User Manual
Front
98 mm
1. Welcome
2. Hardware Requirements
To access FireWire® or USB 2.0 speeds, the computer system must be FireWire®
Thank you for purchasing IOGEAR's
®
ION™ Drive featuring TRI-Select Backup
and/or Hi-Speed USB 2.0 enabled. The Tri-Select ION™ Drive will work at
Technology, one of the fastest Hi-Speed external Hard Drives on the market.
®
FireWire® 400 and/or USB 1.1 speeds with FireWire® enabled and/or USB 1.1
IOGEAR
only manufactures high quality storage devices, so we are sure you will be
®
enabled computers.
satisfied with your purchase. IOGEAR
is dedicated to customer service and
satisfaction, and wishes you the best with your new TRI-Select ION™ drive.
For Mac Users
Once again, IOGEAR
®
brings the cutting-edge technology of today and tomorrow to
• Mac OS X (10.2) or greater
your Macintosh or PC.
• Available FireWire port
• Available USB 2.0 or 1.1 port
Note:
Your order has been carefully packaged and inspected, and we hope you are
For PC Users
pleased with the IOGEAR product you purchased. Please inspect the contents of the
package to ensure that you have received all items and that nothing has been
• PC Compatible, 200MHz or greater
damaged. If you discover a problem, please contact your dealer immediately for
• Windows® 98SE*, ME*, 2000, XP
120 mm
assistance
• Minimum 64MB RAM
• Available Hi-Speed USB 2.0, 1.1 port or FireWire port
• CD-ROM drive
Contact Information:
949-453-8782
23 Hubble
Irvine, CA 92618
USA
*Drivers are provided by the supporting OS or host card software.
www.iogear.com
FireWire 400 - Mac OS X(10.2) or greater, Windows 98SE, ME, 2000 & XP
support@iogear.com
USB 2.0 - Mac OS X (10.2) or greater, Windows 2000 & XP
USB 1.1 - Mac OS X(10.2)or greater, Windows 2000 & XP
WARNING!
Accessories / Additional Products
Your IOGEAR ION™ Drive is ESD sensitive, and can be damaged by static electricity! Please
8-in-1 Hi-Speed USB 2.0 Memory Bank™(GFR280)
follow proper and safe ESD handling procedures when connecting the ION™ Drive to your
KVMP™ Extreme Switch – 2 and 4 port USB PS/2 KVMP™ switch (GCS1732/34)
computer.
BOSS™, Router, FTP Server, NAS, VPN end point (GNS1000)
Please visit
http://www.esda.org
for information about Electro-Static Discharge.
Back
Step. 4
8. TRI-Select Button Setup w/Dantz Retrospect
Finally you can click [Finish] to
Button 1 (Mac & PC)
complete the setup or you can click
To begin setting up the square (top) button on your TRI-Select ION Drive simply press
[Start Now] to complete the setup
the button on the drive. At this point Retrospect Express should launch and begin the
and begin the backup now.
backup set tutorial, to begin click [Next].
Otherwise you can initiate backup
by pressing the button.
Step. 1
Choose the volume you want to
Buttons 2 & 3 (PC)
backup from, and click [NEXT]
To begin setting up the next two buttons, launch Dantz Retrospect from your
to continue
Programs Folder in your Start menu.
1
Step. 1
Step. 2
First click on the new script icon 1
Choose what you want backed up,
in the upper left of the tool bar,
backing up your "Documents only"
then choose what kind of backup
will backup all the documents in your
script you would like to make. Your
hard drive. Choosing "Entire volume"
choices are "Backup", "Duplicate"
will backup you entire hard drive.
or "Archive". Then Retrospect will
When you have chosen click [Next] to
ask you to name your script, do so
continue.
and click [NEW].
Step. 2
Step. 3
Then it will prompt you to choose
Choose your appropriate TRI-Select
your Source(s) and Destination.
ION Drive as the destination. Once
Click on [Sources] to begin.
you have chosen click [Next] to
continue.
