RLE Technologies SeaHawk SD User Manual page 2

Technical Specifications
Power
Outputs
Solid State
Relay
Leader Cable (Non-Sensing)
Length
Connector
Operating Environment
Temperature
Humidity
Altitude
Storage Environment
Dimensions
Weight
Figure 2: Wiring to Falcon
N/A
12-36VAC @ 0.01A min., 0.1A max.;
18-36VDC @ 0.01A min., 0.1A max.
N/A
14' (4.27m)
N/A
32° to122°F (0° to 50°C)
5% to 95% RH, non-condensing
10,000' (3,048m) max.
-4°to158°F (-20° to 70°C)
2.0"W x 2.75"H x 3.5"D
(51mmW x 70mmH x 88mmD)
6 oz. (170g)
Figure 3: Wiring to RASP6
110031 Rev 1.0 (04/2006)
