Affirmed by
BS EN ISO 9001
Declaration of Conformity
Certificate No. FM 15094
Amplicon products are designed and manufactured in the United Kingdom under a
quality system approved by the British Standards Institution
P C I 2 3 6
24 LINE
PROGRAMMABLE
DIGITAL
INPUT/OUTPUT
BOARD
This Instruction Manual is supplied with the PCI236 board to provide the user with sufficient information to properly
utilise the product as purchased. The information contained has been reviewed and is believed to be accurate and
reliable, however Amplicon Liveline Limited accepts no responsibility for any problems caused by errors or
omissions. Specifications and instructions are subject to change without notice.
PCI236 Instruction Manual Part Nº 909 936 64 Issue A2
© Amplicon Liveline Limited
Prepared by D.N.Cooper
Approved for issue by A.S. Gorbold, Operations Director
PCI236
Advertisement
Table of Contents
Related Manuals for Amplicon Liveline 200 Series
Summary of Contents for Amplicon Liveline 200 Series
- Page 1 The information contained has been reviewed and is believed to be accurate and reliable, however Amplicon Liveline Limited accepts no responsibility for any problems caused by errors or omissions. Specifications and instructions are subject to change without notice.
-
Page 2: Declaration Of Conformity
HOLLINGDEAN ROAD BRIGHTON BN2 4AW UK We declare that the product(s) described in this Instruction Manual are manufactured by Amplicon Liveline Limited and perform in conformity with the following standards or standardisation documents: Electro Magnetic Compatibility (EMC): EMC Directive 89/336/EEC... -
Page 3: Table Of Contents
Enhanced Features......................1 1.3.2 The Software........................1 What the Package Contains...................... 2 The Amplicon Warranty Covering the PCI236 ................2 Contacting Amplicon Liveline Limited for Support or Service............ 2 1.6.1 Technical Support ......................2 1.6.2 Repairs..........................3 GETTING STARTED........................4 General Information........................ - Page 4 FIGURE B.3 PCI236 CIRCUIT DIAGRAM (SHEET 2) ................. 21 PCI236...
-
Page 5: Introduction
When a large scale system is required, multiple boards can be added from the 200 Series without conflict. For analog input systems, the capacity of the PC mounted hardware can be extended by external expansion panels to provide a convenient to use system with low cost per channel and maintained high performance. -
Page 6: What The Package Contains
This product is covered by the warranty as detailed in the Terms and Conditions stated in the current domestic or international Amplicon Liveline catalogue. Contacting Amplicon Liveline Limited for Support or Service The PCI236 boards are designed and manufactured by Amplicon Liveline Ltd and maintenance is available throughout the supported life of the product. 1.6.1... -
Page 7: Repairs
Please mark the RMA number on the outside of the packaging to ensure that the package is accepted by the Goods Inwards Department. Address repairs to: Customer Services Department AMPLICON LIVELINE LIMITED Centenary Industrial Estate Brighton, East Sussex BN2 4AW... -
Page 8: Getting Started
GETTING STARTED General Information The PCI236 cards are Plug and Play compatible and come complete with all the software required to install and operate the card in any PCI version 2.1 compliant host PC running under Windows NT, 95, 98, Me & 2000 and allow full card functionality. Host Computer Requirements When installing one or more PCI236 series boards, ensure that the host computer has sufficient capacity. -
Page 9: Software Installation
Software Installation Please refer to the ADIO software manual, ampdio32manual.pdf, for the latest Windows 32-bit driver installation information. 2.4.1 Windows 95/98/Me Installation The Windows 95 drivers supplied with this card are compatible with installation and operation under Windows 98 and Windows Me. To install the drivers under Windows 95: 1. -
Page 10: Windows Nt4.0 Installation
2.4.2 Windows NT4.0 Installation Please ensure that PLUG n PLAY OS (or equivalent) option on the BIOS settings screen is set to NO or OFF. The driver is installed as part of the set-up process for the remaining software. 1. To install the example software, rerun Amplicon Softman CD and select the 'Access your manual and software' button, and then double click on the '32 bit' software button for the PCI236. -
Page 11: Application Software
Application Software Example application software, including source code for the applications and the DLL are supplied in the self-extracting archive AMPDIO.EXE along with the SETUP program. When the self-extracting archive is run and software is extracted to a suitable directory (e.g. C:\AMPLICON\AMPDIO), the examples and DLL source code can be found in subdirectories off this directory. -
