- Page 1 User Manual D2-200 DBR Laser Module Revision 01 14988 W. 6th Ave., Suite 700 Golden, CO 80401 www.vescent.com...
-
Page 2: Table Of Contents
3.3.3 Setting the Current Limit .........................11 3.3.4 Starting Laser Emission ..........................12 4 Detailed Operations ........................13 4.1 Adjusting D2-105 diode temperature setting (T2) ....................13 4.2 Configuring D2-105 loop filter settings for a D2-200 ..................14 5 Troubleshooting .......................... 16 A Specifications ..........................17 A.1 Performance ................................17 A.2 Model Designation ..............................18... -
Page 3: Introduction
1 Introduction This manual contains information for operating the Vescent D2-200 DBR Laser Module. The D2-200 is a distributed Bragg reflector (DBR) diode laser that produces a near gaussian free-space output beam with a very low M and exhibits mode hop-free tuning over more than 25 GHz. -
Page 4: Safety
50 Ω SMA terminator to avoid damage to the diode. Never connect or disconnect the D2-200 Laser Module to/from an energized laser controller. Always power down the laser controller completely before making connections to the D2-200. - Page 5 D2-200 User Manual Introduction The D2-200 is not intended for fail-safe operation in hazardous environments or life- threatening situations. The user assumes full responsibility for correct and safe usage of the D2-200 in accordance with any applicable laws, codes, regulations, and standards pertaining to their specific application.
-
Page 6: Affixed Labels
Note: The Maximum Output and Emitted Wavelength will depend on the submodel of D2-200. Points to the laser aperture on the front of the D2-200. Laser light emits in the direction of the arrow. Warns the user about the laser emission hazard at the front of the D2-200. -
Page 7: Hardware
D2-200 User Manual Hardware 2 Hardware This section discusses the hardware features and connections of the D2-200 and the other items that are shipped with the unit. 2.1 Package Contents The D2-200 is shipped in a package designed to provide excellent protection from shock and vibration experienced during shipping. -
Page 8: Controls And Connections
50 Ω SMA terminator to avoid damage to the diode. Never connect or disconnect the D2-200 to an energized laser controller. Doing so can cause irreparable damage to the diode laser. Always power down the laser controller completely before making connections to this laser. - Page 9 Hardware 3. Temperature Control Port (Micro-D) The D2-200 has two temperature control stages: the housing stage (1) and the diode stage (2). Each stage has a thermo-electric cooler (TEC) that controls the temperature and an NTC thermistor (Rth) that monitors the temperature. A laser controller (e.g. D2-105 or SLICE-DLC) is required to stabilize the temperature of the D2-200.
-
Page 10: Front View
Laser light is emitted from the laser through an aperture located on the front panel of the D2-200. Never view the laser from the above position. 4. Shutter The D2-200 has a rotating manual shutter that features a laser aperture and control lever, each of which are described below. 5. Laser Aperture The D2-200 has one laser aperture located on the front of the unit. -
Page 11: Top View
8. Baseplate Slots The D2-200 comes with either an imperial or metric baseplate for mounting the unit to a matching optical breadboard. To mount the D2-200 to a breadboard, use the included cap screws and washers in the baseplate slots and securely fasten. -
Page 12: Getting Started
DBR laser diodes are fabricated with the feedback grating patterned directly adjacent to the gain region of the diode. The cavity of the D2-200 is short with no moving tuning element, making it highly immune to vibrations and acoustic perturbations. -
Page 13: Typical Operation
The D2-105 will turn on and the Power light will light up. 3.3.2 Temperature Stabilization If your D2-200 was purchased with a D2-105, then the D2-105 is set to the correct temperature settings for your laser. If your D2-105 was purchased separately, refer to Section 4 to configure the temperature settings. -
Page 14: Starting Laser Emission
D2-200 User Manual Getting Started • In the supplied D2-200 test documentation, find the Maximum Current on the Laser Module table. • Turn the D2-105 Current Limit Set knob to set I at or below the Maximum Current. I protects the diode from overcurrent by shunting excess current through a transistor to ground. -
Page 15: Detailed Operations
This section provides additional detail about the operation of the D2-200. 4.1 Adjusting D2-105 diode temperature setting (T2) If you are using a D2-200 with a D2-105 that was purchased separately, the diode temperature setting may not be set appropriately for spectroscopy. To adjust the diode... -
Page 16: Configuring D2-105 Loop Filter Settings For A D2-200
4.2 Configuring D2-105 loop filter settings for a D2-200 If you are controlling the D2-200 with a D2-105 that has been configured for a different laser module (e.g. a D2-100), then the D2-105 loop filter settings will need to be updated. - Page 17 D2-200 User Manual Detailed Operations o T1 Proportional (3) Prop. 0.047 0.22 0.47 o T1 Differential (4) Prop. 0.01 0.022 0.047 0.22 0.47 • Use the image below to locate the GAIN2 test point (A), GND3 test point (B), and the PROPGAIN2 trimpot (C). Also locate the GAIN1 test point (D), GND2 test point (E), and the PROPGAIN1 trimpot (F).
-
Page 18: Troubleshooting
D2-200 User Manual Troubleshooting 5 Troubleshooting The following table describes issues that may be encountered while using the D2-200 and recommended actions to solve the problems. Problem Recommended Actions Current is supplied to the laser, but 1. Check that the aperture lever is in the OPEN the unit is not emitting light. -
Page 19: A Specifications
D2-200 User Manual Specifications A Specifications A.1 Performance Parameter Min. Typical Max. Units Optics Center Wavelength Model dependent. See model designation on the next page.* Maximum Output power See test documentation provided with the laser.* Linewidth Beam Diameter (1/e Beam Divergence... -
Page 20: Model Designation
D2-200 User Manual Specifications A.2 Model Designation D2-200-DBR-λ λ λ(-HP)(/M) λ λ λ Laser wavelength in nanometers, e.g. 780 If included, indicates high power variant If included, indicates the baseplate spacing is metric Vescent Technologies Inc. - Page 18 -... -
Page 21: B Additional Resources
Details Vescent Home https://vescent.com/ Additional resources are available at vescent.com D2-200 Product Page https://vescent.com/us/d2-200-dbr-laser-module.html Check here for more information about the D2-200 D2-105 Manual https://www.vescent.com/manuals/doku.php?id=d2:laser_controller Manual for the D2-105 Laser Controller Vescent Technologies Inc. - Page 19 - Revision 01... -
Page 22: C Service & Maintenance
RMA form. 5. Return the unit, postage prepaid, to Vescent. Do not forget to return a hard copy of the completed RMA form with the unit and write the RMA number on the shipping label. -
Page 23: D Warranty
“Warranty Period” during which this warranty applies varies with Product type as follows: a. For standard Vescent lasers in which a counter is incorporated (i.e. lasers with counters for which Vescent has published a datasheet and which have not been obsoleted by the time of order placement): one (1) year after the date of original shipment or 3,000 hours of use, whichever occurs first;... - Page 24 D2-200 User Manual Warranty e. For Products that are discontinued, Vescent’s liability shall terminate at the end of the applicable Warranty Period or one (1) year from the date of discontinuity, whichever occurs first. f. Except for the warranty stated herein and to the extent permitted by applicable law...
