All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR, Inc. assumes no responsibility for any inaccuracies or errors that may appear in this document.
Table of Contents Package Contents Features System Requirements Introduction Hardware Setup Software Installation Software Configuration Web Administration Technical Support Limited Warranty...
Package Contents This package contains: • 1 USB Multi-Function Print Server • 1 CAT5 patch cable • 1 User manual • 1 Installation CD • 1 Warranty/registration card • 1 Power adapter * If any items are damaged or missing, please contact your dealer.
Features • Allows multiple users to share a Multi-Function Printer (MFP) over the network to Print, Scan, and Fax from any networked computer •Print text documents and color photos without compromising quality •Fax documents over the network and at the convenience of your desk without the clutter •Scan documents or photos in high-resolution color format •One USB port compliant with USB 1.1 specification •One network port for support of 10/100Base-T networks...
Introduction IOGEAR’s palm-sized USB Multi-Function Print Server allows any networked computer to share a USB Multi-Function Printer (MFP). This multi-function server goes a step beyond ordinary print servers by allowing multiple network users to Print, Scan, and Fax using the same Multi-Function Printer. This elimi- nates the need to purchase multiple expensive MFPs as all you need to share the printer is a connection to the print server’s network port.
Hardware Setup Hardware Setup 1) Plug the included power adapter into the print server and a power outlet near the multifunction printer. 2) Plug the network port of the print server into a network switch or available LAN port on a router using standard Ethernet patch cable.
Software Installation Software Installation (repeat on each networked computer) 1) Insert the Setup CD into your computer. 2) Click the Installation button on the window that opens.
Page 11
Software Installation 3) Choose a language to use for installation and click OK.
Page 12
Software Installation 4) Click Next at the first screen of the setup wizard.
Page 13
Software Installation 5) Choose a folder to install the print server software or just click Next.
Page 14
Software Installation 6) Choose a folder in the start menu to launch the software from or just click Next.
Page 15
Software Installation 7) On Windows XP, a window may come up warning you that this software has not been tested by Microsoft and certified by their Windows Logo program. If so, simply click Continue Anyway to continue with installation.
Page 16
Software Installation 8) When the installation is complete, click OK.
Page 17
Software Installation 9) If you would like the print server software to run automatically when starting your computer (recom mended), leave the box checked and click Finish.
Page 18
Software Installation On Windows XP systems, the Found New Hardware wizard may pop up during installation. You will need to do the following to complete the driver installation: 1) If asked if Windows can connect to the internet to search for software, click the No, not this time option and then click Next.
Page 19
Software Installation 2) When asked how the wizard should install software, leave Install the software automatically selected and click Next.
Page 20
Software Installation 3) If you see another warning that the software has not been Windows Logo certified by Microsoft, click Continue Anyway.
Page 21
Software Installation 4) Click Finish to complete the Found New Hardware wizard.
Software Configuration Software Configuration (repeat on each networked computer) 1) Launch the IOGear MFP Utility program from the start menu or icon on the desktop.
Page 23
Software Configuration 2) If you have Windows XP and the Windows Firewall is enabled you will see this window pop up when the Utility is first launched. Make sure you click the Unblock button to allow communication with the print server. Other software firewalls may display similar options – make sure the print server software is allowed to bypass such programs.
Page 24
Software Configuration 3) The Utility will search your network for the print server and display it in the window. If no print server is found please make sure any third party firewalls such as Norton Internet Security, McAfee Personal Firewall, or ZoneAlarm have been disabled or bypassed and click the Search button to try again.
Page 25
Software Configuration 4) If your printer software has already been installed, skip ahead to step 7. Otherwise, once the print server has been found, close the window with the X button in the top right corner (NOT the one labeled Exit) to hide the Utility for now.
Page 26
Software Configuration 5) Install the software that came with your printer. When the drivers for the printer have finished installing OR the software asks you to plug in the printer using a USB cable, you are ready to “connect” the device.
Page 27
Software Configuration 6) You should see a small USB icon like this in the tray in the lower right corner of your screen. Double-click on the icon to open the Utility window again.
Page 28
Software Configuration 7) Click the plus in front of the print server name to show the name of the attached printer. Then select the printer name and click the Connect button in the Utility.
Page 29
Software Configuration 8) The printer should be detected as if it was plugged directly into the computer. Finish any remaining setup needed by the printer software. Your multifunction printer should be ready to use.
Page 30
Software Configuration 9) If you would like the connection to this printer to be restored automatically when the Utility software launches, you will need to add the device to your favorites list. Click the plus in front of Connected devices and right-click the name of the printer. Choose Add to favorites from the menu that pops up.
Page 31
Software Configuration 10) Click OK to confirm that the printer is in your favorites list.
Page 32
Software Configuration 11) Once you have connected to the print server you can close the Utility window. Be sure to use the close box with an X in the top right corner so that the Utility continues to run in the background. The large button labeled Exit will shut down the Utility and disconnect your computer from the printer.
Web Administration Web Administration (advanced options) Normally you will not need to change the name or IP address used by the print server. However, if you have multiple print servers or want to override these default settings for another reason, you may do so using the Web Administration tool.
Page 34
Web Administration Changing the print server name The default name may not be convenient if you have multiple print servers. If you would like to change the print server’s name to something more meaningful such as “Front Office” or “Accounting Scanner” you can do so with the Web Admin tool.
Page 35
Web Administration Protecting the Admin tool with a password If you would like to prevent unauthorized access to the Admin tool, you can establish a password from the same System tab of the Setup section shown above. Type in your password twice to confirm it, then click Save &...
Page 36
Web Administration Changing the IP address Normally the server requests an IP address automatically from your router or other DHCP server on the network. If you would prefer to specify an address, you can do so by clicking the Setup button, then on the TCP/IP tab.
Page 37
Web Administration Restoring factory default settings If you would like to restore all settings on the print server to their original configuration and can still access the Web Admin tool, simply click on the Misc button and make sure the Factory Default tab is selected.
Page 38
If you are experiencing any compatibility issues please check the Support section of the IOGEAR website at http://www.iogear.com for firmware upgrade files. Download the latest version to your computer and make sure that you unzip it if necessary. The file name should end in “.BIN”...
Page 39
Web Administration Click the Browse button and you will be asked to locate the firmware upgrade file you just downloaded. Select it and click Open.
Page 40
Web Administration You will see the location you selected in the box next to the Browse button. Click the button at the bottom labeled Firmware Upgrade to load the new firmware onto the server.
Technical Support If you need technical support, please check out our IOGEAR Tech Info Library (T.I.L.) at www.iogear.com/support for the latest tips, tricks, and troubleshooting. The IOGEAR T.I.L. was designed to provide you with the latest technical information about our products. Most of the answers to your ques- tions can be found here, so please try it out before contacting technical support.
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCI- DENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchant- ability, or fitness for any particular purpose.
