Affirmed by
BS EN ISO 9001
Declaration of Conformity
Certificate No. FM 15094
Amplicon products are designed and manufactured in the United Kingdom under a
quality system approved by the British Standards Institution
P C I 2 6 3
16 CHANNEL
REED
RELAY
OUTPUT
BOARD
This Instruction Manual is supplied with the PCI263 board to provide the user with sufficient information to properly
utilise the product as purchased. The information contained has been reviewed and is believed to be accurate and
reliable, however Amplicon Liveline Limited accepts no responsibility for any problems caused by errors or
omissions. Specifications and instructions are subject to change without notice.
PCI263 Instruction Manual Part Nº 860 038 44 Issue A2
© Amplicon Liveline Limited
Prepared by N.Stubbs
Approved for issue by A.S. Gorbold, Operations Director
PCI263
Advertisement
Table of Contents
Related Manuals for Amplicon Liveline 200 Series
Summary of Contents for Amplicon Liveline 200 Series
- Page 1 The information contained has been reviewed and is believed to be accurate and reliable, however Amplicon Liveline Limited accepts no responsibility for any problems caused by errors or omissions. Specifications and instructions are subject to change without notice.
-
Page 2: Declaration Of Conformity
HOLLINGDEAN ROAD BRIGHTON BN2 4AW UK We declare that the product(s) described in this Instruction Manual are manufactured by Amplicon Liveline Limited and perform in conformity with the following standards or standardisation documents: Electro Magnetic Compatibility (EMC): EMC Directive 89/336/EEC... -
Page 3: Table Of Contents
General Description........................1 1.3.1 The Software........................1 What the Package Contains...................... 2 The Amplicon Warranty Covering the PCI263 ................2 Contacting Amplicon Liveline Limited for Support or Service............ 2 1.6.1 Technical Support ......................2 1.6.2 Repairs..........................3 GETTING STARTED........................4 General Information........................ - Page 4 B. CIRCUIT LAYOUT AND SCHEMATIC DRAWINGS ..............19 TABLE OF FIGURES FIGURE 3.1 37 WAY D-TYPE CONNECTOR (SK1 - USER OUTPUT) ..........10 FIGURE 4.1 PCI263 REGISTER ASSIGNMENTS ................14 FIGURE B.1 PRINTED CIRCUIT LAYOUT ..................19 FIGURE B.2 PCI263 CIRCUIT DIAGRAM (SHEET1) ................20 FIGURE B.3 PCI263 CIRCUIT DIAGRAM (SHEET 2) .................
-
Page 5: Introduction
When a large-scale system is required, multiple boards can be added from the 200 Series without conflict. For analog input systems, the capacity of the PC mounted hardware can be extended by external expansion panels to provide a convenient to use system with low cost per channel and maintained high performance. -
Page 6: What The Package Contains
This product is covered by the warranty as detailed in the Terms and Conditions stated in the current domestic or international Amplicon Liveline catalogue. Contacting Amplicon Liveline Limited for Support or Service The PCI263 boards are designed and manufactured by Amplicon Liveline Ltd and maintenance is available throughout the supported life of the product. 1.6.1... -
Page 7: Repairs
Please mark the RMA number on the outside of the packaging to ensure that the package is accepted by the Goods Inwards Department. Address repairs to: Customer Services Department AMPLICON LIVELINE LIMITED Centenary Industrial Estate Brighton, East Sussex BN2 4AW... -
Page 8: Getting Started
GETTING STARTED General Information The PCI263 cards is Plug and Play compatible and comes complete with all the software required to install and operate the card in any PCI version 2.1 compliant host PC running under Windows NT, 95, 98, Me & 2000 and allow full card functionality. Host Computer Requirements When installing one or more PCI263 series boards, ensure that the host computer has sufficient capacity. -
Page 9: Software Installation
Software Installation Please refer to the ADIO software manual, ampdio32manual.pdf, for the latest Windows 32-bit driver installation information. 2.4.1 Windows 95/98/Me Installation The Windows 95 drivers supplied with this card are compatible with installation and operation under Windows 98 and Windows Me. To install the drivers under Windows 95: 1. -
Page 10: Windows Nt4.0 Installation
2.4.2 Windows NT4.0 Installation Please ensure that PLUG n PLAY OS (or equivalent) option on the BIOS settings screen is set to NO or OFF. The driver is installed as part of the set-up process for the remaining software. 1. To install the example software, rerun Amplicon Softman CD and select the 'Access your manual and software' button, and then double click on the '32 bit' software button for the PCI236. -
Page 11: Application Software
