- Page 1 ® Linear Acoustic AERO DTV Audio Processor User Guide Version 3.32.25 September 2024 Telos Alliance 1241 Superior Avenue Cleveland, OH 44114 USA +1 (216) 241-7225 www.telosalliance.com...
-
Page 2: Table Of Contents
Contents User Warnings and Cautions ........................... 8 Important Safety Symbols..........................8 Hazardous Voltages and Fuses........................9 Electrical Warnings ............................... 9 USA Class A Computing Device User Information................10 Canadian Class A Computing Device Warning .................. 10 CE Conformance Information ........................11 Trademarks, Patents, and Licenses ...................... - Page 3 Rear Panel ..............................21 AERO.2400 ................................. 21 Front Panel ..............................22 Rear Panel ..............................22 AERO.8000 ................................. 23 Front Panel ..............................24 Rear Panel ..............................24 Audio Processing ..............................25 AEROMAX Engines............................25 ® Definitions ................................25 AMX5.1.................................. 26 AMX2.0.................................. 27 AMX5x2 ................................
- Page 4 HTTP server ..............................42 Parameter color ............................43 Chapter 3: Audio Routing I/O – chapter 3 ..............................44 Audio Core ................................44 Baseband I/O Routing– AERO.20, AERO.200, AERO.2400 ............45 Input Routing..............................45 Output Routing ..............................46 Main Tab ................................47 Clock Domains in AERO ........................
- Page 5 Address Display............................... 60 AoIP Inputs ................................60 Controls and Status Window ........................62 Channel ................................63 Channel List..............................63 Upload AES67 SDP ........................... 63 Fifo Buffer..............................64 Sample Rate Converters ........................64 “Assign” and Memory Slots......................... 65 AoIP Outputs ................................65 Sample Rate Converters ........................
- Page 6 Loudness Meter tabs ............................ 77 Task Script tab ..............................78 Update Software ............................. 79 MQTT ..................................80 Status Overview .............................. 80 Chapter 7: Factory Presets Factory Presets ..............................82 Fine Arts 5B Gen ............................. 82 ITU 5B Loudness Lim........................... 82 Music 5B Hvy ..............................
- Page 7 Chapter 9: Troubleshooting Troubleshooting..............................89 The unit does not power on........................89 Dialogue causes surrounds to pump....................89 Output audio clicks and pops........................89 Input audio has dropouts .......................... 90 Audio sounds strange ..........................90 Audio issues disappear in bypass ......................90 Audio fixed by re-boot ..........................
-
Page 8: User Warnings And Cautions
User Warnings and Cautions User Warnings and Cautions The installation and service instructions in this manual are for use by qualified personnel only. Refer to qualified personnel for service. This equipment is not suitable for use in locations where children are likely to be present. -
Page 9: Hazardous Voltages And Fuses
Voltage warning symbol. This symbol, whenever it appears, alerts you to important operating and maintenance instructions. Read the manual. Important instructions symbol. This symbol, whenever it appears, identifies the associated terminal as a protective earth ground for protection against electric shock in case of a fault. The terminal should be connected to a proper ground system with 20 - 14 AWG (0.5 - 1.5mm) wire. -
Page 10: Usa Class A Computing Device User Information
that access to the power cord is impaired. If the unit is incorporated into an equipment rack, an easily accessible safety disconnect should be included in the rack design. For equipment that uses PoE (Power over Ethernet), the corresponding Ethernet cable should also be treated as a disconnect device when connected to a switch that provides PoE. -
