- Page 1 Disc Mulcher Operation and Maintenance Manual Revision Date: Nov. 2024...
-
Page 2: Table Of Contents
Modifications to Equipment ......................2 ABOUT THE Disc Mulcher ATTACHMENT ............... 3 Attaching the Disc Mulcher to the Carrier Machine ..............3 Removing the Disc Mulcher from the Carrier Machine ............... 3 Disc Mulcher OPERATION ....................4 ... -
Page 3: About This Owner's Manual
Terminology Carrier Machine: The Disc Mulcher can be attached to many different pieces of equipment; therefore, the term “carrier machine” will be used. A carrier machine is any equipment, tractor, or skid steer providing power to the attachment. -
Page 4: About The Disc Mulcher Attachment
ABOUT THE DISC MULCHER ATTACHMENT The Disc Mulcher attachment is intended for use as a brush or tree cutting and clearing tool. The primary use of the Disc Mulcher attachment includes land clearing, landscaping, and grounds maintenance. Use of this equipment in any other manner is contrary to the intended use of the attachment. -
Page 5: Disc Mulcher Operation
• Wear proper safety equipment as required by working conditions and local, state, and Federal laws. Never operate the Disc Mulcher within 600 feet of people, animals, or damageable property. Clear the • area of objects that could become projectiles, such as rocks, bottles, and construction debris. -
Page 6: Equipment Inspection Schedule
NOTE: Shut off the carrier machine and disengage the Disc Mulcher before performing any maintenance. Daily Inspection Inspect the Disc Mulcher by performing a walk around daily before and after use. Use the following inspection checklist as a guideline. After the Disc Mulcher has been attached, check that all latches or locks are closed. -
Page 7: Inspection Checklist
Are there any visible hydraulic leaks? Is there any wire or vines wound under the deck? Are any cracks visible in Disc Mulcher structure? Are the teeth worn, bent, or broken? Has all debris been removed from the motor area? ... -
Page 8: Parts Diagrams And Lists
DISC MULCHER - PARTS BREAKDOWN LOCATED INSIDE BODY (28) 635-3-0149-KIT IN FLYWHEEL (4) 635-3-0149-KIT IN BODY... - Page 9 DISC MULCHER - PARTS BREAKDOWN ITEM NO. PART NUMBER DESCRIPTION QTY. 635-3-0066 BOLT PLATE HW-.750-16X3.0G8TB 3/4"-16X3" G8 TAP BOLT 635-2-0002 BALANCED - FLY WHEEL SUB ASM 635-2-0025 MULCHER SPINDLE SHAFT HW-.750-16NYLG8 3/4"-16 NYLOCK NUT G8 635-2-0103 DISCHARGE ASM 635-2-0001 DISC MULCHER BODY...
-
Page 10: Drive Assembly - Parts Breakdown
DRIVE ASSEMBLY - PARTS BREAKDOWN... - Page 11 DRIVE ASSEMBLY - PARTS BREAKDOWN ITEM NO. PART NUMBER DESCRIPTION QTY. 635-2-0025 MULCHER SPINDLE SHAFT HW-.375-16X.75FS 3/8"-16 X 3/4" FLAT HEAD CAP SCREW 612-3-0063-2 SEAL PROTECTION RTD-52625TA-H OIL SEAL 612-3-0054-2 594A TAPERED BEARING 612-3-0053-2 592 TAPERED BEARING RACE HW-.750-16NYLG8 3/4"-16 NYLOCK NUT G8 612-2-0024 BEARING HOUSING HW-.750-16X2.5G8TB...
- Page 12 TOOL HOLDERS AND MULCHER TEETH 635-3-0052-KIT 635-3-0053-KIT CARBIDE TOOTH KIT HIGH SPEED STEEL TOOTH KIT (ALTERNATE OPTION) (STANDARD OPTION) TORQUE TO TORQUE TO 120 FT*LBS 120 FT*LBS ITEM NO. PART NUMBER DESCRIPTION QTY. ITEM NO. PART NUMBER DESCRIPTION QTY. 635-3-0052 MULCHER TOOTH - CARBIDE 635-3-0053 MULCHER TOOTH - HSS...
- Page 13 PM RELIEF BLOCK RH - PARTS BREAKDOWN ITEM NO. PART NUMBER DESCRIPTION QTY. H-240718 PM RELIEF BLOCK H-6409-12 -12 MORB PLUG H-RPGCLWN-1750 -1750 PSI RELIEF X SUN T-3A H-6815-16-16 -16 MORB ADJ X -16 FORB 90 O-RINGSAE-219 O-RINGSAE-219 90A H750-FT22-12-12 12 MALE ORB TO 12 JIC MALE 90 H750-FT22-16-12 12JICM-16ORBM 90DEG...
- Page 14 PM RELIEF BLOCK LH - PARTS BREAKDOWN ITEM NO. PART NUMBER DESCRIPTION QTY. H-240718 PM RELIEF BLOCK H-6409-12 -12 MORB PLUG H-RPGCLWN-4500 -4500 PSI RELIEF X SUN T-3A H-6801-16-16 16 JICM-16ORBM 90DEG O-RINGSAE-219 O-RINGSAE-219 90A H750-FT22-12-12 12 MALE ORB TO 12 JIC MALE 90 H750-FT22-16-12 12JICM-16ORBM 90DEG...
-
Page 15: Skid Pro Attachment Warranty
This warranty shall not apply to any attachment’s wear items, or attachments that have been repaired or altered outside the Skid Pro factory in any way, or that has been subject to misuse, negligence or accident beyond Skid Pro’s recommended use and/or machine rated capacity. - Page 16 PO BOX 982 Alexandria, MN 56308 Phone: 877-378-4642 FAX: 320-759-1057 www.skidpro.com sales@skidpro.com Skid Pro Disc Mulcher Rev. 11:24 Page 13...
