- Page 1 INSTRUCTION MANUAL WINE COOLER CW 343ES AT PLEASE READ THIS MANUAL CAREFULLY BEFORE USING THIS PRODUCT PLEASE FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS...
-
Page 2: Table Of Contents
CONTENT Important Safety Instructions ………………………………..…………………………….1-2 Installation………………………………..…………………………………………………… 3 Product Overview …………………………………………..…………………………………4 Operation……………………………..…………………………………………….………. 5-6 General Maintenance………..……………………..…………………………………………7 Troubleshooting……………………………..…………………………………………………8 Technical Specification………………………………..……………………………….…….. 9 Warranty & Service ………………………………..………………………………………..10... -
Page 3: Important Safety Instructions
Dear Customer, Thank you for having purchased and given your preference for our product. This manual provides a means to make full use of the features of this appliance. We recommend that you read this manual for the best performance and to extend the life of your appliance. Please preserve this manual for future use, in the event that doubts arise relating to the operation. - Page 4 • Never clean appliance parts with flammable fluids. • Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or any other appliance. This can create a fire hazard or explosion. • Warning: Do not allow the refrigerant circuit to become damaged while using or installing the appliance.
-
Page 5: Installation
INSTALLATION OF YOUR WINE CABINET • Remove the exterior and interior packing. • Note: Before connecting the Wine Cabinet to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. -
Page 6: Product Overview
PRODUCT OVERVIEW 11. Upper hinge cover 12. Upper hinge 1. Housing 2. Control panel 9. Recessed handle 3. Shelf 10. Door seal 4.Evaporator 8. Door 5. Sensor shield 7. Lower hinge 6. Adjustable foot Note: Shelves, door frame, handle and other accessories could vary depending on models and configuration. The picture is for illustration only. -
Page 7: Operation
OPERATION The Wine Cabinet should be placed where the ambient temperature is between 0-35℃ (32-95 Fahrenheit). If the ambient temperature is above or below this range, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. - Page 8 Press and hold the key for 2 seconds to switch the temperature display between Fahrenheit and Celsius. Attention 1. The cooling temperature could be set from 5℃ - to 20℃. 2. If the unit is unplugged, power lost or turned off, you must wait for 3 to 5 minutes before restarting the unit.
-
Page 9: General Maintenance
GENERAL MAINTENANCE ➢ Cleaning Your Wine Cabinet • Turn off the power, unplug the appliance, and remove all items including shelves and rack. • Clean the interior with warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water. -
Page 10: Troubleshooting
TROUBLESHOOTING Try the suggestions below before calling the customer service center PROBLEM POSSIBLE CAUSE Not plugged in. Wine Cabinet does not operate. The appliance is turned off. The circuit breaker tripped or a blown fuse. Check the temperature control setting. The external environment may require a higher setting. -
Page 11: Technical Specification
TECHNICAL SPECIFICATION Product model CW 343ES AT Voltage/frequency 220-240V～/50Hz Refrigerant/amount R600a/23g Volume Loading capacity 34 bottles Net weight 25.4kg Unit dimension(WxDxH) 480×430×870 mm Packing dimension(WxDxH) 512×466×890mm Remarks： 1. Net weight includes the weight of shelves 2. Unit dimension is excluding the handle on the door. -
Page 12: Warranty And Service
WARRANTY AND SERVICE Please get ready the model number of your appliance, date of purchase, and the product issues when contacting our customer care center. For appliances under warranty, proof of purchase is required • To activate your warranty, please register your appliance. •...
