Model #
2402f
McKenzie
File Cabinet
GAC = Glazed Antique Cherry finish
JAV = Java finish
PEC = Pecan finish
Assembly Instructions
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
• For normal household use only. Not recommended for commercial use.
• Use a protective pad when you use the top of this piece as a writing
surface.
• Do not climb, sit or stand on this piece of furniture.
• Do not overload the drawers.
• Unload items before you move this unit.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code :
VN
WARNING
02/24
Advertisement
Related Manuals for Whittier Wood Furniture McKenzie 2402 Series
Summary of Contents for Whittier Wood Furniture McKenzie 2402 Series
- Page 1 If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you cannot order replacement parts through your dealer, please contact our customer service department.
-
Page 2: Parts List
2402f McKenzie File Cabinet Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and part name. Part Description Quantity Case Assembly Top Assembly (attached) Lower Drawer (inserted) Upper Drawer Face (installed) -
Page 3: Part Description
2402f McKenzie File Cabinet Parts List Part Description Quantity Anti-Tip Snapper (attached) Drawer Clip (attached) Slotted Leveler (installed) Leveler Adjustment Key (attached to Owners Manual) 2402f — Page 3 — 02/24... - Page 4 2402f McKenzie File Cabinet Assembly Instructions Tool Required: Phillips Screwdriver. Tool Provided: Leveler Adjustment Key in the Zip bag taped to the Owner’s Manual and Safety Guide. Use a protective pad when you use the top of this piece as a writing surface. The keys and the Aluminum File Rails are inside the hardware box.
- Page 5 2402f McKenzie File Cabinet Assembly Instructions This piece of furniture includes a drawer interlock system allowing only one drawer to be open at a time. This is a safety feature to reduce the risk of tip over. Do not defeat or remove the drawer interlock system.
- Page 6 2402f McKenzie File Cabinet Assembly Instructions When removing drawers from furniture featuring the Anti-Tip Drawer Interlock System it is important that the drawer is installed back in its original location. Numbers and letters are stamped on the back of the drawers. Stamping sequence starts at the bottom, moves to the top. Drawer back stamping example: Fig.
- Page 7 2402f McKenzie File Cabinet Assembly Instructions Example; if you want to remove the First Drawer and Second Drawer from the cabinet; remove the Second Drawer first. When you remove this drawer, the upper arm on the Anti-Tip Snapper for that side will be pulled forward. See Fig. 8d. As long as this arm is angled toward the front of the case, you cannot remove the First Drawer.
