  • Page 1 Thermal Imager MiniX User Manual Contact Us...

  • Page 2: Table Of Contents

    Imager Mounting ......................4 Surface Mount ............................4 Phone Mount ............................5 Tripod Mount ............................5 Imager Charging .......................6 Download and Connect HIKMICRO Viewer ..............8 HIKMICRO Viewer Introduction ......................8 Download the APP ..........................8 Connect Thermal Imager and the APP....................9 4.3.1 Connection Via QR Code Scanning ....................
  • Page 3 Share Snapshots and Videos ....................... 26 Generate and Share PDF Report ......................26 Upgrade and Maintenance .................... 27 Upgrade the Imager ..........................27 Reset the Imager ..........................27 Error Diagnosis ............................. 27 More Operations ......................28 Connect Thermal Imager to HIKMICRO Analyzer ................28...

  • Page 4: Product Overview

    Android or iOS systems through Wi-Fi or Bluetooth connection. It can be used to conduct temperature measurement, snapshot capturing, video recording and PDF report generation and sharing and other functions with a software client HIKMICRO Viewer. Main Components Figure 1-1 Main Components Table 1-1 Main Component Description...

  • Page 5: Appearance

    Thermal Imager User Manual Thermal imager Infrared thermal camera which can measure temperature, capture snapshots, record video and etc. Surface mount Attach the holder directly on magnetic holder surfaces, or screw the holder to non- magnetic surfaces. Screws are not included in the imager case.
  • Page 6 Thermal Imager User Manual Table 1-2 Thermal Imager Appearance Description Name Description Power button Hold to power on/off the imager. Thermal camera View thermal images. lens Visual camera View visual images. lens Status indicator Indicate the working status of the imager: ...

  • Page 7: Imager Mounting

    Thermal Imager User Manual Imager Mounting Surface Mount Use a surface mount holder to fix the imager as follows: 1. Mount the holder:  On magnetic surfaces: Attach the holder directly.  On non-magnetic surfaces: Use two M3 screws (not included) to fix the holder to the surface.

  • Page 8: Phone Mount

    Thermal Imager User Manual Do Not place any objects on the imager in case of accidental dropping. Phone Mount Use a phone mount holder to clamp the imager to a phone or a pad. 1. Hook the imager to the holder. 2.

  • Page 9: Imager Charging

    Thermal Imager User Manual Figure 2-2 Tripod Mount You need to prepare a tripod (not included in the imager case). Imager Charging Use a supplied USB cable to charge the imager. For the first time use, it is recommended to charge the imager for at least 1.5 hours in power-off status.
  • Page 10 Thermal Imager User Manual Figure 3-1 Imager Charging with a USB Cable  Single flashing indicator means that it is charging normally. Three steady indicators indicate the full battery.  You need to prepare a power adapter (it is NOT included in the imager case).

  • Page 11: Download And Connect Hikmicro Viewer

    PDF report generation and sharing and online firmware upgrade and etc. Download the APP Scan the QR codes or search “HIKMICRO Viewer” on App Store or Google Play to download and install the APP. Figure 4-1 HIKMICRO Viewer QR Code...

  • Page 12: Connect Thermal Imager And The App

    1. Press and hold power button to power on the imager. 2. Launch HIKMICRO Viewer, and tap + > Scan QR Code to scan the QR code attached on the imager. 3. Tap Join in the pop-up window to pair the APP with the imager.

  • Page 13: Connection Via Bluetooth

    1. Press and hold power button to power on the imager. 2. Launch HIKMICRO Viewer, and tap + > Add Device > Thermal Imager (Wireless) to add the imager. 3. Tap Connect to connect the imager and the APP.

  • Page 14: Home Screen Overview

    Thermal Imager User Manual Home Screen Overview Figure 4-4 HIKMICRO Viewer Home Screen Table 4-1 Home Screen Description Name Description Live View Browse real time thermal imaging display, including image calibration, temperature measurement, and taking snapshots and videos, etc. Device Online upgrade the imager firmwares.