Application Software Example application software, including source code for the applications and the DLL are supplied in the self-extracting archive AMPDIO.EXE along with the SETUP program. When the self-extracting archive is run and software is extracted to a suitable directory (e.g. C:\AMPLICON\AMPDIO), the examples and DLL source code can be found in subdirectories off this directory. -
Page 12: Verifying Installation For Windows 2000
(a) Open the Control Panel, e.g. via ‘Start’ -> ‘Settings’ -> ‘Control Panel’. (b) Double click the ‘Devices’ icon (or open it from the Control Panel’s File menu). (c) Look down the list for the device called ‘AmpDIO’ and verify that its status is ‘Started’. To verify that the driver has recognised the card: (a) Open the Control Panel, e.g. -
Page 13: The Pci Interface
The PCI Interface The PCI263 is a PCI bus slave card. Communication between the host PC and the PCI263 board is via the PCI bus. This bus provides data, address, and control lines together with the power supply for the PCI263. The PCI263 is allocated one Base Address (BA) in the available I/O space. -
Page 14: Electrical Connections
ELECTRICAL CONNECTIONS This chapter describes the signal and control connections that the user must make between the PCI263 and any external devices. These output connections are made through the D-type connector protruding from the PC adapter slot corresponding to the chosen board position. The metal shell is connected to the local PC chassis ground. -
Page 15: Voltage Outputs Available On Sk1
Voltage Outputs Available on SK1 In addition to the 16 Reed relay contact pairs, the +5VDC PC voltage rail is brought out on SK1 pin 36 with the ground return on pin 37. No more than 100 mA should be drawn from the +5 V rail. -
Page 16: Use Of Shielded Cables
Use of Shielded Cables Pins 1, 18 and 19 of SK1 are connected to the host PC chassis and may be connected to protective ground or a cable overall screen in order to reduce interference problems. A shielded 1 metre cable is available. However if the user manufactures custom cables for use in a severe or noisy environment, it may be considered advisable to use overall shielded cables. -
Page 17: Using The Pci263
USING THE PCI263 This chapter and gives notes for users of the PCI263. The PCI263 is a PCI bus version of the PC263 and is functionally equivalent to it. The differences are in how the software accesses the card. For the PCI263, the AMPDIO software gives access to all the functions of the card and is covered in the programming section of the manual. -
Page 18: The Led Indicators
port or by a software reference to the previously written data. A new byte must then be written that contains the previous states plus the change(s). The table in figure 4.6 details the relationship between the ports, the port addresses, the bits, the relays, the LED indicators and the output connections. -
Page 19: Programming The Pci263
PCI236 to incorporate any part of the Amplicon copyright software into related application programs, and to use, resell or otherwise distribute such application programs for operation with PCI236 hardware purchased from Amplicon Liveline Limited. Guide to User Programming When developing an application specific program, it is advised that the supplied driver and dynamic link library functions be used for 32-bit Windows applications. -
Page 20: Notes For Users Of The Pc263
Notes for Users of the PC263 The PCI263 is a PCI bus compatible replacement for the PC263 ISA Reed Relay card. Where the PCI263 is used in systems previously using the PC263, the user should note the following. Base Address The I/O Base address are assigned by the PC plug and play BIOS, rather than being set by jumpers. -
Page 21: Technical Specifications
APPENDICES A. TECHNICAL SPECIFICATIONS Electrical Specification DGITAL OUTPUT Data Bit Configuration 16 individual reed relays, each allocated to a single data bit with the 16 bit data word configured as two separately addressable bytes: Low byte at even I/O locations (Base Address). Bits 0 to 7 directly map onto relays RL1 to RL8 High byte at odd I/O locations (Base Address + 1) Bits 0 to 7 directly map onto relays RL9 to RL16... -
Page 22: Software Specification
Software Specification The distribution software is supplied on a CD-ROM. Windows NT 4.0, 2000 & 95/98/Me Driver Software provides Application level access to all the advanced features of the card from these operating systems. Environmental Conditions Environment The PCI263 is designed to operate in a PC/AT environment. Particular attention is paid at the design stage to minimize emission of noise and susceptibility to external radiated noise. -
Page 23: Circuit Layout And Schematic Drawings
B. CIRCUIT LAYOUT AND SCHEMATIC DRAWINGS Full circuit diagrams and layout drawings of the PCI263 are given in this appendix. B.1. ASSEMBLY DETAIL FIGURE B.1 PRINTED CIRCUIT LAYOUT PCI263 page 19... -
Page 24: Figure B.2 Pci263 Circuit Diagram (Sheet1)
FIGURE B.2 PCI263 CIRCUIT DIAGRAM (SHEET1) Page 20 PCI236... -
Page 25: Figure B.3 Pci263 Circuit Diagram (Sheet 2)
FIGURE B.3 PCI263 CIRCUIT DIAGRAM (SHEET 2) Page 21 PCI236...
