Petersen PeteStop 129 Series Instruction Manual

Inflatable line stop, pipe plugging system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TM
PeteStop
Inflatable Line Stop, Pipe Plugging System
129 Series
Instruction Manual
Petersen Pipe Plugs
www.PetersenProducts.com
421 Wheeler Avenue, PO Box 340, Fredonia, Wisconsin 53201-0340, USA
Phone: (262) 692-3100 or 1-800-926-1926
Fax: (262) 692-2418 or 1-800-669-1434
Email: sales@petersenproducts.com
®
Petersen
Warnings, Warranty, Terms and Conditions refer to http://www.petersenproducts.com.