Page 11: Ce Conformance Information
Laboratories Licensing Corporation. All versions, claims of compatibility, trademarks, etc. of hardware and software products not made by The Telos Alliance which are mentioned in this manual or accompanying material are informational only. The Telos Alliance makes no endorsement of any particular product for any purpose, nor claims any responsibility for operation or accuracy. -
Page 12: Feedback
Service You must contact Telos Alliance before returning any equipment for factory service. We will need your unit’s serial number, located on the back of the unit. We will issue a return authorization number, which must be written on the exterior of your shipping container. -
Page 13: Product Registration
Product Registration Register your product today to get the full benefits of our warranty, support, and product updates at www.telosalliance.com/product-registration. Company Headquarters Telos Alliance, 1241 Superior Avenue, Cleveland, OH 44114 USA. Telephone +1-216-241-7225. -
Page 14: Chapter 1: Introduction
Chapter 1: Introduction Introduction and scope of this manual The Linear Acoustic AEROMAX family of processors are state-of-the-art, adaptive, ® multiband, broadcast audio/loudness processors. This manual covers the entire family of AERO processors, including: • AERO.10 • AERO.20 • AERO.100 •... -
Page 15: Rear Panel
Figure 1 - AERO.10 front panel On the front panel of the AERO.10, you will find: • Power Indicator • LCD Display • Rotary joystick encoder • Headphone volume control • Headphone jack • USB connector The LCD display provides the user with visual feedback and interaction as to what the AERO.10 is doing, parameter settings, and input signal status. -
Page 16: Aero.20
Front Panel Figure 3 - AERO.20 Front Panel On the front panel of the AERO.20, you will find: • Power Indicator (backlit Telos Alliance logo) • LCD Display • USB connector The LCD display provides the user with software version, host computer name, and IP address of the unit. -
Page 17: Aero.100
Connect to stable network • AoIP (RJ45) – Auto-sense 100/1000 BASE-T, used for AES67 audio streams in support of SMPTE ST 2110-30 and Telos Alliance Livewire streams. Connect to stable network • SDI I/O (BNC) – Auto-sensing 3G/SD/HD, supports 16 audio channels in each path, VANC metadata, and has internal compensating video delay •... -
Page 18: Rear Panel
On the front panel of the AERO.100, you will find: • Power Indicator (backlit Telos Alliance logo) • LCD Display • USB connector The LCD display provides the user with software version, host computer name, and IP address of the unit. Configuration and control of the unit is performed by way of the remote client, NfRemote, or connecting to the unit’s internal https server. -
Page 19: Aero.200
Connect to stable network • AoIP (RJ45) – Auto-sense 100/1000 BASE-T, used for AES67 audio streams in support of SMPTE ST 2110-30 and Telos Alliance Livewire streams. Connect to stable network • SDI I/O (BNC) – Auto-sensing 3G/SD/HD, supports 16 audio channels in each path, VANC metadata, and has internal compensating video delay •... -
Page 20: Aero.2000
• ENC Out (BNC) – Encoder output, fed in parallel with AES3 15/16 • Vref (BNC) – Video reference input (not currently supported) • LTC In (BNC) – LTC timecode input (not currently supported) • GPI/O (DB15) – five parallel inputs, 5-V TTL levels, active low •... -
Page 21: Rear Panel
The LCD display provides the user with visual feedback and interaction as to what the AERO.2000 is doing, parameter settings, and input signal status. It is possible to configure the unit with the front panel controls and display, but doing so by way of the remote client, NfRemote, is much easier and offers a number of benefits. -
Page 22: Front Panel
AES3 I/O via DB25 connection. It also supports dual 3G/HD/SD -SDI I/O. Front Panel On the front panel of the AERO.2400, you will find: • Power Indicator (backlit Telos Alliance logo) • LCD Display • Up / Down / Left / Right control buttons •... -
Page 23: Aero.8000
Connect to stable network • AoIP (RJ45) – Auto-sense 100/1000 BASE-T, used for AES67 audio streams in support of SMPTE ST 2110-30 and Telos Alliance Livewire streams. Connect to stable network • SDI I/O #1 (dual BNC) – Auto-sensing 3G/SD/HD, supports 16 audio channels, VANC metadata, and has internal compensating video delay •... -
