Summary of Contents for AOC U32U3CV
-
Page 2: Table Of Contents
Safety ......................................1 National Conventions ..............................1 Power ....................................2 Installation ..................................3 Cleaning ....................................4 Other....................................5 Setup ......................................6 Contents in Box ................................6 Set-up Stand & Base ...............................7 Adjusting Viewing Angle ..............................8 Connecting the Monitor ..............................9 Wall Mounting ................................10 Adaptive-Sync function ..............................11 KVM ....................................12 HDR .................................... -
Page 3: Safety
Safety National Conventions The following subsections describe national conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 4: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. -
Page 5: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 6: Cleaning
Cleaning Clean the cabinet regularly with a water-dampened, soft cloth. When cleaning use a soft cotton or microfiber cloth. The cloth should be damp and almost dry, do not allow liquid into the case. Please disconnect the power cord before cleaning the product. -
Page 7: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 8: Setup
Warranty Card Stand Base USB C-C/A Cable USB C-C Cable Power Cable HDMI Cable DP Cable Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. -
Page 9: Set-Up Stand & Base
Set-up Stand & Base Please setup or remove the base following the steps as below. Setup: Note: Align the stand with the positioning holes in the base. Hold the stand and base without gaps and lock the two screws at the bottom before releasing the support to prevent it from falling. -
Page 10: Adjusting Viewing Angle
Adjusting Viewing Angle To achieve the best viewing experience, it is recommended that the user can make sure they are able to look at their whole face on the screen, then adjust the monitor’s angle based on personal preference. Hold the stand so you will not topple the monitor when you change the monitor’s angle. You are able to adjust the monitor as below: +15°... -
Page 11: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor and Computer: 5 6 7 8 1. Power Switch 2. Power 3. HDMI 1 4. HDMI 2 5. DisplayPort 6. USB C1 (Video, PD 96W) 7. USB C2 (upstream, data only) 8. -
Page 12: Wall Mounting
Dk=8.0 H=2.0 Note: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. Always contact manufacturer for wall-mount installation. * Display design may differ from those illustrated. WARNING: 1. To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward by more than -5 degrees. -
Page 13: Adaptive-Sync Function
Adaptive-Sync function 1. Adaptive-Sync function works with DisplayPort/HDMI/USB C 2. Compatible Graphics Card: Recommended list is as below, also could be checked by visiting www.AMD.com Graphics Cards • Radeon™ RX Vega series • Radeon™ RX 500 series • Radeon™ RX 400 series •... -
Page 14: Kvm
This product supports the KVM feature. In the display on state, you can control two signal output devices (two computers, or two laptops, or one computer and one laptop) with a keyboard and mouse set through the KVM feature. Setup steps: 1. -
Page 15: Hdr
It is compatible with input signals in HDR10 format. The display may automatically activate the HDR function if the player and content are compatible. Please contact the device manufacturer and the content provider for information on the compatibility of your device and content. Please select “OFF”... -
Page 16: Calman Ready
Calman Compatible Meter For information see : Calman Compatible Meters Scan the following QR code to open the AOC Monitor Calibration Workflow Guide for instructions on calibrating compatible AOC Calman Ready monitors: Note: Once calibration is complete, the calibration will be stored in the monitor OSD under the Picture → CMR Color Space. - Page 17 Step 1: Install your calman Tool.
- Page 18 1. Connect the laptop to the monitor’s USB C1 (bottom). 2. Connect a color meter to the laptop. 3. Open Calman and scan the following QR code to open the AOC Monitor Calibration Walkthrough Guide for instructions on calibrating compatible AOC Calman Ready monitors: Note: Once calibration is complete, the calibration will be stored in the monitor OSD under the Picture →...
-
Page 19: Adjusting
Adjusting Hotkeys Source/Exit Preset Mode/HDR Brightness Menu/Enter Power Menu/Enter Press to display the OSD or confirm the selection. Power Press the Power button to turn on the monitor. Brightness When there is no OSD, press “ ” key to open brightness function, then press “ ” or “ ” key to adjustment backlight. Preset Mode / HDR When there is no OSD, press “... -
Page 20: Osd Setting
OSD Setting Basic and simple instruction on the control keys. BRIGHTNESS PICTURE PRESET PRESET COLOR SPACE RESOLUTION 3840x2160 Standard Panel Native Preset Mode Standard Picture Text Input Reading PIP/PBP Internet Settings Movie OSD Setup Sports Information 1). Press the MENU-button to activate the OSD window. 2). -
Page 21: Preset Mode
Preset Mode BRIGHTNESS PICTURE PRESET PRESET COLOR SPACE RESOLUTION 3840x2160 Standard Panel Native Preset Mode Standard Picture Text Input Reading PIP/PBP Internet Settings Movie OSD Setup Sports Information Standard Standard Mode Text Text Mode Reading Reading Mode Internet Internet Mode Movie Movie Mode Sports... -
Page 22: Picture
Picture BRIGHTNESS PICTURE PRESET PRESET COLOR SPACE RESOLUTION 3840x2160 Standard Panel Native Preset Mode Preset Mode Brightness Picture Contrast Input Sharpness PIP/PBP Gamma Settings Color Temp. OSD Setup Information Brightness 0-100 Adjust brightness. Contrast 0-100 Adjust contrast. Sharpness 0-100 Adjust Sharpness. Gamma 1.8 / 2.0 / 2.2 / 2.4 / 2.6 Adjust Gamma. - Page 23 sRGB Display-P3 Adjust CMR Color Space. Note: This feature is optional only after the color DCI-P3 space of the machine is adjusted through the DCI-P3 (D50) Calman tool (PC software) developed by Portrait. This product can be color-calibrated by using CMR Color Space Adobe RGB Calman color calibration software, and the hardware...