  • Page 15: Live View

    Thermal Imager User Manual Live View Live View In Live View, you can adjust and calibrate thermal image, measure temperatures, change palettes, etc. 5.1.1 Live View Interface Figure 5-1 Live View Interface...
  • Page 16 Thermal Imager User Manual Table 5-1 Live View Interface Icons Functions Description Enhance the object outlines for better SuperIR image display. Auto The device will automatically implement Calibration Flat Field Calibration (FFC). The device will implement Flat Field Manual Calibration (FFC) one time after you tap Calibration the icon.

  • Page 17: Adjust Image Display

    Thermal Imager User Manual Figure 5-2 Status Bar Rotation 5.1.2 Adjust Image Display Focusing Adjustment Aim the thermal lens to your target, and rotate the focus ring to make the image clear. SuperIR Switch on to get an enhanced thermal image. Tap again to turn it off.

  • Page 18: Set Image Mode

    Thermal Imager User Manual It is recommended to enable Auto Calibration. Otherwise, you need conduct Manual Calibration periodically for the accuracy of thermal imaging and temperature measurement. Manual Calibration to calibrate the image for one time. 5.1.4 Set Image Mode You can set the thermal/visual view of the device.

  • Page 19: Select Palettes

    Thermal Imager User Manual Figure 5-3 Parallax Correction Adjustment 5.1.5 Select Palettes Palettes highlights the imaging details as the image displays different colors according to temperature range. to select appropriate palettes. Figure 5-4 Different Palettes 5.1.6 Adjust Display Temperature Range After selecting appropriate palettes, it is advisable to adjust display temperature range to highlight the thermal image of the target of interest.

  • Page 20: Set Image Parameters

    Thermal Imager User Manual Auto Adjustment , the imager will shift to Auto Adjustment, and the display temperature range will be automatically adjusted. Manual Adjustment , the imager will shift to Manual Adjustment. It is a focus palette that you can swipe the temperature value up and down to adjust the range, focusing on the target in the set range.

  • Page 21: Measure Temperature

    Thermal Imager User Manual Table 6-1 Temperature Measurement Parameters ICON Function Description Select or customize the emissivity of the Emissivity target. Set the distance (unit: m) between the Distance target and the imager. Set the temperature range of targets. It is recommended to choose Auto mode as Temperature the temperature range is automatically...

  • Page 22: Add Line Measurement Tool

    Thermal Imager User Manual Table 6-2 Point Measurement Tools Icon Function Description Center Point Display the real-time temperature of the center of the live image. Hot Point Display the real-time highest temperature in live view. Cold Point Display the real-time lowest temperature in live view.

  • Page 23: Add Rectangle Measurement Tool

    Thermal Imager User Manual 4. Optional: Remove the Line again to turn off the line tool. Tap the line and then Edit character on the line. on the upper right corner in the pop-up window. 6.2.3 Add Rectangle Measurement Tool 1.
  • Page 24 Thermal Imager User Manual 1. Tap > to open the High Temp interface. 2. Input the maximum value of High Temp. 3. Optional: Set Sound Alarm/Vibrating Alarm. Slide to show/hide the sound alarm or vibrating alarm. 4. Slide High Temp to enable the alarm.

  • Page 25: Capture Snapshots And Record Videos

    Thermal Imager User Manual Capture Snapshots and Record Videos Capture Snapshots 1. Tap to capture thermal images and save them to the APP album. 2. Optional 1: Save the visual image. If enabled, a correspondent visual image will be saved to Albums while taking the thermal image of the target.

