MYAMPLIFIERS.COM
PHONE SIGNAL BOOSTER
Nikrans NS-500GD
Calls/GSM / 3G / 4G/LTE
Coverage: 500 m²
Freq.: 900, 1800 MHz
https://www.myamplifiers.com/repeater-32/
Nikrans NS-500GD
Free Support
3-YEAR warranty & service
30-DAY return policy
3-7 business day delivery
Need help?
Buyer's Guide
contact@myamplifiers.com
+(44)8000485044
(Sales)
Indoor Antennas /
Outdoor Antennas

SPECIFICATION

Indoor coverage: 500 m²
Up-link freq: 880-915 & 1710-1785 MHz
Down-link freq: 925-960 & 1805-1880 MHz
Up-link Gain: 65 dB
Down-link Gain: 65 dB
Power Output: Input AC100~240V,output
DC7V/3A
Working t °C: -25/+55
Humidity: 5 - 85 %
Size (mm): 175*131*33mm
Booster Weight: 0.7 kg
dBm: 17 dBm

PACKAGE

Cables
Power supply
Safety for Human Health
Conformity to CE and RoHS standards
Full kit ready to use
Full duplex mode (improvement of outcoming
and incoming signal)
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS-500GD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nikrans NS-500GD

  • Page 1 MYAMPLIFIERS.COM PHONE SIGNAL BOOSTER Nikrans NS-500GD SPECIFICATION Indoor coverage: 500 m² Up-link freq: 880-915 & 1710-1785 MHz Down-link freq: 925-960 & 1805-1880 MHz Up-link Gain: 65 dB Down-link Gain: 65 dB Power Output: Input AC100~240V,output DC7V/3A Working t °C: -25/+55...
  • Page 2 PRODUCT DESCRIPTION Dual band cellular amplifier Nikrans NS-500 GD is a device to boost mobile signal at home. It works on two frequency bands of 900MHz and 1800MHz at a time. This cell amplifier is suitable for all providers of the European and other countries which apart from traditional 900MHz often use 1800MHz frequency as additional one.
  • Page 3 INSTALLATION GUIDE Fix an outdoor antenna (outside the window, on the roof or wall of the building) and connect it to the booster box using a cable. Fix an indoor antenna on the ceiling and connect it to the booster box using a cable. Connect the power supply to the booster box and plug it into a power socket.