- Page 24 Over Scan Off / On Disable or Enable Over Scan. Enhance the screen details in the dark or bright Off / Level 10 / Level 20 Shadow Boost area to adjust the brightness in the bright area and / Level 30 ensure that it is not oversaturated.
-
Page 25: Input
Input BRIGHTNESS PICTURE PRESET PRESET COLOR SPACE RESOLUTION 3840x2160 Standard Panel Native Preset Mode Preset Mode Auto Source Auto Source Picture HDMI 1 HDMI 1 Input HDMI 2 HDMI 2 PIP/PBP DisplayPort DisplayPort Settings USB C USB C OSD Setup Information Auto Source Off / On... -
Page 26: Pip/Pbp
PIP/PBP BRIGHTNESS PICTURE PRESET PRESET COLOR SPACE RESOLUTION 3840x2160 Standard Panel Native Preset Mode Preset Mode PIP/PBP Mode Auto Source Picture Main Source HDMI 1 Input Sub Source HDMI 2 PIP/PBP DisplayPort Audio Settings USB C Size OSD Setup Position Information PIP / PBP Mode Off / PIP / PBP... -
Page 27: Settings
Settings BRIGHTNESS PICTURE PRESET PRESET COLOR SPACE RESOLUTION 3840x2160 Standard Panel Native Preset Mode Preset Mode Auto Source Language Picture USB Selection HDMI 1 Input HDMI 2 USB C PIP/PBP USB Standby Mode DisplayPort Settings SmartPower USB C OSD Setup Break Reminder Information English/Français/Español/... -
Page 28: Osd Setup
OSD Setup BRIGHTNESS PICTURE PRESET PRESET COLOR SPACE RESOLUTION 3840x2160 Standard Panel Native Preset Mode Preset Mode Transparence Auto Source Picture H. Position HDMI 1 Input V. Position HDMI 2 PIP/PBP OSD Timeout DisplayPort Settings OSD Setup Information Transparence 0-100 Adjust the transparence of OSD. -
Page 29: Information
Information BRIGHTNESS PICTURE PRESET PRESET COLOR SPACE RESOLUTION 3840x2160 Standard Panel Native Preset Mode Preset Mode Input HDMI2 xxxxxxxxxxxxx Picture Resolution 3840x2160@60Hz FW Version Vxxx Input Brightness PIP/PBP Color Space Panel Native Firmware Date xxxxxxxx Settings Gamma HBR2/HBR3 OSD Setup White Point 6500K Sync... -
Page 30: Led Indicator
LED Indicator Status LED Color Full Power Mode White Active-off Mode Orange... -
Page 31: Troubleshoot
Press hot-key (AUTO) to auto-adjust. Please refer to Regulation & Service Information which is in the CD manual Regulation & Service or www.aoc.com (to find the model you purchase in your country and to find Regulation & Service Information in Support page. -
Page 32: Specification
Specification General Specification Model name U32U3CV Driving system TFT Color LCD Panel Viewable Image Size 80.0 cm diagonal(31.5” Wide Screen) Pixel pitch 0.18159mm(H) x 0.18159mm(V) Display Color 1.07B Colors Horizontal scan range 30k~140kHz Horizontal scan Size(Maximum) 697.3mm Vertical scan range 23~75Hz Vertical Scan Size(Maximum) 392.2mm... -
Page 33: Preset Display Modes
Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION(±1Hz) FREQUENCY(KHz) FREQUENCY(Hz) DOS MODE 720x400@70Hz 31.469 70.087 640x480@60Hz 31.469 59.94 640x480@67Hz 66.667 640x480@72Hz 37.861 72.809 640x480@75Hz 37.5 800x600@56Hz 35.156 56.25 800x600@60Hz 37.879 60.317 SVGA 800x600@72Hz 48.077 72.188 800x600@75Hz 46.875 MAC MODES 832X624@75Hz 49.725 74.551 1024x768@60Hz 48.363... -
Page 34: Pin Assignments
Pin Assignments 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Data 0- DDC/CEC Ground TMDS Data 2 Shield TMDS Clock + +5V Power TMDS Data 2- TMDS Clock Shield Hot Plug Detect TMDS Data 1+ TMDS Clock-... -
Page 35: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
