- Page 1 User Manual RPC-7 Gauge Kit 07GK001-010 07GK001-010 Rosenberger Hochfrequenztechnik GmbH & Co. KG Tel. : +49 8684 18-0 Page P.O.Box 1260 D-84526 Tittmoning Germany www.rosenberger.com Email : info@rosenberger.com 1 / 11...
-
Page 2: Table Of Contents
Handling and Storage 4. Gauge Kit Service Calibration interval Spare parts Where to send a Kit for Re-Calibration / Repair Extent of Rosenberger Re-Calibration Services Rosenberger Hochfrequenztechnik GmbH & Co. KG Tel. : +49 8684 18-0 Page P.O.Box 1260 D-84526 Tittmoning Germany www.rosenberger.com... -
Page 3: General Information
Gauge Kits are used to check or measure the connector gauge of calibration standards, adapters, test port adapter and cables for protrusion or recession of connector pins with RPC-7. A protruding connector pin may mechanically damage the counterpart it is connected to, while significant recession in an RF connection degrades the RF performance. -
Page 4: Kit Contents
/ international standards. An Accredited Calibration is not available. 2. Specifications Mechanical specifications are defined for all gauges in their specific data sheets. Rosenberger Hochfrequenztechnik GmbH & Co. KG Tel. : +49 8684 18-0 Page P.O.Box 1260... -
Page 5: Gauging Connectors
NOTE: At no time should the pin depth of the connector be protruding. Inner conductor recession This will result in poor reflection and possibly unreliable contact. Rosenberger Hochfrequenztechnik GmbH & Co. KG Tel. : +49 8684 18-0 Page P.O.Box 1260... - Page 6 Gauge Kit 07GK001-010 3.1.2 Gauges The Rosenberger gauges are of screw-on type in plug and jack version. They can be used to gauge calibration standards as well as test ports, test port cables, adapters and DUTs. Naming convention: A “gauge plug” (male) is used to measure a DUT with plug (male) connector. The gauge itself has a jack (female) connector and needs a gauge block with plug (male) connector.
- Page 7 Gauge Kit 07GK001-010 Figure 3-1 shows a set of gauge and gauge blocks for the RPC-7 connector. When the gauge block is connected to the gauge a zero reading should be indicated and both pointers show values close to “0”.
- Page 8 Recession is the condition in which the centre conductor is set back from the outer conductor mating plane. The amount of unwanted reflections is directly proportional to the pin depth. Pin depth limits are defined for all calibration standards in the specific data sheets. Rosenberger Hochfrequenztechnik GmbH & Co. KG Tel. : +49 8684 18-0 Page P.O.Box 1260...
- Page 9 0.025mm forward from the 0.128mm forward from the conductor mating plane outer conductor mating outer conductor mating plane plane Rosenberger Hochfrequenztechnik GmbH & Co. KG Tel. : +49 8684 18-0 Page P.O.Box 1260 D-84526 Tittmoning Germany www.rosenberger.com Email : info@rosenberger.com 9 / 11...
- Page 10 • Do not touch mating plane surfaces. Natural skin oils and microscopic particles of dirt are easily transferred to a connector interface and are very difficult to remove. Rosenberger Hochfrequenztechnik GmbH & Co. KG Tel. : +49 8684 18-0 Page P.O.Box 1260...
- Page 11 In case of re-calibration or repair contact your local Rosenberger sales office. Please inform them about any known problem. If there is no local Rosenberger sales office available a request can be set up on the Rosenberger homepage. Please use the search topic “Calibration Request Form” at www.rosenberger.com 4.4 Extent of Rosenberger Re-Calibration Services...