3. Features
4. Pictorial Introduction
If you purchased an enclosure without a pre-installed Hard Drive please see page
• Transfer or backup pictures, music, and data at speeds up to 480 Mbps
Front View
10 in the manual on the CD on installing your hard drive.
– Transfer 1 GB in under 30 seconds
1. The IOGEAR® Logo - a mark of quality.
2. Tri-Select Backup Buttons
• 3-Button Backup Solution that automates backups with Dantz
2
Retrospect Backup software
1
• Ideal for backup, storage expansion, file sharing, software installation,
and data management
• 3 connectivity solutions in one (FireWire® 400, USB 2.0, and USB 1.1)
• Hot-plug capable, hot swappable, and Plug-N-Play
Step. 1
• Preformatted for your convenience so you are up and running in no
Back View
time (for those with preinstalled drives)
Plug the FireWire 6 pin connector into the
1. USB 2.0 Type B Port (female)
back of the ION™ Drive.
• FireWire® interface supports data transfer rates of up to 400 Mbps
2. FireWire 6-pin Ports (female)
3. Power Switch
Step. 2
• USB 2.0 interface – supporting high speed data transfer rates of up to
4. Power Port
1
480 Mbps
5. Lock Port
2
Plug the Power Adapter into the back of the
6. Stand (optional, screws included)
ION™ Drive (you must connect the power
• One-year limited warranty
3
adapter in order to utilize the drive).
ON / OFF
4
5
POWER
6
Step. 3
Step. 6
Step. 9
Your source is the folder and files you
Choose an encryption type, you
If you wish, you can click the
want backed up. When you are finished
can choose from None,
[Selecting...] button to filter what
selecting everything you want to backup
Password only and
kind of files are backed up. By
then click [OK].
SimpleCrypt. Encryption will
default, Retrospect will backup "All
protect your data so only you
Files" from your specified
can recover it as needed. Click
destination. Once satisfied with
[Next] to continue.
your backup, just click on the Run &
Save 1 icon at the top.
Step. 4
Step. 10
Step. 7
Click on [Destinations] and it will
Now choose Make a "run
prompt you to choose your
Either use the default location for
document" from the choices and
destinations(s). For your first
your Disk Backup Set or click
click [Save...]. Retrospect will
script you will have to click [Creat
[Browse...] to choose your own.
then prompt you to save the
New] to add a destination option.
Click [Next] to continue when you are
script in your desired location.
It will then ask what type of media
ready. Then click [Finish] on the next
Please choose your desired
you want to back up to, to backup
screen to complete your Disk Backup
location and save the script.
your ION Drive choose "Disk",
Set.
click [Next] to continue.
Now that you've finished your script you can choose to run it from one of the buttons
Step. 8
on your TRI-Select ION Drive. To do so, open up the TRI-Select Button Management
Software and decide which button you want to run your script from. Then click on the
Step. 5
appropriate folder icon to pick the script from the location you saved it to. Once you
Now choose your Disk Backup Set
have selected the script as the launch item for a specific button you will be able to run
from in the window and click [OK].
Name your Disk Backup Set and click
that backup script any time you want to by pressing that button on the drive.
the [Select...] button to choose a disk
as your destination, click [OK] after you
To setup another script go back to the beginning of Dantz Retrospect Setup.
have selected your disk, then [Next] to
For more information, advanced techniques and other uses of Dantz Retrospect
continue.
Express refer to the Manual in the Dantz Retrospect folder which is located in your
Program Files folder.
Step. 3
5. ION™ Drive Setup
Plug the FireWire® 6 pin connector into your computer's
FireWire Port.
Step. 1
Note: if your computer has a 4 pin
Firewire Installation
FireWire® or iLink® connection please use
Plug the USB Type B connector into
a FireWire 4 pin(m) to 6 pin(m) cable.
(It is not necessary to install a driver for FireWire under any OS, however
IOGEAR part# G2L13946-6; or you may
the back of the ION™ Drive.
please make sure your computer has all of the latest updates, critical
updates, service packs, service releases, OS patches, security updates,
pick one up at any local electronics store
or catalog reseller.
and all other OS updates provided by the respective developers.)
