WWW.MOBILE-SIGNAL-BOOSTERS.SHOP
MOBILE SIGNAL BOOSTER
Nikrans NS-5000
Calls/GSM / 3G
Indoor coverage: 32300 ft²
Frequency bandwidth of 900 MHz
https://www.mobile-signal-boosters.shop/
repeater-136/
Nikrans NS-5000
Free Support
3-YEAR warranty & service
30-DAY return policy
3-7 business day delivery
Chat with us
info@mobile-signal-boosters.shop
+448000698689
Indoor Antennas /
Outdoor Antennas
Safety for Human Health
Conformity to CE and RoHS standarts
Full kit ready to use
Full duplex mode (improvement of outcoming and incoming signal)
(Sales)
SPECIFICATION
Indoor coverage: 32300 ft²
Up-link freq: 880-915 MHz
Down-link freq: 925-960 MHz
Up-link Gain: 65 dB
Down-link Gain: 70 dB
Power supply: Input AC90~264V, output DC5V/2A
Working t °C: -25/+55
IP-Code: IP40
Humidity: 5 - 95%
Size (mm): 175×131×33
Booster Weight: 0.7 kg
dBm: 23 dBm
PACKAGE
Cables
Power supply
User Manual
Advertisement
Related Manuals for Nikrans NS-5000
Summary of Contents for Nikrans NS-5000
- Page 1 WWW.MOBILE-SIGNAL-BOOSTERS.SHOP MOBILE SIGNAL BOOSTER Nikrans NS-5000 SPECIFICATION Indoor coverage: 32300 ft² Up-link freq: 880-915 MHz Down-link freq: 925-960 MHz Up-link Gain: 65 dB Down-link Gain: 70 dB Power supply: Input AC90~264V, output DC5V/2A Working t °C: -25/+55 IP-Code: IP40 Humidity: 5 - 95% Size (mm): 175×131×33...
- Page 2 32,300 ft². Thus, the device can be used in large buildings such as hotels, shopping malls, entertainment centres, restaurants, offices, car parks, etc. The NS-5000 operates at 900 MHz, the frequency used by all European telecom operators to transmit GSM signals responsible for voice calls.
- Page 3 INSTALLATION SCHEME 1. Find the best position of an outdoor antenna (on the roof/ outside the window where your mobile phone displays 2-3 bars of mobile coverage). Choose the best direction of the antenna – it’s recommended to direct it towards the nearest GSM base station.