Page 24: Front Panel
To power on, apply AC power to the unit; there is no power switch. The blue light behind the Linear Acoustic / Telos Alliance logo illuminates, the LCD screen shows the Linear Acoustic logo, and fans turn on. When the menu appears on the LCD screen, startup is complete and the unit is ready to use. -
Page 25: Audio Processing
Audio Processing This section of the manual provides an overview of the audio processing that is available for the AERO units. This processing is described in more detail later in the manual. AEROMAX® Engines There are three different AEROMAX engines available. They are the: •... -
Page 26: Amx5.1
• Automatic and seamless switching between surround and upmixing of stereo inputs (AutoMAX) • Downmixing (Lo/Ro or Lt/Rt) • Creation of dual channel mono from one channel of an input pair (for SAP, AD/DVS and local emergency audio) • Automatic replacement of SAP (or any stereo/mono source) with a downmix of the main channel •... -
Page 27: Amx2.0
each input program source. The local input feed can be selected automatically when audio is detected at the input, or via a GPI trigger. The last input pair can be processed as a stereo input program, perhaps for a subchannel (often called a “dot 1” or “dot 2” in ATSC programming), or it can be configured to accept an alternate language and/or an AD descriptive service with automatic switching. -
Page 28: Amx5X2
SDI Pair Shuffling and AES Input to SDI output embedding Re-embed Audio HD/SD HD/SD Video Delay Audio Embedding Pairs 1 to 8 Re-embed SDI pairs for pair shuffling Embed AES pairs for pass through of automation tones or other messaging. Upmix Proc 1/2 Down-... -
Page 29: Nielsen
The encoder supports various Nielsen watermarking modes, including: • N2 • N6 • CBET Note: The Nielsen codes (digits) used for your station must be obtained from Nielsen directly. Telos Alliance is unable to provide these codes. -
Page 30: Verance
(optional) Dolby encoding is performed. Note: The Verance Aspect codes used for your station must be obtained from Verance directly. Telos Alliance is unable to provide these codes. Note: Verance Aspect watermark encoding is not supported in the AERO.10 or AERO.20... -
Page 31: Remote And Front Panel Control
The Dolby Digital Plus Transcoder option is not supported in the AERO.10 or AERO.20 Remote and Front Panel Control The AERO units support multiple method of control: • Remote control application • Internal http server (set and get commands) • Front panel controls (AERO.10, AERO.2000, and AERO.2400) Remote Control All AERO units are able to be fully configured, controlled, and monitored via the remote-control application, NfRemote, including those units which include front... -
Page 32: Front Panel Navigation
Front Panel Navigation The AERO.10, AERO.2000, and AERO.2400 include front panel navigation controls and displays which allow you configure and monitor signals, processing, and the unit. The other AERO units are “headless” and only have a front panel display which provides the unit’s software version, “host name” (serial number), and the IP address for the control port. -
Page 33: Aero.2000, Aero.2400
The front panel will now be unlocked, and settings may be changed. Please remember to lock the front panel once you are through making adjustments. It will not lock itself unless it is rebooted. AERO.2000, AERO.2400 The right, left, up, and down arrow keys navigate the menu system: ►... -
Page 34: Chapter 2: Remote Interface
Downloading NfRemote The NfRemote client software (remote control) can be found at the Telos Alliance website in the AERO’s section and is also available for download directly from the unit’s internal http server. -
Page 35: Installing Nfremote
Figure 18 - Browser display when connected to AERO’s HTTP server 2. Download the Remote Interface software installer by clicking the link to its right. Installing NfRemote Copy the NfRemote application to a Windows computer or tablet. Double click to begin the installation and follow the on-screen directions to complete it. - Page 36 Figure 19 - Initial NfRemote connection screen Once the connection is complete, you will see a display of the parameters and meters. Figure 20 - NfRemote connected to an AERO unit To operate the controls in NfRemote, click the left mouse button to select menu items and controls.