Step. 2
3
Note: Before you begin, please make sure that the power to the device
Plug the Power Adapter into the back
and your computer has been turned off.
Step. 4
of the ION™ Drive (you must connect
the power adapter in order to utilize
Plug the power adapter into a
the drive).
surge protector.
Step. 3
4
Step. 5
Plug the USB Type A connector into your
computer's USB 2.0 Port.
Once complete, turn the ION™
1
Drive and your computer on.
Step. 4
Your computer will automatically
identify the ION™ Drive and
ON / OFF
2
load all necessary drivers.
Plug the power adapter into a surge
POWER
protector.
your computer on. Your computer will automatically
identify the ION™ Drive and load all the necessary
drivers.
1
Buttons 2 & 3 (Mac)
Step. 4
Step. 1
Then name your backup set and click
[New...] to continue. Then choose the
Go to the Automate tab in the
location, make sure to choose the Tri-
Retrospect Express Directory window
Select ION drive as the location and
and click on the EasyScript button.
click [Save] to continue.
Step. 5
Step. 2
In the next window EasyScript will
announce that you are finished.
Then you will see the Welcome to
Please click on the [Open Script]
EasyScript window, please click [Next]
button to continue. Then it will open
to continue. EasyScript will ask to you
the main script window that will allow
select your type of media, to backup
you to verify all the settings.
to your Tri-Select ION drive please
select "File backup set (hard disk)"
from the list and click [Next] to
continue.
Step. 6
The [Sources] button will allow to modify
Step. 3
the data that is backed up. The
[Destinations] button should not need to be
The next window will ask you what
changed, but it determines where the data
frequency you want the backup to
will be backed up. The [Selecting] button
happen, choose Once a week and
will allow you to filter the types of files you
click [Next] to continue. Then in the
want to backup from your location. The
next window choose a time for the
[Options] button lets you choose whether you want your data verified and
script to run and click [Create...] to
compressed or not. The [Schedule] button tells you when the script is scheduled to
continue.
run. If you do not want the script to run on a schedule please press the [Schedule]
button and delete the schedules in the next window. The script window should look
something like this when you are done.
Hi-Speed USB 2.0 Installation
6. Installation of ION™ Drive Software (PC)
7. Dantz Retrospect Express & Tri-Select
Button Management Software
Note: Before you begin, please make sure that the power to the
device and your computer has been turned off.
For Windows® 98SE Users Only
Step. 1
Dantz Retrospect Express and the TRI-Select Button Management Software work
together to provide you with up to three backup options (per drive) at the touch of a
Inserting the CD will launch the software
button. The TRI-Select Button Management Software connects your drive and its
installer. Clicking on the first button will
buttons with Dantz Retrospect Express. This section will take you through the
copy the installer of the driver to your
installation and setup of both the TRI-Select Button Management Software and
internal hard drive.
Dantz Retrospect Express, once you have finished you should have three full backup
scripts setup and ready to go.
1
Installation (PC)
From the Software CD installer click on the appropriate buttons to install Dantz
Step. 2
Retrospect Express and the TRI-Select Button Management Software separately.
ON / OFF
Each will launch and installer that will step you through the process. Please install
2
The installer will be copied into
POWER
the Dantz software and the TRI-Select software, once complete please restart your
"C:\IOGEAR GHD335C". Double-click
computer.
on the installer icon to begin the driver
install.
Once your computer has restarted you should find an
IOGEAR icon
1
using the TRI-Select Button Management Software.
Step. 3
Installation (Mac)
3
On this CD you will find two folders. Inside
Click [Next] to begin the install.
the Dantz Retrospect Express folder you will
need to choose from your appropriate
language and launch the installer. Inside the
TRI-Select folder simply run the installer and
Step. 4
then restart your computer.
The next screen will ask you to click
Once complete, turn on ION™ Drive and
After your computer restarts you can begin
[Finish] to end the wizard. After the wizard
using the TRI-Select Button Management
has quit you simply need to connect the
Software. You will find it in your application
ION Drive to the computer and the driver
folder.
will be loaded for the drive.
