  • Page 1 TR-3 OWNER/OPERATOR MANUAL...

  • Page 2: Operation

    Department at 800-930-5623, Ext. 229, should you need assistance. Please have your loader Serial Number available when calling our Parts Department. See “How to Find the Serial Number” in this section of the manual. Petersen Industries, Inc. TR Owner's Manual...
  • Page 3 Single Cylinder Trash Bucket Rotator Diagram Single Cylinder Bucket Manifold Diagram Single Cylinder Bucket Jaw Diagram Big Bite Bucket Diagram P. I. Self-Winding Tarp Roller Diagram Miscellaneous Parts Diagrams and Bill of Materials Notification of Transfer of Ownership Petersen Industries, Inc. TR Owner's Manual...
  • Page 4 WARRANTY: VENDOR INSERTS: Hydraulic Pump Information PTO Information Hydraulic Hoist Information Petersen Industries, Inc. TR Owner's Manual...
  • Page 5 Operators must be trained by an experienced trash loader operator who is familiar with all aspects of operation, safety, and maintenance of this equipment. Keep children, visitors and untrained personnel away from the equipment. Petersen Industries, Inc. TR Owner's Manual...
  • Page 6 22.5 degree tangent angle out the rear tire. It is however the responsibility of the end user to verify that the mud flaps comply with requirements for the area that the truck is to be operated within. Petersen Industries, Inc. TR Owner's Manual...
  • Page 7 Consult the truck manufacturer's manual for vehicle checks recommended by them. Any insufficiencies found during this inspection must be corrected prior to use of the equipment. Petersen Industries, Inc. TR Owner's Manual...
  • Page 8 The result of unexpected component failure could be damage to the equipment and/or serious bodily injury or death. Petersen Industries, Inc. TR Owner's Manual...

  • Page 9: Flow Restrictors

    3. Excessive swing speed causes excessive wear on the main boom/tip boom connecting bolt. Swing Actuator Restrictors: HA36 Actuator Restrictor Size = 0.056” Dinamic Oil Restrictor Size = 0.110” Petersen Industries, Inc. TR Owner's Manual...
  • Page 10 Some signs of restrictor removal or modification are: 1. Excessive bucket rotation speed. Bucket rotation must not exceed 15 RPM. 2. Broken bucket rotator motor mounting bolts. 3. Broken bucket motor shaft and/or housing. Bucket Restrictors Petersen Industries, Inc. TR Owner's Manual...
  • Page 11 FAILURE TO FOLLOW THE PRECEDING INSTRUCTIONS REGARDING COUNTER-BALANCE VALVE ADJUSTMENT AND/OR REPLACEMENT, COULD RESULT IN THE BOOM FALLING ONCE THE CARTRIDGE VALVE IS REMOVED, WHICH COULD RESULT IN DAMAGE TO THE EQUIPMENT OR SERIOUS PERSONAL INJURY OR DEATH. Petersen Industries, Inc. TR Owner's Manual...
  • Page 12 Improper lock collar installation and/or the improper operating practices listed above, could result in the head assembly being pulled up out of the pedestal assembly. The Petersen Industries, Inc. TR Owner's Manual...

  • Page 13: Back-Up Alarm

    “BOOM-UP” ALARM A warning system that alerts the loader operator when the boom is not stowed properly for travel. A sensor is installed on the boom, and an audible alarm and red light in the Petersen Industries, Inc. TR Owner's Manual...
  • Page 14 Set the outriggers out and down to stabilize the truck (Do not lift the truck). Swing the boom over to the side of the truck with the boom fully extended. Lift the main boom to desired height (typically the highest point is at the tip boom stop). Petersen Industries, Inc. TR Owner's Manual...

  • Page 15: Safety Symbols

    The safety decals are used to show the consequence of human interaction with a hazard in terms of: 1. The degree of severity. (minor injury, severe injury, death) Petersen Industries, Inc. TR Owner's Manual...
  • Page 16 Immediate hazards which WILL result in severe personal injury or death. WARNING Hazards or unsafe practices which COULD result in severe personal injury or death. CAUTION Hazards or unsafe practices which COULD result in minor personal injury or product or property damage. Petersen Industries, Inc. TR Owner's Manual...
  • Page 17 Petersen Industries, Inc. TR Owner's Manual...
  • Page 18 Petersen Industries, Inc. TR Owner's Manual...

  • Page 19: Throttle Control

    Air Shift Control – The PTO is engaged when the switch is moved to apply air to PTO, the “On” position. The PTO is disengaged when the switch is Petersen Industries, Inc. TR Owner's Manual...

