Sealey VS0276 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. INTRODUCTION
Simple-to-read- traffic light system to show moisture levels in the brake
fluid. Compatible with DOT 3, DOT 4 and DOT 5.1 brake fluid. Digital tyre
pressure gauge with light which can be displayed in bar, psi, kPa and
kg/cm². Pressure range 3-150 PSI (0.2-10.4 bar). Bright LED Display,
ideal for reading the screen in low light conditions. Powered by 2 x LR44
batteries (supplied)
2. OPERATION
2.1. BRAKE FLUID TESTING
2.1.1. Remove the cap from the brake fluid probe.
2.1.2. Press the BRAKE FLUID button. The green LED will light.
2.1.3. Place the probes of the tester in brake fluid. The LED will indicate the
condition of the fluid:
• Green 0% = Good.
• Yellow <2% = OK.
• Red >4% = Bad.
2.1.4. Clean the probes with clean water and dry.
2.2. TYRE PRESSURE TESTING
2.2.1. Press the TYRE PRESSURE button. Press to cycle between desired units
(Bar, PSI, kPA, kg/cm
2.2.2. Push the pressure gauge onto the tyre valve. Ensure a good seal to
prevent air from escaping.
2.2.3. The pressure will display on the LCD screen.
2.2.4. The tool will automatically power off after 40s. Alternatively hold the TYRE
PRESSURE button.
2.3. CHANGING THE BATTERY (FIG.2)
2.3.1. Remove the battery cover from the back of the tool (fig.2.1).
2.3.2. Remove the batteries and replace with an equivalent. Ensure the
batteries are inserted with the correct polarity (fig.2.2).
FIG.2
1
© Jack Sealey Limited
2-IN-1 BRAKE FLUID TESTER & TYRE
PRESSURE GAUGE
MODEL NO:
)
2
2
Original Language Version
VS0276
FIG.1
PRESSURE GAUGE
& LED LIGHT
TYRE PRESSURE
BUTTON
BRAKE FLUID
BUTTON
LED LIGHTS
(FOR BRAKE FLUID)
BRAKE FLUID
PROBE
VS0276 Issue 1 29/02/24