-
Page 37: Nfremote Overview
Figure 21 - parameters displayed by "mousing over" a control Right clicking on the parameter will allow you to select between copying the value Example: Upmix Enable: On Or copying the parameter’s path and value: Example: /inst_1/umx1/md_upmix_enable=1 NfRemote Overview After successful connection, the remote starts at the Home Screen. The remote interface screen is fully re-sizeable and can be adjusted in the same manner as any such window, that is, via handles at each corner. -
Page 38: Tree And Tabbed Navigation Modes
To the right of the Menu button are six Display Presets that quickly recall saved screen configurations. Tree and Tabbed Navigation Modes “Tree” and “Tabbed” navigation modes refer ONLY to how information and controls are displayed on the screen, and not to the number of controls available or their precision. -
Page 39: Display Presets
Figure 24 - Tree Navigation mode view Both modes allow you to resize the sections that take up room on the screen. In both modes, small horizontal lines separate the sections. Tree Navigation mode has top and bottom sections, while Tabbed Navigation mode has top, center, and bottom sections. -
Page 40: Loudness Metering
Figure 25 - Display Settings controls From this menu, you can: • turn displays on and off • select the information to display in each: o processing meters for DRC 1, 2, and local engines o Dolby Digital confidence decoding information o I/O meters for each processing instance o I/O meters for the hardware. -
Page 41: Remote Computer Whitelist
Figure 27 - ITU BS.1770 Loudness Meter settings The precise patch points available for these tools differ depending on which section of the audio and/or signal path is selected for display. The list is detailed and comprehensive. The loudness meters and logging are configurable between ATSC A/85 (used in North America) and ITU R-128. -
Page 42: General Notes
Figure 29 - HTTP Server "Whitelist" configuration General Notes Multiple computers can connect to the same AERO unit simultaneously. One computer can connect to multiple AERO units with a single installation of the Remote Interface software, This is a handy feature for monitoring or adjusting main and backup units at the same facility, or addressing units assigned to additional channels or even different stations. -
Page 43: Parameter Color
Parameter color Parameters in NfRemote will appear one of two colors, either white or yellow. The parameter will be displayed as white when its value is unchanged from either the default value, or the value saved in the current preset it is part of. The parameter will be displayed as yellow when its value has been changed from the default value, or the value saved in the current preset it is part of. -
Page 44: Chapter 3: Audio Routing
Chapter 3: Audio Routing Audio I/O routing with the AEROs is very flexible, but admittedly, can seem somewhat complex at first. Once you understand the concepts, it’s really not that difficult. The AERO.20, AERO.200, and AERO.2400 support: • Dual 3G-SDI I/O •... -
Page 45: Baseband I/O Routing- Aero.20, Aero.200, Aero.2400
Baseband I/O Routing– AERO.20, AERO.200, AERO.2400 The audio I/O is configured in the System -> Baseband I/O menu. This menu is laid out logically from left to right, configuring inputs to outputs, following the block diagram / workflow of the AERO unit. Input Routing The audio core can accept up to 36 input channels, and each AEROMAX instance supports up to 10 audio channels in and out, which are configured as a 5.1+2+2,... -
Page 46: Output Routing
System -> Baseband I/O -> Core Input Source Figure 32 - Audio Core Input routing Once the desired input audio sources are routed to the Audo Core Inputs, the audio then needs to be routed to the inputs of the AEROMAX instance. This is handled in the (AEROMAX) Instance Source, which directly to the right of the Core Input Source menu System ->... -
Page 47: Main Tab
System -> Baseband I/O -> AES3 Outputs There are some additional constraints around the output routing though. • Audio Core Outputs 1 – 16 are dedicated to SDI #1 Output • Audio Core Outputs 17 – 32 can be routed to SDI #2 Output •... -
Page 48: Input Status
System -> Baseband I/O -> Main Figure 34 - Baseband Audio Reference Clock configuration Input Status The Input Status tab provides status for each physical base band input, along with the status of both power supplies. Sample Rate Converters (SRC) There are 36 channels of hardware Sample Rate Conversion (SRC) built into the AERO.20, AERO.200, and AERO.2400. -
Page 49: Core Input Source