  • Page 20: Park Brake

    PTO, apply the service brakes, disengage the parking brake, and then select the appropriate transmission gear. PARK BRAKE The truck brake must be set before leaving the cab for any reason. Petersen Industries, Inc. TR Owner's Manual...
  • Page 21 (2) handles on the left operate the left outrigger. The following decal shows the control handle configuration, and the arrows indicate the direction to push or pull the handle for each function. Petersen Industries, Inc. TR Owner's Manual...
  • Page 22 After a slow, smooth start, move the valve handle control to extreme for full speed. Just before stopping movement, move valve handle control smoothly back to the neutral position. Petersen Industries, Inc. TR Owner's Manual...
  • Page 23 On units equipped with dual controls, always operate the loader on the side closest to the debris being loaded. Do not store any collectibles on the operator's platform, as they can create a tripping hazard or become lodged in the controls. Petersen Industries, Inc. TR Owner's Manual...
  • Page 24 Push the handle forward to lower the right vertical outrigger foot. Pull the handle back to raise the right vertical outrigger foot. Body Dump: Pull the handle back to raise the dump body. Push the handle forward to lower the dump body. Petersen Industries, Inc. TR Owner's Manual...
  • Page 25 Push handle forward to lower tip boom. Bucket Grab: Move handle right to open bucket. Move handle left to close bucket. Bucket Rot.: Twist handle clockwise to rotate bucket right (clockwise). Twist handle counter-clockwise to rotate bucket left (counter-clockwise). Petersen Industries, Inc. TR Owner's Manual...
  • Page 26 Always operate the loader on the side closest to the debris being loaded. Do not store any collectibles on the operator's platform, as they can create a tripping hazard or become lodged in the controls. Petersen Industries, Inc. TR Owner's Manual...
  • Page 27 Bucket Grab: Move handle right to open bucket. Move handle left to close bucket. Bucket Rot.: While holding the thumb switch move handle right to rotate bucket right (clockwise) or move handle left to rotate bucket left (counter-clockwise). Petersen Industries, Inc. TR Owner's Manual...

