INSTRUCTIONS FOR ASSEMBLY AND USE OF SPORTS EQUIPMENT
Product: Beach football goal /5.49x2.21m/
Code: 15,901
The beach football goal meets the requirements of the PN-EN 748 standard: "Playing field equipment -
Football goals. Functional and safety requirements, test methods".
1. Components of the goal
Number Part/subassembly name
1
Goal crossbar
2
Goalpost /left, right/
3
Goal connector
4
Allen screw M8x16
5
Allen screw M8x20
6
Fixing block
7
PP hook
8
Mounting sleeve with cross-piece
9
Wooden beam
10
Goal arch /left, right/
1
Quantity per
product
1
2
2
8
8
8
50
2
4
2
Advertisement
Table of Contents
Related Manuals for SPORT-TRANSFER 15,901
Summary of Contents for SPORT-TRANSFER 15,901
- Page 1 SPORT-TRANSFER sp. z o.o. Jawornik 564 32-400 Myślenice Tel. +48 12 649 14 83 e-mail: biuro@sport-transfer.com.pl INSTRUCTIONS FOR ASSEMBLY AND USE OF SPORTS EQUIPMENT Product: Beach football goal /5.49x2.21m/ Code: 15,901 The beach football goal meets the requirements of the PN-EN 748 standard: “Playing field equipment - Football goals.
- Page 2 2. Sleeve assembly Insert the sleeves (8) into the ground in an axial distance of 5590 mm.
- Page 3 Upper edges of the sleeves must match the zero-level of the playground. 3. Goal assembly Connect the goal crossbar (1) to the goalposts (2) using the goal connector (3) and fix by means of M8x16 Allen screws (8).
- Page 4 Screw the gate arches (10) oby means of M8x20 Allen screws (5) and fixing blocks with thread (6). Insert the goal into the mounted sleeves.
- Page 6 4. Fastening the goal The net should be fastened to the goal crosspiece, goalposts, net with PP hooks at intervals of ~15 cm. Put the hook on the edge wire of the net, put it into the embossing in the frame of the goal and the crossbar and turn it by 90°.
