SPORT-TRANSFER sp. z o.o.
Jawornik 564
32-400 Myślenice
Tel. +48 12 649 14 83
e-mail: biuro@sport-transfer.com.pl
INSTRUCTIONS FOR ASSEMBLY AND USE OF SPORTS EQUIPMENT
Product: FIXING STRUCTURE /SINGLE/
Code: 10 050
The single basketball structure meets the requirements of EN 913:2019-3 and EN 1270:2006 "Pitch
equipment – Basketball equipment. Functional and Safety Requirements, Research Methods."
1. Product description
10 050 – TYPE 6
Design for outdoor facilities. Made of steel profiles, protected from the weather by hot-dip galvanisation.
Sleeve included to secure the structure in the ground /1 pc. Designed for a 105x180 cm backboard.
Extension arms L=1.60 m, L=1.40 m, L=1.20 m.
2. Purpose
The basketball structure is used for fixing a 105x180 basketball backboard in outdoor facilities.
3. Components
Number Name of part / component
1
Stand pole
2
Stand extension arm
3
Strut
4
Epoxy board 105x180 – NOT INCLUDED
5
Galvanised hoop with a chain net – NOT INCLUDED
6
Steel sleeve
1
Quantity per
product
1
1
2
1
1
1
Advertisement
Related Manuals for SPORT-TRANSFER 10 050
Summary of Contents for SPORT-TRANSFER 10 050
- Page 1 – Basketball equipment. Functional and Safety Requirements, Research Methods." 1. Product description 10 050 – TYPE 6 Design for outdoor facilities. Made of steel profiles, protected from the weather by hot-dip galvanisation. Sleeve included to secure the structure in the ground /1 pc. Designed for a 105x180 cm backboard.
- Page 2 Locking mechanism clamp screw M16x45 M16x25 screw Self-locking nut M10 M10x25 screw M10x35 mushroom head screw Height adjustment mechanism code 10 021 – optional Mechanism screw Mechanism guide Locking rod M16x125 screw Self-locking nut M16 4. Basketball set assembly a) Make a foundation in the ground and embed the sleeves (6). b) The top edge of the sleeve should coincide with the zero level of the pitch.
- Page 3 d) The stand in the sleeve can be installed and operated after the concrete has dried completely /min. 5-7 days/. e) Mount the backboards (4) and the chain net hoop on the extension arm (2) by sliding on the M10 pins at the front and fasten with M10 self-locking nuts (9).
- Page 5 h) Slide the pre-assembled backboard and extension arm onto the post, set them at the desired height and lock them onto the post using M16x25 screws (8). i) Adjust the position of the strut so that the backboard is vertical.
- Page 6 5. Height adjustment mechanism installation a) Fit the mechanism guides (13) with the locking rods (14) by sliding them into the bushings at the rear of the extension arm (2). b) Screw the mechanism screw (12) to the post (1) using M16x125 screws (15) and M16 nuts (16). c) Loosen the M16x25 screws locking the extension arm (8).
- Page 8 Note: installation may only be carried out by adults authorised to work at heights using a scaffold. 6. Use of the set a) The set is designed for playing basketball on outdoor courts. b) The fastenings of all individual components must be checked before use and then periodically (max. every 3 months).
- Page 9 c) To be wiped down with a cloth dampened with a mild cleaning agent by persons with the appropriate qualifications for working at heights. d) Depending on local requirements, the product may be intended for recycling or energy recovery after use. e) The product and its accessories must be properly disposed of at an appropriate local waste disposal/recycling facility.