  • Page 28: Loading Sequence

    Slowly lift bucket control and confirm the rotating lock mechanism has engaged the lower lock bar on the cart. Complete the dump cycle if engaged, otherwise lower the cart and reposition it. Locked carts will automatically release before they contact the ground. LOADING SEQUENCE Petersen Industries, Inc. TR Owner's Manual...
  • Page 29 The operating procedures set up in this manual are Petersen's recommendations and do not necessarily cover employer and governmental regulations. Each operator must know and observe those regulations.
  • Page 30 Remember, power lines deflect in winds and additional clearances must be allowed. Death or serious injury may result from contact or arcing due to inadequate clearance to anyone working on or around the loader. All Petersen Industries, Inc. TR Owner's Manual...
  • Page 31 Never use controls as handholds. Do not mount the machine if handholds or steps are broken or missing. Repair them first. Failure to heed these instructions can result in serious personal injury or death. Petersen Industries, Inc. TR Owner's Manual...
  • Page 32 3. Lift and swing the load over the dump body. In order to minimize the height and stress on the boom, it is recommended that the tip extension be retracted prior to swinging the load. It is recommended to load the front of the body first. Petersen Industries, Inc. TR Owner's Manual...
  • Page 33 Do not attempt to lift loads exceeding manufacturer's recommended safe working capacity. Do not impose lateral loads on the boom. Do not use stability to determine safe working load. Petersen Industries, Inc. TR Owner's Manual...
  • Page 34 To cover the load: When using a Petersen manufactured and installed load cover, please follow these procedures: 1. Knuckle the bucket to the front of the dump body. 2. Hook the tarp chain to the hook on the bucket. 3. Extend the boom to cover the debris, and rest the bucket on the load.
  • Page 35 Once the bucket has been properly stowed for travel, retract all outriggers, disengage the PTO, and pickup any safety cones or markers that were used. Release the parking brake, and you're ready to travel to the dump site. Petersen Industries, Inc. TR Owner's Manual...
  • Page 36 Petersen Industries, Inc. TR Owner's Manual...
  • Page 37 11. When you have finished dumping the load, lower the dump body. Stow the boom and bucket in the dump body with bucket open and resting on body floor. 12. Raise and retract the outriggers, and disengage the power-take-off. Petersen Industries, Inc. TR Owner's Manual...
  • Page 38 Do not dump the load until the rear body doors are latched open. The doors and body hinges can be damaged if doors are allowed to swing freely during the dumping procedure. Do not travel with rear body doors open. They must be closed and locked for travel. Petersen Industries, Inc. TR Owner's Manual...
  • Page 39 Do not disconnect hydraulic connections under pressure. Hot hydraulic fluid can cause serious injury. Stay clear of hydraulic leaks as high pressure and hot hydraulic fluid can cause serious injury. Always use dump body prop(s) before servicing or repairing body or hoist. Petersen Industries, Inc. TR Owner's Manual...
  • Page 40 Disconnecting, removing, or disabling any part or component which controls the speed of the loader is a misuse of the loader. Petersen Industries, Inc. TR Owner's Manual...
  • Page 41 After service adjustment, and repairs, the loader shall not be returned to service until all guards have been reinstalled, trapped air removed from the hydraulic system if required, safety devices reactivated, and maintenance equipment removed. Petersen Industries, Inc. TR Owner's Manual...
  • Page 42 Oil level should be two to three (2 to 3) inches from top of tank. Planetary Gearbox Oil should be visible on site glass. Hydraulic Oil = AW32 Gear Oil = 80W Gearlube Petersen Industries, Inc. TR Owner's Manual...
  • Page 43 The Petersen rotating head assembly has special high strength steel components that are welded together. After welding, the entire assembly receives post-weld heat treatment.
  • Page 44 (These requirements are in addition to the 600 hour service requirements.) Change oil in planetary gearbox (if Drain existing oil from swing gearbox applicable) and replace with 7 quarts of 80W Gearlube Change hydraulic oil Petersen Industries, Inc. TR Owner's Manual...
  • Page 45 Suspend the outrigger assembly from an overhead hoist. Using a forklift and chains pull the outrigger leg weldment out from the horizontal tube. 6. Place the vertical outrigger leg weldment on a flat work surface. Petersen Industries, Inc. TR Owner's Manual...
  • Page 46 How to Find the Serial Number The serial number for your unit can be found in two places. The number is stamped on the side of the base plate of the head assembly, and is also stamped on the base plate of the pedestal assembly.
  • Page 47 4400 lb Tire pressures must be in accordance to the tire manufacturer’s recommendations. 20 ft 1800 lb * 3200 lb TOLERANCES PETERSEN INDUSTRIES INC. MODEL SL 3 4000 S.R. 60 WEST 1 DEC. 0.100 RADIUS MODEL SL 2 LAKE WALES, FL. 33859-8234 TIP EXTENSION RETRACTED TIP EXTENSION EXTENDED 2 DEC.
  • Page 48 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: TL3 MAINTENANCE POINTS PART NUMBER: SCALE: 01 00 00 008 2 DRAWN BY: APPROVED BY: DATE: SHEET: 1 OF 4 8/24/2016 Last Printed: 1/3/2018 by bburtle...
  • Page 49 Hydraulic Tank ISO 32 Hyd Oil Fill to Max Level 40 Hours Hydraulic Filter OT03008 Replace 1000 Hours PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 Hydraulic Tank Breather OT05007 Replace 1000 Hours TEL: (863) 676-1493 FAX: (863) 676-6844...