Page 12: Verifying Installation For Windows 2000
(c) Look down the list for the device called ‘AmpDIO’ and verify that its status is ‘Started’. To verify that the driver has recognised the card: (a) Open the Control Panel, e.g. via ‘Start’ -> ‘Settings’ -> ‘Control Panel’. (b) Double click the ‘Amplicon DIO’ icon (or open it from the Control Panel’s File menu). (c) Select each of the ‘DIOn’... -
Page 13: Digital I/O
Digital I/O This digital I/O board features an uncommitted 82C55 CMOS Programmable Peripheral Interface (PPI) which can be configured in a variety of operating modes. The operational mode for each port is established by writing to the control register of the 82C55. This control word also establishes whether the port is configured to operate as input, output or bi-directional. -
Page 14: Digital I/O Conditions
Digital I/O Conditions The digital I/O lines on ports A, B and C are TTL compatible. When an input line is left open circuit, its high input impedance makes it susceptible to static charge and interference and the state may be indeterminate. Ensure that signals to any inputs are within the above limits, and that any unused input lines are grounded or masked out in software. -
Page 15: 2.10 Digital I/O Connections
• High current output • Resistor capacitor filtered input • Schmitt input • Opto-isolated input • Opto-isolated output 2.10 Digital I/O Connections The three ports of the PPI are all terminated on the rear 37 way D type connector PL1, and use pin 37 for the digital ground connection. -
Page 16: 2.11.1 Ier Interrupts Enable / Status Register
2.11.1 IER Interrupts Enable / Status Register This is a read and write register. When written to, it is an interrupt enable / mask register. PPI C bit 3 int enable PPI C bit 3 int polarity PPI C bit 3 int status Reserved PCI Global Int enable Reserved... -
Page 17: Electrical Connections
ELECTRICAL CONNECTIONS This chapter describes the signal and control connections that the user must make between the PCI236 and any external devices. These I/O connections are made through the D-type connector protruding from the PC adapter slot corresponding to the chosen board position. The metal shell connected to the local PC chassis ground. -
Page 18: Voltage Outputs Available On Pl1
Voltage Outputs Available on PL1 In addition to the 24 digital I/O lines, the PC voltage rails are brought out on PL1, the I/O connector. These rails are +5, +12 and -12 VDC. No more than 1.0 A should be drawn from the +5 V rail and no more than 100 mA from either of the other rails. -
Page 19: Programming The Pci236
PCI236 to incorporate any part of the Amplicon copyright software into related application programs, and to use, resell or otherwise distribute such application programs for operation with PCI236 hardware purchased from Amplicon Liveline Limited. Guide to User Programming When developing an application specific program, it is advised that the supplied driver and dynamic link library functions be used for 32-bit Windows applications. -
Page 20: Interfacing With Commercial Software Packages
Interfacing with Commercial Software Packages The supplied software examples are not intended to be stand alone applications programs, other than for demonstration and test purposes. To meet most user requirements, either a dedicated program must be written using the functions and examples provided or the PCI236 can be interfaced to a commercial applications package. -
Page 21: Technical Specifications
APPENDICES A. TECHNICAL SPECIFICATIONS A.1. Electrical Specification Digital I/O Ports 24 I/O lines arrange as three 8 bit ports (A, B and C). Programmable as two groups of 12 bits (group A, group B) and used in three modes of operation. Each Control block (Group A and Group B) accepts "commands"... -
Page 22: Environmental Conditions
A.3. Environmental Conditions Environment The PCI236 is designed to operate in a PC/AT environment. Particular attention is paid at the design stage to minimise emission of noise and susceptibility to external radiated noise. Specific conditions I/O Positions Required One PCI bus version 2.1 I/O adapter slot with room for half- length card. -
Page 23: Circuit Layout And Schematic Drawings
B. CIRCUIT LAYOUT AND SCHEMATIC DRAWINGS Full circuit diagrams and layout drawings of the PCI236 are given in this appendix. B.1. ASSEMBLY DETAIL FIGURE B.1 PRINTED CIRCUIT LAYOUT Page 19 PCI236... -
Page 24: Figure B.2 Pci236 Circuit Diagram (Sheet1)
FIGURE B.2 PCI236 CIRCUIT DIAGRAM (SHEET1) Page 20 PCI236... - Page 25 FIGURE B.3 PCI236 CIRCUIT DIAGRAM (SHEET 2) Page 21 PCI236...
