IRHD M-METHOD/MICRO-SIZE/DUROMETER HARDNESS: TYPE-A/E/E2/FO/OO
INTERNATIONAL RUBBER HARDNESS TESTER
-- ITEMS CONTAINED --
GX-700 Main unit
AC adapter
Power cord
Measuring table (ZY-086)
Plunger (ZS-121) x 2
PC connecting cable (ZE-119)
Transport jig
Software CD
Operation manual
Warranty
DUROMETER HARDNESS TESTER
SmartTester
OPERATION MANUAL
GX-700
Q-060
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TECLOCK SmartTester GX-700
Summary of Contents for TECLOCK SmartTester GX-700
- Page 1 IRHD M-METHOD/MICRO-SIZE/DUROMETER HARDNESS: TYPE-A/E/E2/FO/OO INTERNATIONAL RUBBER HARDNESS TESTER DUROMETER HARDNESS TESTER SmartTester GX-700 OPERATION MANUAL -- ITEMS CONTAINED -- GX-700 Main unit AC adapter Power cord Measuring table (ZY-086) Plunger (ZS-121) x 2 PC connecting cable (ZE-119) ...
- Page 2 ・ This manual may contain inaccuracies or typographical errors. Any of your questions and comments on the contents of this manual should be directed to TECLOCK Corporation. ・ Regardless of the above, TECLOCK Corporation is exempt from any responsibilities for results by using this product.
-
Page 3: Precautions For Safety
Precautions For Safety In order to use this product properly and protect you and others from injuring, and the properties from damaging, observe the followings. Be sure to read thoroughly the descriptions of operation manual, and keep this operation manual in such place that it is accessible easily. Precaution Indications Improper handing in failure to heed this warning may lead to serious injury or Warning... - Page 4 Precaution Strict observe the warning or caution indications instructed by PC or printer manufacturer if this product is connecting to a PC or printer to use. Strict Observance Do not disassemble nor modify this product. Contact to a sales shop for repairing. It may require a repair for payment even within the Disassembly guarantee period if the product has been disassembled or modified.
-
Page 5: Before Use
Before Use Icons used in this manual In this manual, the additional information is described by using the following icons. Precaution Precaution items are described. MEMO Convenient or additional items are described. * In this manual, the displays of software are described in accordance with the Windows XP (Service Pack 2). -
Page 6: Table Of Contents
Table of Contents Features of This model ·················································································· 7 Name of Each part ························································································· 9 Front side of Main unit ........................9 Backside of Main unit ........................9 Operation panel ..........................10 LCD ..............................10 Operating procedure of Main unit ··································································· 11 Preparation for Main unit ....................... -
Page 7: Features Of This Model
Also, this model can be used for the measurement (the approximation with a similar figure of approximate 1/8.3) approximating to the measurement method of the durometer hardness type A/E (AO) [JIS K 6253/ISO7619], E2/F0 [TECLOCK standard] and OO [ASTM/D2240]. Additionally, this can measure with any setting fluctuating load value. - Page 8 Settable to a different value from the values in the HD S1 mode and HDS2 mode. By connecting a dedicated potable printer to the main unit directly, the measured data can be printed out. As for the software By installing the accessory software (GS-680 PC Application) in your PC, all of the operations are controllable from the PC side.
-
Page 9: Name Of Each Part
Name of Each part Front side of Main unit Name Description Spindle Part attaching the plunger. Fix the part in transporting. Plunger (Probe) Part contacting a specimen for measurement. Foot(Presser foot) Annulated part contacting a specimen and applying a pressure. Measurement table Part placing a specimen to measure. -
Page 10: Operation Panel
Operation panel Name Description To display the measuring mode and measured value. [UP] button To raise the plunger. To increase a value in setting. [DOWN] button To lower the plunger. To decrease a value in setting. [SET] button To fix a set value. Press more than 2 seconds to enter “RS-232C selecting mode”. -
Page 11: Operating Procedure Of Main Unit
Operating procedure of Main unit This chapter describes the operating procedure for the measurement using this model solely. For the procedure using with the PC connected, refer to “Operating procedure for Software” (P.20). Preparation for Main unit Remove all of the packaging materials. Mount the measurement table onto the main unit. -
Page 12: Measuring Procedure
Measuring procedure This chapter describes the measuring procedure. Turn the power of main unit ON. The LCD lights up to indicate the measurable condition. An error (ERR11) is indicated when the power is turned on if the plunger is located at the most top end. - Page 13 Press the [START/STOP] button to start the measurement. The lamp of [START/STOP] button lights up during the measurement. The lamp goes out and the measurement result is indicated on the LCD panel when the measurement is completed. It ends at that time if the number of measurement(s) is one time.