  • Page 50 ITEM # ITEM DESCRIPTION NUMBER OF GREASE POINTS AND FREQUENCY TOP SHAFT ROTATOR 1 FITTING EA. SIDE GREASE WEEKLY PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: ROUTE ASSISTANT MECHANISM GREASE POINTS...
  • Page 51 2 FITTINGS EA. SIDE GREASE WEEKLY TOP SHAFT LINK ARM 2 FITTINGS EA. SIDE GREASE WEEKLY BUCKET ROLLERS 1 FITTING ON EA. ROLLER 2 PER SIDE GREASE WEEKLY PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844...
  • Page 53 Labeled Wire and Color List Wire Label Part Number Printed on Wire Wire Gauge Wire Color TCM 143 EL03005LGR-143 Light Green TCM 145 EL03005BL-145 Blue TCM 130 EL03005YE-130 Yellow ENGINE KILL EL03005GY-K Gray THROTTLE EL03005TN-THR HORN EL03005WH-H White STROBE Orange WORK LIGHT EL03005OR-WL Orange...
  • Page 54 IN/OUT UP/DOWN 1200 1500 2000 2000 1500 INLET PETERSEN INDUSTRIES INC. TO CASE DRAIN PORT 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 ON TANK TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: V20 11 SECTION VALVE BANK W/MID INLET - QUADSTICK...
  • Page 55 2000 2000 1500 INLET V20 VALVE ASSEMBLY VA01000001TL FOR ROUTE ASSISTANT PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: V20 11 SECTION VALVE BANK W/MID INLET - QUADSTICK PART NUMBER:...
  • Page 56 RETURN LINE, PLUMB TO RETURN FILTER PRESSURE LINE TO LOADER VALVE BANK THAT CONTAINS PRESSURE LINE FROM FRONT BUCKET GRAB PUMP SECTION PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 ROUTE ASSISTANT LIFT TITLE:...
  • Page 57 IN/OUT UP/DOWN 2700 1500 1500 2000 2700 1500 PETERSEN INDUSTRIES INC. TO CASE DRAIN PORT 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 ON TANK TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: V20 11 SECTION VALVE BANK WITH MID INLET - STANDARD...
  • Page 58 UP/DOWN IN/OUT IN/OUT UP/DOWN 2700 1500 2000 1500 1500 2700 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 RIGGERS RIGGERS RIGGERS RIGGERS TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: V20 11 SECTION VALVE BANK WITH MID INLET - STANDARD...
  • Page 59 RETURN LINE, PLUMB TO RETURN FILTER PRESSURE LINE TO LOADER VALVE BANK THAT CONTAINS PRESSURE LINE FROM FRONT BUCKET GRAB PUMP SECTION PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 ROUTE ASSISTANT LIFT TEL: (863) 676-1493 FAX: (863) 676-6844 CYLINDER...
  • Page 60 DESCRIPTION DATE 010 ASSEMBLY DETAIL A TOLERANCES PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST 1 DEC. 0.100 LAKE WALES, FL. 33859-8234 2 DEC. 0.050 TEL: (863) 676-1493 FAX: (863) 676-6844 3 DEC. 0.010 TITLE: RA, FULL TROUGH ASSEMBLY ANGLE: 1.000 1/32"...
  • Page 61 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: RA, FULL TROUGH ASSEMBLY PART NUMBER: SCALE: 12 11 12 001 0 / 132000 1: 3 0 DRAWN BY: APPROVED BY: DATE:...
  • Page 62 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: RA, FULL TROUGH ASSEMBLY PART NUMBER: SCALE: 12 11 12 001 0 / 132000 1: 2 0 DRAWN BY: APPROVED BY: DATE:...
  • Page 63 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: RA, FULL TROUGH ASSEMBLY PART NUMBER: SCALE: 12 11 12 001 0 / 132000 1: 3 0 DRAWN BY: APPROVED BY: DATE:...
  • Page 64 CLAMP, H/P/C 2-HOLE ASSEMBLY CLH2AP CLH2AP RA, FLOW DIVIDER, LS, MOUNTING BRACKET 42 11 12 103 0 132143 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST RA, TRACK RETAINER HOOK 42 11 12 038 0 132068 LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493...
  • Page 65 NOTE: FOR HA36 12 INCH EXTENDED PEDESTAL SEE PART NUMBER 106116 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: TL GEARBOX HEAD PEDESTAL AND O_R ASSEMBLY PART NUMBER: SCALE: 02 02 13 001 6 / NA...
  • Page 66 SPOOL, OUTRIGGER LEG CYLINDER UPPER 115106 OUTRIGGER COVER PLATE BRACKET 113110 CYLINDER, OUTRIGGER, VERTICAL LEG EXTENSION CY05003 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: TL GEARBOX HEAD PEDESTAL AND O_R ASSEMBLY...
  • Page 67 NOTE: FOR HA36 12 INCH EXTENDED PEDESTAL SEE PART NUMBER 106116 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: HA36, HEAD, PEDESTAL AND O/R ASSEMBLY PART NUMBER: SCALE: 02 02 10 001 8...
  • Page 68 COLLAR - 42 116102 OUTRIGGER VERTICAL LEG COVER PLATE 113107 PIN - OUTRIGGER LEG CYLINDER LOWER PI18122F PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 COTTER PIN, 5/16 X 3 FA020548 TEL: (863) 676-1493 FAX: (863) 676-6844...
  • Page 69 REV. DESCRIPTION DATE 010 ASSEMBLY 17.500 140.113 12.735 TOLERANCES PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST 1 DEC. 0.100 LAKE WALES, FL. 33859-8234 2 DEC. 0.050 TEL: (863) 676-1493 FAX: (863) 676-6844 3 DEC. 0.010 TITLE: MAIN BOOM TL3 ASSEMBLY ANGLE: 1.000...
  • Page 70 BOLT HEX 1/4-20 X 1-1/2 UNC G5 BL304024U520 BL304024U520 HYDRAULIC TUBE, TL MAIN BOOM45 DG - 12" LONG 41 03 05 020 0 TU03002 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST CLAMP SAFETY PLATE CL5G211 CL5G211 LAKE WALES, FL. 33859-8234 BUSHING, 2-1/2"...
  • Page 71 010 ASSEMBLY DESCRIPTION REV. DATE ITEM #24 OPTIONAL FOR STANDARD BUCKET 101.41 12.00 18.61 TOLERANCES PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST 1 DEC. 0.100 LAKE WALES, FL. 33859-8234 2 DEC. 0.050 TEL: (863) 676-1493 FAX: (863) 676-6844 3 DEC.
  • Page 72 HEX BOLT 1-1/4-7 X 7-3/4 GR8 BL120124U87 BL120124U87 BUCKET BRAKE WASHER 4 X 1-5/16 X 1/4 WAF642004 WAF642004 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST BUCKET BOLT NUT 40 00 00 053 1 102454 LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 HEX BOLT 5/16-18 X 2.50 USS G5...