Coded audio, such as Dolby Digital (AC-3) and other formats can never be passed through Sample Rate Converters without being destroyed. Properly managing clock domains is required when using coded audio. Core Input Source The Core Input Source tab is where the physical base band inputs are routed to the Audio Core Input channels Figure 35 - Baseband Audio Core Input routing Each of the physical inputs can be routed to any of the Core Input channels. -
Page 50: Instance Overview
The Instance Source tab is where the Audio Core Input channels are routed to the AMX Instance inputs. Each instance will have its own settings, and the available options are: • Off • Core 1/2 • Core 35/36 Figure 36 - AEROMAX Processor Input routing Instance Overview The Instance Overview tab is a status display of all the I/O routes, both input and output, made for each AEROMAX Engine Instance. -
Page 51: Core Output Source
Core Output Source The Core Output Source is where the output of the audio processing core (where the AMX engines run) is mapped to the output channels. The audio core output supports 34 audio channels, though there are some constraints. •... -
Page 52: Audio
Figure 39 - SDI Output Overview tab Audio The Audio tab is where the output audio is configured. The Embed control enables or disables embedding audio from the AMX processing engine or Core Audio, along with pair shuffling. When the Embed control is disabled, the audio from the SDI Input passes through directly to the SDI Output, but that completely defeats the purpose of having an audio processor inline. -
Page 53: Video
Video The Video tab is where the video compensating delays are configured. The video delays allow for audio/video sync to be maintained on the output of the unit. These are manual controls and must be adjusted during setup. The AERO is shipped with no video delay added, so it must be set on each SDI Output for audio and video to be synchronous. -
Page 54: Aes3 Outputs
AES3 Outputs The AES3 Outputs tab is where the routing for the AES3 Outputs is configured. Similar to the SDI Outputs tab, there’s an Overview / Status tab at the top, and then the Assign tab is where the routing is configured. Figure 42 - AES3 Outputs Overview tab The available output source options for the AES3 Outputs are: •... -
Page 55: Tcp Link Status
TCP Link Status This tab displays the status of the link between the AERO unit and the host computer running NfRemote. Display Settings This tab allows configuration of the display windows displayed in the top half of the NfRemote window. Presets To make configuration and setup of your AERO easier, sample Baseband I/O routing presets are included to use as a starting point. -
Page 56: Clock Status Indicator
• 2x SDI with 5.1+2+2 and 3x 2.0 w AES3 Local(9-10) Inputs (AMX5.1 + AMX2.0) • 2x SDI with 5.1+2+2 and 5x Stereo (AMX5.1 + AMX5x2) One thing to note with the presets, is that all adjustable parameters that fall under the Baseband I/O menu are stored in these presets. -
Page 57: Aoip I/O Routing
PTP clock (IEEE-1588) or a Livewire clock. PTP is the industry standard clock when using AES67 or SMPTE ST 2110 workflows, and Livewire clock is a clock option when using workflows based on Telos Alliance Livewire. Livewire systems can also use PTP clocks instead of a Livewire clock. -
Page 58: Sample Rate Conversion
Figure 47 - PTP / Livewire clock page Sample Rate Conversion Since the AoIP section uses a separate, and different, reference clock than the audio processing engine and baseband I/O, clock management is essential. To aid in this, sample rate converters (SRC) are included in between the AoIP section and the audio processing engine. -
Page 59: Chapter 4: Audio Over Ip
NMOS IS-04, defined by AMWA (www.amwa.tv), is how stream discovery is typically handled with SMPTE ST 2110 workflows. Livewire+, from the Telos Alliance, includes stream discovery as well as audio, and additional features as well At the time of this writing, the AERO units do not support the NMOS suite, but do support manual configuration of AES67 / SMPTE 2110-30 flows, including uploading and downloading of SDP files. -
Page 60: Clock Mode
Clock Mode Clock Mode allows the selection of whether the AoIP clock is either: • PTP (IEEE-1588) for AES67 or Livewire streams • Livewire clock for use with Livewire streams It is also possible to enter the PTP Clock Domain value. Ensure that this matches the clock domain value of the PTP primary clock generator. - Page 61 • Receive 1 (2ch) • Receive 2 (2ch) • Receive 3 (2ch) • Return Receive 1+2 (8ch) will be an 8-channel stream, where channels 1-6 are a 5.1-ch input for Program 1 to be downmixed, and channels 7 and 8 are the input of Program 2 Receive 1 (2ch) will be a 2-channel stream, which is the stereo input stream to Program 1...