-
Page 14: Measuring Modes
Measuring modes This model has other measuring modes, which can change the measuring conditions, than the hardness measurement (the setting at shipping) in compliance with the IRHD M-method. The measuring mode is selectable from the following 7 modes. Measuring mode Description IRHD Measuring mode in compliance with the IRHD M-method. - Page 15 Changing procedure of measuring mode The measuring mode is changeable by pressing the [MODE] button on the operation panel. The mode is changed in the following order, and returns to the IRHD mode following the HDS3 mode. ...
- Page 16 Set the Major load time (sec) with the [UP] / [DOWN] button then the [SET] button. Set the Major load time within 1-999sec/0 (Limitless). After the set is fixed, it enters in the condition that the - NG (Lower limit judgment value) can be set.
- Page 17 Set the Creep judgment Hardness value with the [UP] / [DOWN] button then the [SET] button. Set the Creep judgment Hardness value within 0.1-9.9. When the set is fixed, it enters in the condition that the Creep judgment Time value can be set. Set the Creep judgment Time value with the [UP] / [DOWN] button then the [SET] button.
-
Page 18: Time Setting
Set the - NG value within 30.0-100.0. “NG” is judged and an error (-NG) occurs if the measured value is less that this value. When the set is fixed, it enters in the condition that the + NG (Upper limit judgment value) can be set. -
Page 19: Error Clearing
Error clearing When an error occurs due to some reason, the indications on the LCD turn red. The error code corresponding to the error is displayed on the LCD and the measurement operation is stopped. Eliminate the cause of error, and then press the [DIPS/ERR-CLR] button. If the cause of error is successfully eliminated, the error condition is cleared and it in the measurable condition. -
Page 20: Measured Data Printing
Measured data printing This model has a feature to print out the measured data by connecting to the following printer with a serial interface in compliance with RS-232C. Connectable printer Connecting cable CITIZEN : CBM-910 II Separate option : ZE-118(cable for printer connection) RS-232C Communication mode In order to print out the measured data with the printer, the communication setting is required to be set for the RS-232C. - Page 21 Select ON/OFF of plunger error with the [UP] / [DOWN] button then the [SET] button. When “PS on” is selected, a plunger error gets effective. For the measurement of conductive rubber or the like, select “PS off” to make the plunger error ineffective. After the setting is completed, it returns to the original display.
-
Page 22: Operating Procedure Of Software
Operating procedure of Software The installing procedure and operating procedure of accessory software “GS-680 PC Application” are described. Required system The following hardware and system are required to operate “GS-680 PC Application”. Serial port in compliance with RS-232C ... -
Page 23: Installing And Starting
[Yes]. The installation is completed. If the PC does not restart automatically, restart it manually. When the software is uninstalled, delete “TECLOCK GS-680” by using the functions of control panel. Windows 2000: [Control Panel] – [Add/Remove Programs] Windows XP: [Control Panel] – [Add or Remove Programs] MEMO Windows Vista: [Control Panel] –... -
Page 24: Starting Procedure
This software can be also stared by clicking the followings: [Start] button - [All Programs] – [TECLOCK GS-680] – [TECLOCK GS-680]. MEMO If the following message is displayed at starting, the set of serial port of PC does not match up to the set on the software. - Page 25 As a confirming message is displayed, click [Yes]. The user parameters are set to the main unit. Select "Mode" on the main display (Measuring Mode). Select the measuring mode from “IRHD”, “S1”, “S2”, “S3”, “HDS1”, “HDS2” and “HDS3”. Select "Method" on the main display (Measurement). When the number of measurement(s) is plural times, select either “Median value”...