  • Page 73 HEX BOLT 5/16-18 X 2.50 USS G5 BL305040U518 BL305040U518 HEX NUT 5/16-24 SAE STOVERLOCK NUS05S NUS05S PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TL, 16 FOOT TIP BOOM SIDE COVER 41 04 04 074 0 109253...
  • Page 74 030 5" BORE X 32" STROKE X 2.5" ROD 46.000 6.250 STROKE = 32.000 RETRACTED = 42.500 .063 EXTENDED = 74.500 .063 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: 5.0" LIFT CYLINDER PART NUMBER: SCALE:...
  • Page 75 SEAL KIT 2-1/2 X 5 TH10329A 52 14 05 001 0 HPKTH10329A HYDRAULIC, #6 JIC X #8 M OR HF10608JM HF10608JM PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: 5.0" LIFT CYLINDER...
  • Page 76 ROD SEAL 2-1/2 ID X 3 OD X 1/4 ROD WIPER 2-1/2 ID X 3 OD X 0.395 WEAR BAND 2-3/4 OD X 1/2 W X 1/8 CS SECTION B-B PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: 5.0"...
  • Page 77 030 5" BORE X 32" STROKE X 2.5" ROD 6.250 46.000 STROKE = 32.000 RETRACTED = 42.500 .063 EXTENDED = 74.500 .063 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: 5.0" TIP CYLINDER PART NUMBER: SCALE:...
  • Page 78 121167 121167 1/8" STRAIGHT GREASE FITTING HF2002S HF2002S HYDRAULIC, #6 JIC X #8 M OR HF10608JM HF10608JM PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: 5.0" TIP CYLINDER PART NUMBER:...
  • Page 79 PISTON SEAL 4-5/8 ID X 5 OD X .281 GROOVE (1/2) O-RING 1-1/16 X 1/16 WEAR BAND 2-3/4 OD X 1/2 W X 1/8 CS SECTION B-B PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493...
  • Page 80 REV. DESCRIPTION DATE CHANGE CASING WELDMENT 06/05/06 010 ASSEMBLY 61.938 15.626 3.875 4.504 TOLERANCES PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST 1 DEC. 0.100 LAKE WALES, FL. 33859-8234 2 DEC. 0.050 TEL: (863) 676-1493 FAX: (863) 676-6844 3 DEC. 0.010 TITLE: 2.0"...
  • Page 81 010 BILL OF MATERIALS 020 ASSEMBLE AS SHOWN Item # Title Document # MACOLA PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST CYLINDER 2.0", TIP EXTENSION CASING WELDMENT 22 14 01 002 3 121127 LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 VALVE CART.
  • Page 82 HPKTH12570 2.0" CYLINDER PISTON 42 14 01 004 2 121160 1 1/2 ID X 2 OD X 3/8 PISTON HPKTH12570 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: 2.0" TIP EXTENSION CYLINDER...
  • Page 83 HOSE CUT 36" #6-S RECOIL BOX HS10576FS HS10576FS TUBE, TL3 HOSE RECOIL BOX - CURVED 41 04 04 043 0 TU04004 TOLERANCES PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST 1 DEC. 0.100 HOSE RECOIL, COVER ASSEMBLY 21 04 04 018 0 123127 LAKE WALES, FL.
  • Page 84 HOSE RECOIL, COVER ASSEMBLY 21 04 04 018 0 123127 CLAMP, PLASTIC ONLY (2-HOLE) (1 SET) CLP220 CLP220 TOLERANCES PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST 1 DEC. 0.100 CLAMP, TOP PLATE ONLY (2-HOLE) CL5G225 CL5G225 LAKE WALES, FL. 33859-8234 2 DEC.
  • Page 85 TRASH BUCKET JAW ASSEMBLY 22 11 01 002 5 102132 BOLT HEX 3/8-16 UNC X 3 G8 BL108048U816 BL108048U816 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 STD BUCKET A FRAME SHAFT 42 11 01 011 1 102173...
  • Page 86 STANDARD BUCKET A FRAME WELDMENT 22 11 01 009 0 102172 1/8" STRAIGHT GREASE FITTING HF2002S HF2002S PETERSEN INDUSTRIES INC. NUT SLOTTED 1-14 SAE GR5 NUB16S5 NUB16S5 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 HEX NUT 1/4-20 STOVERLOCK USS...
  • Page 87 102178 HEX BOLT 1-1/4-7 X 7-3/4 GR8 BL120124U87 BL120124U87 SLOTTED NUT 1-1/4 UNC GR5 NUB20U NUB20U PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST BUCKET SADDLE PIVOT PIN 41 11 09 005 0 PI30204F LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493...
  • Page 88 SLOTTED NUT 1-1/4 UNC GR5 NUB20U NUB20U HEX BOLT 5/16-18 X 2-1/4 USS G5 BL305036U518 BL305036U518 PETERSEN INDUSTRIES INC. GIMBAL WELDMENT 4 X 5-1/2 31 11 09 042 1 102119 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 BOLT - ROTATOR GIMBAL, TRASH...
  • Page 89 BEARING GREASE RETAINER FOR CONTINUOUS ROTATOR 41 11 09 013 2 WAL866902 CONTINUOUS ROTATOR THRUST WASHER 41 11 09 015 1 WAF885002 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE:...
  • Page 90 BUCKET, TL JAW RIB TUBE 42 11 01 019 1 102169 STD BUCKET JAWS RIB 41 11 09 021 2 102165 PETERSEN INDUSTRIES INC. BUCKET, TL JAW SKIN 3/16" 42 11 01 015 4 102166 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234...
  • Page 91 REVISED GIMBAL MOUNTING PIN 09/30/2016 010 ASSEMBLY REVISED BUCKET SADDLE WELDMENT 10/04/2016 46.62 63.35 54.60 TOLERANCES PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST 1 DEC. 0.100 LAKE WALES, FL. 33859-8234 2 DEC. 0.050 NOTE: DUAL CYLINDER BUCKET WEIGHS 1040 LBS TEL: (863) 676-1493 FAX: (863) 676-6844 3 DEC.
  • Page 92 NOTE: APPLY RED LOCKTITE AND TORQUE BOLTS 2, 9 AND 13 TO 150 FT LB PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: DUAL CYLINDER BUCKET ASSEMBLY PART NUMBER: SCALE:...
  • Page 93 BL310016U511 WASHER LOCK 1/2 SPLIT USS WAS085 WAS085 BOLT, HEX 1/2-13 X 3/4 USS G5 BL308012U513 BL308012U513 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: DUAL CYLINDER BUCKET ASSEMBLY PART NUMBER:...
  • Page 94 010 ASSEMBLY 122140 QTY 1 122141 QTY 1 TARP NOT SHOWN 122113 QTY 2 TOLERANCES PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST 1 DEC. 0.100 LAKE WALES, FL. 33859-8234 2 DEC. 0.050 TEL: (863) 676-1493 FAX: (863) 676-6844 3 DEC.
  • Page 95 1: 3 0 SCALE SHAFT END HOLE 79.625 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE: RA, LOAD COVER ASSEMBLY PART NUMBER: SCALE: 22 09 01 004 0 / 122105...
  • Page 96 LOAD COVER OVERWIND BRACKET PIPE 42 09 01 018 0 122130 MOUNTING EAR, PI SELF WINDING TARP ROLLER ASSEMBLY 42 09 01 005 1 122811 PETERSEN INDUSTRIES INC. 4000 S.R. 60 WEST LAKE WALES, FL. 33859-8234 TEL: (863) 676-1493 FAX: (863) 676-6844 TITLE:...