-
Page 62: Controls And Status Window
When the AMX engine is AMX5x2, there will be: • Receive 1A (2-ch) • Receive 1B (2-ch) • Receive 1C (2-ch) • Receive 2 (2-ch) • Receive 3 (2-ch) • Return Receive 1A will be a 2-channel stream which is the input of Program 1. Receive 1B will be a 2-channel stream which is the input of Program 1B. -
Page 63: Channel
Channel This field allows the source stream to be entered directly and displays the address of the current input stream. Input Stream Port Number The default port number that AES67 and Livewire+ streams use is 5004, but it is sometimes desirable to change the port number being used. The AERO supports receiving streams at different port numbers. -
Page 64: Fifo Buffer
This allows you to load an SDP file for an incoming AES67 stream. The SDP file contains information regarding the input stream, such as sample rate, number of audio channels, multicast address and port number, RTP header information, and more. This information is necessary for AES67 audio streams, whereas Livewire streams contain this. -
Page 65: Assign" And Memory Slots
It is important to know that coded audio, such as any Dolby audio, cannot be passed through a sample rate converter without being destroyed. “Assign” and Memory Slots The furthest column to the right on this page includes memory slots to store the address and other relevant information regarding commonly used input streams. - Page 66 When the AMX engine is AMX5.1, there will be: • Send 1+2 (8-ch) • Send 1 (6-ch) • Send 2 (2-ch) • Send 3 (2-ch) • DD+ Encoder Out* • DD+ Encoder Out 2* • Send Send 1+2 (8-ch) will be an 8-channel stream, where channels 1-6 are the 5.1-ch output of Program 1, and channels 7 and 8 are the output of Program 2 Send 1 (6-ch) is a 6-channel stream containing the 5.1-channel output of Program 1 Send 2 (2-ch) is a stereo stream containing the output of Program 2...
-
Page 67: Sample Rate Converters
Send 1C (2-ch) will be a 2-channel stream which is the output of Program 1C. Send 2 (2-ch) is a stereo stream containing the output of Program 2 (7/8) Send 3 (2-ch) is a stereo stream containing the output of the 9/10 Local DD+ Encoder Out is a stereo stream containing the output of the Dolby Digital Plus encoder for Program 1 when the Dolby transcoder option is installed. -
Page 68: Status
The left side of the display selects the stream “slot” to configure and display. Directly to the right of that is the stream status and statistics display. Status The status and statistics display Figure 52 - AoIP output stream status tab At the top of this window, the stream address, port number (if set away from default), and connection status are shown. -
Page 69: Channel
• “Standard” streams are Livewire standard streams, which have a packet time of 5 ms, or 200 packets per second • “LW Surround” streams are Livewire Surround streams, and a packet time of 1.25 ms or 800 packets per second The RTP header / payload type is the 3 number shown in this line Channel... -
Page 70: Take
Figure 55 - AoIP Output Stream using port value of 5006 Take The Take control applies all changes made to the Output stream, and updates the SDP information. After any changes are made to the output stream, press the Take button, and then the (updated) SDP file can be downloaded. -
Page 71: Override Payload Type / Rtp Header
Override Payload Type / RTP Header This field allows for the changing of the RTP header type inserted into the output stream. The RTP Header type is automatically set by the stream configuration, however, the default value can be overwritten and may be set to a value that you need. -
Page 72: Chapter 5: Audio Clocking
Chapter 5: Audio Clocking Clocking System clocking is such an important topic that we decided to give it its own chapter. Clock Domains in AERO With the exception of the AERO.8000 and AERO.soft, the AERO units support several baseband audio reference clock options, including: •... -
Page 73: Clock Status Indicator
PTP clock (IEEE-1588) or a Livewire clock. PTP is the industry standard clock when using AES67 or SMPTE ST 2110 workflows, and Livewire clock is a clock option when using workflows based on Telos Alliance Livewire. Livewire systems can also use PTP clocks instead of a Livewire clock. -
