RTD200
USB Adapter for 2/3-Wire RTD Probe
Model name
USB-RTD200
USB-RTD200-CAL
VCP-RTD200
VCP-RTD200-CAL
HS code: 8471.60.10.50
Part number Description
601046
USB adapter for 2/3-wire RTD probe
608046
USB adapter for 2/3-wire RTD probe
– calibratable
603046
USB adapter for 2/3-wire RTD probe
– with VCP mode
605046
USB adapter for 2/3-wire RTD probe
– calibratable with VCP mode
Advertisement
Table of Contents
Related Manuals for Dracal Technologies RTD200
Summary of Contents for Dracal Technologies RTD200
- Page 1 User Manual RTD200 USB Adapter for 2/3-Wire RTD Probe Model name Part number Description USB-RTD200 601046 USB adapter for 2/3-wire RTD probe USB-RTD200-CAL 608046 USB adapter for 2/3-wire RTD probe – calibratable VCP-RTD200 603046 USB adapter for 2/3-wire RTD probe –...
-
Page 2: Table Of Contents
6 Installation and Setup 6 Usage Guidelines and Applications 9 Care, Storage, and Recalibration 9 Troubleshooting Guide and Support 10 Return Process and Warranty Information 10 Accessories and Peripherals 10 Disassembly and Environmental Considerations 11 Document Revision History Dracal Technologies Inc. -
Page 3: Compliance Certification
It is available upon request to the relevant authorities. Signed for and on behalf of: Dracal Technologies Inc., January 2024 Ariane Garon President Dracal Technologies Inc. RTD200 – USB Adapter for 2/3-Wire RTD Probe... -
Page 4: Overview
The RTD series are USB adapters for Pt100 RTD probes, Class AA (1/3 DIN) or less. Connect any suitable probe to the adapter to measure temperature with outstanding precision. The RTD200 comes with a polarized 3-pin connector that facilitates connection and disconnection of the probe. The RTD200: the simplest way to collect temperature data with an RTD probe. -
Page 5: Product Overview And Specifications
Product Overview The RTD200 is a versatile USB adapter designed to measure temperatures using 2- or 3-wire 100-ohm Pt100 RTD sensors. With its 18-bit data converter, the RTD200 provides precise temperature measurements with high resolution. It compensates for errors introduced by the length of the probe cable when connected with three wires, allowing for accurate readings even with cables up to 30 meters long. -
Page 6: Safety Guidelines
Connect an instrument. Launch DracalView. Verify the instrument appears in the Sources tab. Modify units and decimals in the Configuration tab (Optional). Customize the names of channels to record in the Sources tab (Optional). Visualize data on GraphView. Dracal Technologies Inc. - Page 7 Please refer to the RTD200 page for the complete guide, specifically the “Software & Documentation” tab. Of note, to log data with DracalView, these are the remaining main steps of the Getting Started guide: Initiate the logging task in the Logging tab.
- Page 8 DracalView and the command-line tools. For additional information, please click the relevant link in the Software & Documentation section of the RTD200 page. Calibration “-CAL” suffix: If present, the product is equipped with a 3-point user-calibration mechanism.
-
Page 9: Care, Storage, And Recalibration
If the instrument has a “-CAL” suffix, it can be adjusted for accuracy during the calibration. The long-term drift of the RTD200 is minimal. Therefore, depending on the user’s application, an adjustment might be required more frequently. Troubleshooting Guide and Support... -
Page 10: Return Process And Warranty Information
In most cases, there will be an easy solution. In the rare event of a faulty instrument under warranty, Dracal Technologies will proceed to a replacement upon evaluating the situation. The procedure will be explained through email once the customer advises support@dracal.com. -
Page 11: Document Revision History
These USB sensors comply with CE (Conformité Européenne) and REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulations, meeting European safety and environmental impact standards. Document Revision History Version 1.0 2024-02-08 Creation of the User Manual. RTD200 – USB Adapter for 2/3-Wire RTD Probe... - Page 12 +1 450.812.8612 Dracal Technologies Inc. A204 - 7900 Taschereau Blvd Brossard (Quebec) J4X 1C2 Canada...