  • Page 26: View Snapshots/Videos

    Thermal Imager User Manual View Snapshots/Videos You can view the pictures and videos saved in the APP album as follows:  View the last captured pictures and videos: Tap the thumbnail image on the lower left corner in live view. ...
  • Page 27 Thermal Imager User Manual Table 7-1 Icons for Snapshots Editing Icon Function Description Re-adjust temperature measurement tools and the accroding temperature results in the image.  Tap Delete to remove single Measurement measurement tool. No more than 3 points and rectangles are supported. ...

  • Page 28: Set Alarm Mode Palettes

    Thermal Imager User Manual Video does NOT support editing functions. 7.4.1 Set Alarm Mode Palettes Alarm mode palettes allows to mark the targets of certain temperature range with a different color from the rest. 1. Tap to select an alarm mode. >...

  • Page 29: Share Snapshots And Videos

    Thermal Imager User Manual Share Snapshots and Videos 1. Enter to Albums, and tap to select the snapshots and videos. 2. Tap to share a ZIP Archive with the third party or save to your phone. 3. Optional: Tap to save snapshots and videos to your phone. Generate and Share PDF Report 1.

  • Page 30: Upgrade And Maintenance

    Thermal Imager User Manual Upgrade and Maintenance Upgrade the Imager For better operation experience, it is recommended to upgrade to the latest version in time. The imager firmware update is as follows:  In the home screen, tap Device Upgrade > Check for Updates. ...

  • Page 31: More Operations

    Thermal Imager User Manual More Operations Connect Thermal Imager to HIKMICRO Analyzer The Imager can also connect to HIKMICRO Analyzer, a PC client, to realize real-time temperature measurement and target observation, etc. Please contact dealers or technical support employers to get the installation package of HIKMICRO Analyzer.

  • Page 32: Legal Statement

    The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version of this Manual at the HIKMICRO website (www.hikmicrotech.com/). Please use this Manual with the guidance and assistance of professionals trained in supporting the Product.
  • Page 33 Thermal Imager User Manual CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKMICRO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY RISKS, AND HIKMICRO SHALL NOT TAKE ANY...

  • Page 34: Regulatory Information

    Thermal Imager User Manual Regulatory Information These clauses apply only to the products bearing the corresponding mark or information. EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the Directive 2014/30/EU (EMCD), Directive 2014/35/EU(LVD), Directive 2011/65/EU (RoHS).
  • Page 35 Thermal Imager User Manual waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information, see: www.recyclethis.info Directive 2006/66/EC and its amendment 2013/56/EU (Battery Directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 36 Thermal Imager User Manual (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. ce matériel est conforme aux limites de dose d'exposition aux rayonnements, CNR-102 énoncée dans un autre environnement. (i)Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à...

  • Page 37: Safety Instruction

    Use of the product must be in strict compliance with the local electrical safety regulations. Technical Support https://www.hikmicrotech.com/en/contact-us.html portal will help you as a HIKMICRO customer to get the most out of your HIKMICRO products. The portal gives you access to our support team, software and documentation, service contacts, etc. Power Supply ...

  • Page 38: Maintenance

    Thermal Imager User Manual Maintenance  If the product does not work properly, please contact your dealer or the nearest service center. We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.  Wipe the device gently with a clean cloth and a small quantity of ethanol, if necessary.

  • Page 39: Limited Warranty

    Thermal Imager User Manual Limited Warranty Scan the QR code for the product warranty policy. Manufacture Address Room 313, Unit B, Building 2, 399 Danfeng Road, Xixing Subdistrict, Binjiang District, Hangzhou, Zhejiang 310052, China Hangzhou Microimage Software Co., Ltd. COMPLIANCE NOTICE: The thermal series products might be subject to export controls in various countries or regions, including without limitation, the United States, European Union, United Kingdom and/or other member countries of the Wassenaar Arrangement.
  • Page 40 Facebook: Hikmicro Industrial LinkedIn: HIKMICRO Instagram: hikmicro_industrial YouTube: HIKMICRO Industrial E-mail: support@hikmicrotech.com Website: https://www.hikmicrotech.com/ UD38767B...