-
Page 26: Parameter Setting Display
Parameter setting display Symbol Item Description Minor Load Time Set value of Minor load time Major Load Time Set value of Major load time Minor Load Set value of Minor load value Major Load Set value of Major load value Lower Limit - NG set value Upper Limit... -
Page 27: Main Display
Main display Item Item (Detail) Description Menu bars [File] Menu Measured data can be saved and printed. [Edit] Menu Measured data can be edited and exported. [View] Menu Graph switchover in the S3 mode and Display of measured data (Hardness/Indentation depth) are enabled. Execute Graph switchover in the S3 mode before measure. - Page 28 Measured data Measured data is displayed. This can be switched between Display “Hardness” and “Indentation depth (mm)” by using the button or the [View] menu. Control [Start] Button/[Stop] Button Measurement is started. In measurement, this switches to [Stop] button display and stops measurement. [Error Reset] Button In case of Error, Error is cleared.
-
Page 29: Measured Data Saving
Measured data saving The measured data can be saved with a name. The saved data can be opened by using “GS-680 PC application” and updated by adding the measured data. Saving Execute the measurement then display the data. The measured result is displayed on the “Measured data” window. Click [Save as] from the [File] menu. -
Page 30: Measured Data Printing
Measured data printing The measured data can be printed out by the printers set in Windows. The ”Print preview” function, which displays the print image prior to printing, is also available. Printing Execute the measurement and display the data. The measured result is displayed on the [Measured data] window. -
Page 31: Measured Data Editing
Measured data editing The measured data is editable on the [Data edit] window. Data editing Click [Edit] of the [Edit] menu or the button to display the [Edit] window. The data can be modified by double-clicking each item. The followings are operable with the buttons on the [Edit] window. ... -
Page 32: Communication Parameter Setting
Communication parameter setting This setting is for the RS-232C serial interface. It is required to match up to the PC set connected. If the following message is displayed at starting, the set of serial port of PC does not match up to the set on the software. Adjust the MEMO serial port set to the PC with [Communication Parameter settings]. -
Page 33: Pc Logging
PC logging The latest measured data, which has been recorded in the internal memory of this product, is read in automatically, and then saved in the PC as a CSV formatted file. Put a check to [Enable logging PC] of the parameter setting display. The log data is read from this product to the PC per measurement. -
Page 34: Appendix
・ Request a transporter who can transport precise equipments to transport this product, with notifying in advance that this is a precise equipment. * TECLOCK Corporation will not bear any responsibilities for problems caused in transporting by a customer. ... -
Page 35: Replaceable Parts/Optional Parts
Replaceable parts/Optional parts For this product, the following replaceable parts and optional parts are available. For purchasing, contact to a sales shop. Part name Part No. Remarks Plunger ZS-121 Contained at shipping IRHD-M method Plunger ZS-128 Type E, E2 approximation, SR0.6 Plunger ZS-129... -
Page 36: Specifications
Hardness test: JIS K 6253/ ISO 48/ IRHD M-method Durometer hardness (approximate 1/8.3 Similar figure approximation) Type A/E (A/O): JIS K 6253/ ISO 7619, Type E2/FO: TECLOCK standard Type OO: ASTM/D2240 Durometer hardness the force values(Durometer hardness 0-100) Type A/E (A/O):7.9-115.9mN, Type E2/FO:7.9-61.9mN, Type OO:2.9-16mN ... - Page 37 Set values at shipping Communication parameters Setting item Set value at shipping Communication set PC-on (PC connection) Communicating speed 38400 (bps) Parity Po (Parity: Odd) Plunger-SW detection PSon (Error detecting) Measuring parameters IRHD Minor load time (sec) Major load time (sec) Lower Limit (Hardness value) 30.0 30.0...
-
Page 38: How To Use Transport Jigs
Detailed Description of Detaching Fixture Detaching Fixture have to be installed during GX-700 is under transportation in order to keep the components correctly. １．How to remove the fixture 1.1 Turn on Main Switch 1.2 An error indication appears “ERR 93 or 23” 1.3 Push the Rising Switch, then releasing the foot from the fixture 1.4 Remove the lower fixture 1.5 Remove the rubber fixture from the spindle... - Page 39 MEMO...
- Page 40 TECLOCK Corporation http://www.teclock.co.jp HEAD OFFICE & FACTORY: 2-10-3 NARITA-MACHI, OKAYA-SHI, NAGANO-KEN 394-0042 PHONE: 81-266-22-4911, FACSIMILE: 81-266-22-4914, E-mail: teclock@teclock.co.jp...