Page 74: Sample Rate Conversion
System -> System -> AoIP -> Clock Figure 58 - AoIP clock configuration page Sample Rate Conversion Since the AoIP section uses a separate, and different, reference clock than the audio processing engine and baseband I/O, clock management is essential. To aid in this, sample rate converters (SRC) are included in between the AoIP section and the audio processing engine. -
Page 75: Chapter 6: Internal Http Server
Chapter 6: Internal HTTP Server HTTP Server The AERO unit contains an internal HTTP server. This server provides access to many functions, including: • Full list of parameters • Full status/settings of parameters • Preset management • Unit Status and Log files •... -
Page 76: List Status Outputs
Figure 60 - List of parameters List Status Outputs The List Status Output tab provides a complete list of status of the parameters in the AERO. This list can be used for a custom scripting monitor (rear) interface to the unit. -
Page 77: Launch Remote Interface (Windows Application)
Figure 63 - Example preset page Launch Remote Interface (Windows Application) This link starts the NfRemote application. Log Files The Log Files tab allows you to download the system log files. Loudness log files are not included in this tab. They will be located in each AMX Instance Loudness Meter tab. -
Page 78: Task Script Tab
Figure 65 - Loudness Meter Page In the Loudness Meter tab, it is possible to start, stop, and reset the Loudness Meter for that instance, as well as download output loudness logs for that audio program. The loudness logs are measured at the output of the AERO unit, after the loudness control processing has taken place. -
Page 79: Update Software
Scripts can be built in the HTTP server’s editing window. The appropriate parameters are required to be included in the script. One easy way to enter the parameter is to have NfRemote running simultaneously and simply copying the parameter and value desired to be included, then paste it into the script window. Figure 67 - Task Script Editor page Update Software It is possible to update the AERO’s software via the HTTP page. -
Page 80: Mqtt
When updating the software from the HTTP server page, it will automatically and instantly install the updates. This means all audio processing will immediately stop, and the unit will be offline until the updates are installed. Ensure that the unit is not on-air when performing a software update from the HTTP server page. - Page 81 • Control Port IP Address • Unit Uptime are reported on this tab Figure 70 - Status Overview tab...
-
Page 82: Chapter 7: Factory Presets
Chapter 7: Presets Factory Presets This section lists each preset in alphabetical order, as they appear in the AERO and the remote interface. Each preset’s adjustable processing parameters are described. Some presets do not use every parameter. For example, TV 4B Gen does not use the 5th band. -
Page 83: Music 5B Hvy
Music 5B Hvy Music 5-Band Heavy is an aggressive preset for TV music channels that effectively delivers music programming to small televisions and portable receivers. MVPD 5B Gen MVPD 5B Gen is intended for Multiple Video Program Distributors who may not have full control of all programs, interstitials or commercials present in a given network stream. -
Page 84: Tv 5B Gen (Default)
on dialogue, and results in more open sounding audio, albeit with less short-term dynamic loudness control. TV 5B Gen (Default) Television 5-Band General is the factory default preset and also the most commonly used. It provides moderate dynamic range processing and is appropriate for all content types. -
Page 85: Chapter 8: Maintenance
Chapter 8: Maintenance Maintenance AERO units are reliable and easy to install. Most problems turn out to be wiring mistakes that apply incorrect input signals. However, the AERO is a powerful processor with many user-adjustable parameters, some of which interact. If you cannot find the source of a problem, simplify the signal path. -
Page 86: Upload Software
Figure 72 - System Maintenance tab Upload Software The Upload Software control will allow you to upload a new version of AERO software and firmware (*.pak file). Once the package is uploaded, the AERO unit checks and validates the file to ensure it’s the correct file and is not corrupted. Updating Software / Firmware Once the software is validated, the options to update are presented. -