  • Page 99: Miscellaneous Parts

    * NOTE: Item numbers with an asterisk (*) may have part numbers and prices different than what is shown on this price list. Please consult with the Petersen Parts Department to help correctly identify these parts for your loader. You may reach our Parts Department at 800/930-5623, ext.
  • Page 100 FROM: ____________________________________ ____________________________________ ____________________________________ This is to advise you that our organization is no longer the owner of the Petersen loader listed below. We have listed the name and address of the subsequent owner. Would you please change your records accordingly.
  • Page 101 Service Manual HY09-SM020/US Service Manual ™ PGP020 Effective: July 1, 2006 Supersedes: All Others PGP020 Series...

  • Page 102: Worldwide Sales And Service

    The Gear Pump Division’s ability to engineer The Parker Hannifin specialty products for unique applications has Gear Pump Division kept us at the forefront of technology, and Assures: ensured our position as the industry leader. Our success has come from providing a Consistent quality quality product with excellent sales and service support.

  • Page 103: Table Of Contents

    PGP020 Service Manual Service Manual HY09-SM020/US ™ Contents PGP020 Series Index General Instructions ..........4 Cleanliness ............. 4 Cautions ..............4 Exploded View and Parts List ......... 5 PGP020™ Disassembly Instructions ...... 6 PGP020™ Assembly Instructions ......9 Part Replacement Guide ........12 Tool List ..............

  • Page 104: General Instructions

    PGP020 Service Manual Service Manual HY09-SM020/US ™ General Instructions/Cleanliness/Cautions PGP020 Series Pump Service Instructions General Instructions Cautions These service instructions will: 1) Parker replacement parts are made to original equipment standards. For assured quality of • familiarize you with the PGP020 series roller material and workmanship and for compatibility bearing pump, its component parts and their in assembly, USE ONLY GENUINE Parker...

  • Page 105: Exploded View And Parts List

    PGP020 Service Manual Service Manual HY09-SM020/US ™ Exploded View and Parts List PGP020 Series Exploded View and Parts List Item No. Description Required Ten Digit No. (TDN) Snap Ring 391-2686-063 Outboard Bearing 391-0381-040 Outboard Spacer 391-3383-069 Lip Seal (pump) 391-2883-058 Seal Retainer (motor) 391-3381-040 Lip Seal (motor)

  • Page 106: Pgp020™ Disassembly Instructions

    PGP020 Service Manual Service Manual HY09-SM020/US ™ PGP020™ Disassembly Instructions PGP020 Series PGP020™ Disassembly Instructions STEP 1 STEP 2 Place the pump in a Mark each casting in vise with the drive shaft the assembly with pointing down. Clamp machinist ink or a prick unit on the sides of the punch to orient the mounting flange.
  • Page 107 PGP020 Service Manual Service Manual HY09-SM020/US ™ PGP020™ Disassembly Instructions PGP020 Series PGP020™ Disassembly Instructions STEP 5.1 STEP 5.2 Remove the gear 5.2 Lift off the gear housing subassembly housing subassembly. using steps 5.1 - 5.3: 5.1 Place the two, large, flat-bladed screwdrivers into the separation notches...
  • Page 108 PGP020 Service Manual Service Manual HY09-SM020/US ™ PGP020™ Disassembly Instructions PGP020 Series PGP020™ Disassembly Instructions STEP 9 STEP 10 Gently lift off the thrust Remove lip seal. Place a plate. Be careful not to lip seal removal tool (see bend or score the plate Tool List P11) or a and mating surface of screwdriver tip against...