Step. 7
Radio & TV Interference Statement
Finally, in the menu bar go to "Script"
and select "Save and Run...", in the
WARNING!!! This equipment generates, uses and can radiate radio frequency
window that opens chose "Make a
energy and, if not installed and used in accordance with the instruction manual, may
run document" and click [Save...]
cause interference to radio communications. This equipment has been tested and
and choose the location for the script
found to comply with the limits for a Class B computing device pursuant to Subpart J
to be saved.
of Part 15 of FCC Rules, which are designed to provide reasonable protection
against such interference when operated in a commercial environment. Operation of
Now that you've finished your script you can choose to run it from one of the buttons
this equipment in a residential area is likely to cause interference, in which case the
on your TRI-Select ION Drive. To do so, open up the TRI-Select Button Management
user at his own expense will be required to take whatever measures may be required
Software and decide which button you want to run your script from. Then click on the
to correct the interference.
appropriate folder icon to pick the script from the location you saved it to. Once you
have selected the script as the launch item for a specific button you will be able to run
that backup script any time you want to by pressing that button on the drive.
To setup another script go back to the beginning of Dantz Retrospect Setup.
For more information, advanced techniques and other uses of Dantz Retrospect
Limited Warranty
Express refer to the Manual in the Dantz Retrospect folder which is located in your
Applications folder.
N NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY FOR DIRECT,
INDIRECT, SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE
PRODUCT, DISK, OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE
PRODUCT.
The direct vendor makes no warranty or representation, expressed, implied, or
statutory with respect to the contents or use of this documentation, and especially
disclaims its quality, performance, merchantability, or fitness for any particular
purpose.
The direct vendor also reserves the right to revise or update the device or
documentation without obligation to notify any individual or entity of such revisions, or
updates. For further inquires please contact your direct vendor.
TRI-Select Button Management Software Introduction
The TRI-Select Button Management Software allows you to configure each button for
your custom backup sets as you wish. The Button Management Software identifies
each disk for you by drive letter
1
and serial number
2
. When selected the drive letter
and serial number are red and you can begin configuring the buttons. Each button is
3
identified by the shape that appears on it. The top button is the square
, the middle
4
5
button is the circle
and the bottom button is the triangle
.
6
In the software you will see a box
next to each shape, this is where the path to the
selected backup script will be displayed. To choose a backup script for that button you
want to click on the folder icon
7
below its box. If you ever decide you no longer want
that button active simply click the red X
8
next to the folder icon and it will clear the box
of your selected path.
Whenever you have a drive connected you want the TRI-Select Button Management
Software active so be sure to minimize rather than close it whenever you are done
using it. If you connect a new drive and want to configure its buttons be sure to click
the Refresh button
9
and the software will scan for all new drives and list them as it
finds them.
1
in your systray, click on it to begin
6
3
1
2
8
7
4
5
9
The TRI-Select Button Management Software in your start menu under Programs.
On a Mac, there will be a TRI-Select folder installed into your Applications folder.
3.5" Tri-Select™ COMBO ION™ Drive
High-Speed External Hard Drive
Featuring Dantz Retrospect Backup Software
Quick Start Guide (3.5" FireWire / USB 2.0 Tri-Select Backup ION™ Series)
Read this guide thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit and/or any of the
devices it connects to.
Please refer to the electronic manual on the IOGEAR CD for further
instructions on your new ION™ Drive.
Package contains:
1 - 3.5" ION™ Drive featuring TRI-Select Backup Technology
1 - Base (with screws)
1 - Hi-Speed USB 2.0 (Type A to Type B) Cable
1 - FireWire® (6 pin – 6 pin) cable
1 - Power Adapter
1 - Power cable
1 - Quick Start Guide
1 - IOGEAR® Installation CD with Electronic Manual
1 - Warranty / Registration Card
Copyright © 2004 IOGEAR
All brand names and trademarks
are the registered property of their
respective owners
PKG-M0061/QS
Advertisement