Page 87: Power Cycle
Power Cycle The Power Cycle will restart the unit. This is equivalent to removing power and reapplying it. Re-initialize Software This performs a “soft reset” of the unit and restarts the main software running in the unit. Reset OLED Display This control restarts the part of the unit which drives the front panel display and controls. -
Page 88: Misc Config Page
While it is not required to backup the current key or system configuration before installing a new key, it is recommended. To backup the current key, mouse over the “Current Key” field, right click, and copy it to your clipboard. Paste it in a Word or text document. To back up the system configuration, please refer to the System Backup and Restore section above. -
Page 89: Chapter 9: Troubleshooting
Chapter 9: Troubleshooting Troubleshooting AERO units are reliable and easy to install. Most problems turn out to be wiring mistakes that apply incorrect input signals. However, the AERO is a powerful processor with many user-adjustable parameters, some of which interact. If you cannot find the source of a problem, simplify the signal path. -
Page 90: Input Audio Has Dropouts
As an example, the AES3 Reference may be missing or at the wrong sample rate; the unit expects to lock to 48 kHz. The AERO defaults to an internal 48 kHz reference if the external reference is removed or missing. This allows audio to continue, but with asynchronous inputs and outputs (due to the sample rate converters on each input pair). -
Page 91: Audio Fixed By Re-Boot
Moral of the story: make sure the input audio is immaculately clean or it will sound worse in surround! Audio fixed by re-boot Re-booting sometimes fixes audio problems by interrupting the AES3 signals, thereby causing equipment downstream to re-lock to the incoming signals. Selecting a preset with minimal processing (i.e., Protection Limit) may shed further light on the problem. -
Page 92: Chapter 10: Specifications
Chapter 10: Specifications Specifications Processing AMX 5.1 Instance: 5.1+2+2 with up to 2 downmix outputs, dual-path upmixing and SAP/DVS capability. AMX2.0 Instance: Structure 2+2+2 with Auto SAP/DVS with 3 downmix outputs and SAP/DVS capability. AMX5x2 Instance: 2+2+2+2+2 with 2 downmix outputs and SAP/DVS capability. AEROMAX : ITU-R BS.1770 and EBU R128-compliant loudness control via ®... - Page 93 Signal levels per SMPTE 276M/ AES-3ID-2001 All I/O can be assigned as needed Single SDI I/O path Signal levels per SMPTE 292M / 259M; Auto-sensing HD or SD De-embed up to 16 audio channels from SDI, process and/or encode, and re -embed (AERO.10, AERO.100, up to 16 channels AERO.2000)
-
Page 94: Latency
Frequency 20 Hz – 20 kHz +/-1 dB (Protection Limit preset). Response Level Balanced Audio, +4 dBu ref 0.775V nominal, +18 dBu maximum Input: Balanced Audio, +4 dBu ref 0.775V nominal, +18 dBu maximum Output: DB9 (pinout described below) Connector Physical Unit Dimensions... -
Page 95: Connector Pinouts
Nielsen watermark encoding does not cause additional latency. Verance Aspect watermark encoding adds 26 ms additional latency. Disabling sample rate conversion (SRC) for any AES input decreases the latency on that pair by 1.5 ms. Note! If a Dolby encoded bitstream is connected to an AES input the SRC must be disabled. - Page 96 GPI E (Active Low) GPI E (Active Low) Ground GPI F (Active Low) Ground GPI G (Active Low) GPI H (Active Low) GPO A No Connection GPO B Status OK GPO C No Connection GPO D Ground GPO E +5 V, 150 mA Status OK GPO A GPO B...
- Page 97 No Connection Ground No Connection Ground Ground AES 9/10 In Ground AES 11/12 In Ground AES 13/14 In Ground AES 15/16 In Ground AES 9/10 Out Ground AES 11/12 Out Ground AES 13/14 Out Ground AES 15/16 Out Ground Ground Ground Ground Ground...
- Page 98 Function Left In + Right In + Left Out + Right Out + GND / Shield Left In - Right In - Left Out - Right Out - Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the Double-D symbols are registered trademarks of Dolby Laboratories All other trademarks are registered trademarks of their respective owners.
