORTABLE CAR LIFT 2.25 TONNE 750W/230V
CLM2250
MODEL NO:
Thank you for purchasing a Sealey product. Manufactured to a high standard, this
product will, if used according to these instructions, and properly maintained, give you
years of trouble free performance.
Original Language Version
Wear eye
Wear
Wear
protection
protective
protective
gloves
footwear
Wear head
protection
CLM2250 Issue:4(1) 22/10/24

Advertisement

loading
Need help?

Need help?

Do you have a question about the CLM2250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sealey CLM2250

  • Page 1 Keep all body parts away from the product during use. Never modify the product in any way. In the event of oil spillage ensure an oil spill kit is to hand. Consult Sealey website for Materials Safety Data Sheet for characteristics of fluids included with the product.
  • Page 2: Specification

    A transportable lifting system which makes total vehicle lifting, for maintenance or detailing, much more convenient. Each Strut weighs less than 40kg, and is on wheels for easy positioning. Automatic safety lock bars, with dual locking positions. A low clearance height of just 75mm, making it ideal for custom, sports and race vehicles. 3. SPECIFICATION Model No: ...............CLM2250 Capacity: ............. 2.25 tonnes Weight: ..............104.4kg Sound: ..............<70dBA Max.
  • Page 3: Operation

    Never leave the product unattended if it is not fully lowered or locked in the lower or upper locking position. Scissor lifts are designed to only hold loads with lock bar applied in the locking positions. 7.10. Only use lifting blocks of the same height, do not mix low and high lifting blocks. CLM2250 Issue:4(1) 22/10/24 Original Language Version © Jack Sealey Limited...
  • Page 4 Adjust the lifting blocks on the plates so that they are directly beneath the vehicle’s lifting points. 7.14.8. In this way, lifting frames and lifting blocks are correctly positioned to lift the vehicle. IMPORTANT: The lifting frames must be parallel under the vehicle. CLM2250 Issue:4(1) 22/10/24 Original Language Version © Jack Sealey Limited...
  • Page 5 7.17.1. Press and hold U button until the lock bar is clear of the lock block. CLM2250 Issue:4(1) 22/10/24 Original Language Version © Jack Sealey Limited...
  • Page 6: Maintenance

    8.4. STORAGE 8.4.1. Store in fully lowered position when not in use. 8.5. REPAIR 8.5.1. Professional repair only. Contact Sealey for Technical Assistance. 8.5.2. Warranty will be invalidated if the product is modified in any way, damaged as a result of an accident, negligence or incorrect use, or if it has been repaired by unauthorised personnel. 8.6. SAFETY CHECKS 8.6.1. Check all bolted joints regularly, and tighten them if necessary.
  • Page 7: Troubleshooting

    Pressure in the hydraulic system. Relieve the pressure by pressing and holding the D button for a few seconds after the lifting frames have been fully lowered, in order to return as much hydraulic fluid as possible to the fluid reservoir. Contact Sealey if the pressure is so high that it is not possible to connect the couplers. WEEE REGULATIONS Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way.