  • Page 109: Pgp020™ Assembly Instructions

    PGP020 Service Manual Service Manual HY09-SM020/US ™ PGP020™ Assembly Instructions PGP020 Series PGP020™ Assembly Instructions STEP 1 STEP 2 Stone all machined Coat the outside casting surfaces with a diameter of the lip seal medium-grit with Permatex Aviation carborundum stone. If Form-A-Gasket No.3 the bearings were Non-Hardening Sealant...
  • Page 110 PGP020 Service Manual Service Manual HY09-SM020/US ™ PGP020™ Assembly Instructions PGP020 Series PGP020™ Assembly Instructions STEP 7 STEP 8 Install the bearings in Grip the shaft end cover the shaft end cover and in a vise with the the port end cover. Use mounting face down.
  • Page 111 PGP020 Service Manual Service Manual HY09-SM020/US ™ PGP020™ Assembly Instructions PGP020 Series PGP020™ Assembly Instructions STEP 12 STEP 13 Apply a light coating of Locate the orientation grease to the new mark on the gear section seals and place housing and line it up them into the machined with the mark on the grooves on both sides...

  • Page 112: Part Replacement Guide

    PGP020 Service Manual Service Manual HY09-SM020/US ™ Part Replacement Guide PGP020 Series Part Replacement Guide If the gear set contains any of the following defects, it should be replaced: • Wear on the hubs or in the seal areas detectable by touch or in excess of .002”.

  • Page 113: Tool List

    PGP020 Service Manual Service Manual HY09-SM020/US ™ Tool List PGP020 Series Tool List Check Tool • Arbor press • Permanent marker or an awl • Bearing puller (Owatonna Tool Co. MD-956 or equivalent) • Clean, lint-free cloths • Deburring tool (a file with the cutting teeth ground off) •...

  • Page 114: Lubrication And Oil Recommendations

    PGP020 Service Manual Service Manual HY09-SM020/US ™ Lubrication/Oil Recommendations PGP020 Series Lubrication and Oil Recommendations All parts, with the exception of the outboard bearing, are lubricated by the hydraulic oil in the circuit. Particular attention must be paid to keep the oil in the system clean. Whenever there is a pump or motor failure and there is reason to suspect that metal particles may be in the system, the oil must be drained, the entire system flushed clean and any filter screens thoroughly cleaned or replaced.
  • Page 115 PGP020 Service Manual Service Manual HY09-SM020/US ™ Lubrication/Oil Recommendations PGP020 Series Lubrication and Oil Recommendations The Use of Other Oils: • Diesel Fuel or Kerosene (Coal Oil): These are sometimes used as dilutants for cold weather operations but are not recommended as they are not sufficiently refined products. •...

  • Page 116: Recommended Start-Up Procedure For New Or Rebuilt Pump Or Motor

    PGP020 Service Manual Service Manual HY09-SM020/US ™ Reccomended Start-up Procedure PGP020 Series Recommended Start-up Procedure for New or Rebuilt Pump or Motor Before installing a new or a rebuilt pump or motor, back out the main relief valve until the spring tension on the adjusting screw is relaxed.

  • Page 117: Test Procedure Recommended

    PGP020 Service Manual Service Manual HY09-SM020/US ™ Test Procedure Recommended PGP020 Series Test Procedure Recommended Be sure there is an adequate supply of oil for the have to be disassembled and be rebuilt, taking extra pump; at least one gallon of oil for each gpm of pump care to remove burrs and to assure freedom from capacity.

  • Page 118: Instructions For Change Of Rotation

    PGP020 Service Manual Service Manual HY09-SM020/US ™ Instructions for Change of Rotation PGP020 Series Instructions for Change of Rotation The PGP020 series pump can be assembled for clockwise (CW), counterclockwise (CCW), or bi-rotational operation. The direction of rotation is determined by looking at the pump with the drive shaft facing you and the idler gear down.
  • Page 119 Service Manual HY09-SM020/US PGP020 Service Manual Instructions for Change of Rotation ™ PGP020 Series ASSEMBLY 1) Before assembling the unit, stone off the machined surfaces. This will remove any nicks or burrs that may have resulted from the disassembly. 2) Air blast all parts and wipe them with a clean, lint-free cloth before starting the assembly.
  • Page 120 Notes Parker Hannifin Corporation Gear Pump Division Youngstown, Ohio USA...
  • Page 121 Notes Parker Hannifin Corporation Gear Pump Division Youngstown, Ohio USA...

