IF YOU HAVE A WIRELESS
REMOTE
Your remote is already paired
with your power base. Follow
the below instructions for
replacement remote pairing.
STEP 1
Place batteries into the remote
control (3 x AAA batteries).
STEP 2
Ensure the power base is plugged
into a functioning outlet.
STEP 3
Press and hold the pairing button on
the control box until the indication
light blinks.
STEP 4
Press any button on the remote
control. When the control box light
turns solid, the remote should be
successfully paired.
STEP 5
Test and verify the remote is
correctly paried by activating
functions of the power base. You
have now completed the pairing
process.
How To Unpair a Remote
To unpair a remote, simply pair
another remote twice, to unpair the
previously paired remote.
IF YOU HAVE A WIRED REMOTE
If you have a wired remote and want
to connect to 2 power bases that will
move in tandem as a single unit, follow
the below instructions. For reference,
bases will be refered to as "Base A"
and "Base B", but are not acutally
label as such in person.
STEP 1
Make sure both Base A and Base B
are set up and positioned closely
side-by-side together. (Ignore this step
for Split Top Queen setup. For the
following steps, Base A/B will refer to
Side A/B).
STEP 2
Unplug both wired remote
controls from their lift motors and set
aside.
STEP 3
Remove and extend one of the
provided Y-Cables.
B
A
STEP 4
Plug in the "A" output of the Y-Cable
into Base A control port.
STEP 5
Plug in the "B" output of the Y-Cable
into Base B control port.
STEP 6
Plug one of the provided hardwired
remote controls into the "Control Input"
side of the Y-Cable.
STEP 7
Route the control cable to your
preferred side of the bed.
4
Emergency Power Down
Feature
Your power base has an emergency
lowering feature in the event that
your power base is in the raised
position and has lost power due to a
power outage.
STEP 1
Locate and remove the cover for the
9 volt batteries on the control box or
power supply box.
STEP 2
Install the two (2) alkaline 9 volt
batteries and reinstall the battery
cover.
WARNING: DO NOT USE
RECHARGEABLE BATTERIES
IN THE CONTROL BOX OR
POWER SUPPLY FOR THE
EMERGENCY POWER DOWN
FEATURE.
STEP 3
Press the "FLAT" button or the
individual lowering buttons.
STEP 4
Control
Input
Once the bed returns to the flat
position, remove the batteries from
the Control box.
NOTE: DO NOT raise the base
when powered with only backup
batteries. The batteries are only
intended to lower the base in
case of emergency.