  • Page 122: Offer Of Sale

    Offer of Sale The items described in this document are hereby offered for sale at prices to be established by Parker Hannifin Corporation, its subsidiaries and its authorized distributors. This offer and its acceptance by any customer (“Buyer”) shall be governed by all of the following Terms and Conditions. Buyer’s order for any item described in its document, when communicated to Parker Hannifin Corporation, its subsidiary or an authorized distributor (“Seller”) verbally or in writing, shall constitute acceptance of this offer.
  • Page 123 Parker Hannifin Corporation 6035 Parkland Blvd. Parker Hannifin Corporation Cleveland, Ohio 44124-4141 Telephone: (216) 896-3000 Fax: (216) 896-4000 Web site: www.parker.com About Parker Hannifin Corporation Parker’s Charter Parker Hannifin is a leading global motion-control To be a leading worldwide manufacturer of components company dedicated to delivering premier customer and systems for the builders and users of durable service.
  • Page 124 Parker Hannifin Corporation Service Manual HY09-SM020/US Gear Pump Division 2.5M, 07/06, T&M 1775 Logan Avenue Youngstown, OH 44501 USA Tel: (330) 746-8011 Fax: (330) 746-1148 http://www.parker.com/gearpump...
  • Page 169 LISTA RICAMBI N°2712-02 N°PAGINE 08 DATA DI COMPILAZIONE 04/02/2013 FIRMA : Grosso.G N° RICHIESTA:CI_0116 RE 1523 TS SP.8/16 Z26 60.5 MR GEARBOX DESCRIPTION 91V2HS300600 GEARBOX CODE Pagina 1...
  • Page 170 LISTA RICAMBI N°2712-02 N°PAGINE 08 DATA DI COMPILAZIONE 04/02/2013 FIRMA : Grosso.G N° RICHIESTA:CI_0116 SPARE PARTS LIST FOR OUTPUT SUPPORT RE1520 TS SPEC.DONA GRU-1520 TS DESCRIZIONE ITEM CODICE POS. Q.TA' ALBERO SCANALATO SPEC. 8/16 DP Z26 RE1520 SHAFT 02261309 ANELLO DI TENUTA 105x130x12 RING SEAL 415003300 COPERCHIETTO PORTATEN.RE1020/1520...
  • Page 171 LISTA RICAMBI N°2712-02 N°PAGINE 08 DATA DI COMPILAZIONE 04/02/2013 FIRMA : Grosso.G N° RICHIESTA:CI_0116 SPARE PARTS LIST FOR GEAR SET RE1520 M R=4.09 GRI-RE1520 M POS. DESCRIZIONE ITEM Q.TA' CODICE RAGG.INGRANAGGERIA RE1520 R1:4.09 GEAR SET 99130400 OR 2-277 O RING SEAL 406023400 CORONA RE1520/2000 RING GEAR...
  • Page 172 LISTA RICAMBI N°2712-02 N°PAGINE 08 DATA DI COMPILAZIONE 04/02/2013 FIRMA : Grosso.G N° RICHIESTA:CI_0116 SPARE PARTS LIST FOR INTERMEDIATE FLANGE RE1520 x SUPPORT "T" GR-FL RE1520 DESCRIZIONE ITEM CODICE POS. Q.TA' GUARNIZIONE OR 2-277 OR-RING SEAL 406023400 TAPPO TCEI DIN 908 R 3/8"GAS PLUG 419000700 RONDELLA 3/8"...
  • Page 173 LISTA RICAMBI N°2712-02 N°PAGINE 08 DATA DI COMPILAZIONE 04/02/2013 FIRMA : Grosso.G N° RICHIESTA:CI_0116 SPARE PARTS LIST FOR GEAR SET RE510 N R=4.25 GRI-RE510 N POS. DESCRIZIONE ITEM Q.TA' CODICE RAGG.INGRANAGGERIA RE 510 4,25 GEAR SET 99121600 GUARNIZIONE OR 2-171 O RING SEAL 406015000 CORONA RE500...
  • Page 174 LISTA RICAMBI N°2712-02 N°PAGINE 08 DATA DI COMPILAZIONE 04/02/2013 FIRMA : Grosso.G N° RICHIESTA:CI_0116 GR-FL RE510 SPARE PARTS LIST FOR INTERMEDIATE FLANGE RE510 x RE1520 POS. DESCRIZIONE ITEM Q.TA' CODICE GUARNIZIONE OR 2-171 OR-RING SEAL 406015000 TAPPO TCEI 1/4"GAS DIN 90 PLUG 419000600 RONDELLA RAME 1/4"...
  • Page 175 LISTA RICAMBI N°2712-02 N°PAGINE 08 DATA DI COMPILAZIONE 04/02/2013 FIRMA : Grosso.G N° RICHIESTA:CI_0116 SPARE PARTS LIST FOR GEAR SET RE 210 N 1"6B i=3.48 GRI-210 N DESCRIZIONE ITEM CODICE POS. Q.TA' RAGG.INGRANAGGERIA RE 210 N 3,48 GEAR SET 99103600 OR 147X2,62 N70-N003 O-RING SEAL 406018200...
  • Page 176 LISTA RICAMBI N°2712-02 N°PAGINE 08 DATA DI COMPILAZIONE 04/02/2013 FIRMA : Grosso.G N° RICHIESTA:CI_0116 SPARE PARTS LIST FOR MR INPUT GRE-MR 1"6B DESCRIZIONE CODICE POS. ITEM Q.TA' FLANGIA MR 110-240 2000080100 INPUT MOTOR FLANGE TAPPO TCEI 1/4"GAS DIN 908 PLUG 419000600 RONDELLA RAME 1/4"RICOTTO 13X19X1.5 WASHER...
