Summary of Contents for Whirlpool AKZM 6560/IXL

  • Page 1 Priručnik za uporabu i održavanje Navodila za uporabo in vzdrževanje Manual del usuario y de mantenimiento Manual do utilizador e manutenção...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS These instructions shall also be available on website: www.whirlpool.eu YOUR SAFETY AND THAT OF OTHERS IS VERY IMPORTANT This manual and the appliance itself provide important safety warnings, to be read and observed at all times. This is the danger symbol, pertaining to safety, which alerts users to potential risks to themselves and others.
  • Page 4 - If the surface of the induction plate is cracked, do not use it and switch off the appliance to avoid the possibility of electric shock (only for models with induction function). - Do not touch the appliance with any wet part of the body and do not operate it when barefoot.
  • Page 5 - Do not use containers made of synthetic materials. - Overheated oils and fats catch fire easily. Always remain vigilant when cooking foods rich in fat and oil. - Never leave the appliance unattended during food drying. - If alcoholic beverages are used when cooking foods (e.g. rum, cognac, wine), remember that alcohol evaporates at high temperatures.

  • Page 6: General Recommendations

    GENERAL RECOMMENDATIONS Before use: Remove cardboard protection pieces, protective film and adhesive labels from accessories. Remove the accessories from the oven and heat it at 200° for about an hour to eliminate the smell and fumes from the insulating materials and protective grease. During use: Do not place heavy objects on the door as they could damage it.

  • Page 7: After Sales Service

    AFTER-SALES SERVICE Before calling the After-Sales Service: See if you can solve the problem yourself with the help of the suggestions given in the “Troubleshooting guide“. Switch the appliance off and back on again it to see if the fault persists. If after the above checks the fault still occurs, get in touch with the nearest After-sales Service.

  • Page 8: Maintenance

    • Remove all accessories before running the pyrolysis function (also the lateral grids). • For optimum cleaning of the oven door, remove the worst soiling with a damp sponge before using the pyrolytic function. The appliance is equipped with 2 pyrolysis functions: Energy-saving cycle (PYRO EXPRESS/ECO): which consumes approximately 25% less energy than the standard cycle.
  • Page 9 Fig. 6 Fig. 7 Fig. 8 Fig. 9 N.B.: Only use 25-40W/230V type E-14, T300°C incandescent lamps, or 20-40W/230 V type G9, T300°C halogen lamps. The lamp used in the appliance is specifically designed for electrical appliances and is not suitable for household room illumination (Commission Regulation (EC) No 244/2009).

  • Page 10: Instructions For Oven Use

    INSTRUCTIONS FOR OVEN USE FOR ELECTRICAL CONNECTION, SEE THE PARAGRAPH ON INSTALLATION Control panel Upper heating element/grill Cooling fan (not visible) Dataplate (not to be removed) Lamps Circular heating element (not visible) Turnspit (if present) Lower heating element (not visible) 10.

  • Page 11: Control Panel Description

    INSERTING WIRE SHELVES AND OTHER ACCESSORIES IN THE OVEN Insert the wire shelf horizontally, with the raised part “A” upwards (Fig. 1). The other accessories, like the drip tray and baking tray, are inserted with the raised part on the flat section “B”...

  • Page 12: Preheating The Oven

    USING THE APPLIANCE FOR THE FIRST TIME - LANGUAGE SELECTION AND SETTING THE TIME For correct use of the oven, when it is switched on for the first time you will have to select the desired language and set the correct time. Proceed as follows: Press : the display will show the list of the first three available languages.

  • Page 13: Fast Preheating

    FAST PREHEATING 180°C - 00:02 180°C - 00:02 180°C - 00:02 TEMPERATURE INSERT IN TEMPERATURE INSERT IN TEMPERATURE INSERT IN Fast Preheating Preheating Oven is Hot! If you wish to preheat the oven quickly before inserting food, change the oven’s default selection as follows: Select the fast preheating function using buttons Confirm by pressing...
  • Page 14 At any time during cooking, set values (temperature, grill setting, cooking time) can be changed using buttons and button as described in previous paragraphs. TIMER 00 : 00 : 00 01 : 10 : 00 01 : 09 : 00 (HH) (MM) (SS)
  • Page 15 SETTINGS To change some display settings, select “SETTINGS” from the main menu using buttons Confirm by pressing : the display shows which settings can be changed (language, volume of acoustic signal, display brightness, time, energy saving function). Select the setting you wish to change using buttons Press button to confirm.

  • Page 16: Function Description Table

    FUNCTION DESCRIPTION TABLE MAIN MENU Setting the display (language, time, brightness, volume of acoustic signal, SETTINGS energy saving function). Selecting 30 different pre-set recipes (see enclosed recipe booklet). The oven automatically sets the optimum cooking temperature, function RECIPES and time. It is important to follow the instructions given in the recipe book regarding preparation, accessories and which oven shelf to use.
  • Page 17 SPECIAL To speed up defrosting of food. Place food on the middle shelf. Leave food DEFROST in its packaging in order to prevent it from drying out on the outside. For keeping just-cooked food hot and crisp (e.g: meat, fried food or flans). KEEP WARM Place food on the middle shelf.

  • Page 18: Cooking Tables

    COOKING TABLES Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) 160-180 30-90 Cake tin on rack Leavened cakes Level 4: cake tin on rack 160-180 30-90 Level 1: cake tin on rack Drip-tray / baking tray or 160-200 35-90 Filled pies...
  • Page 19 Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) 180-190 40-55 Cake tin on rack Level 4: cake tin on rack 180-190 45-70 Savoury pies Level 1: cake tin on rack (vegetable pie, Level 5: cake tin on rack quiche lorraine) Level 3: cake tin on rack 1-3-5...
  • Page 20 Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) Drip-tray or baking tray (turn food two thirds of the way Baked potatoes Medium 45-55 through cooking if necessary) Vegetables au gratin High 10-25 Drip-tray or pan on rack Level 4: pan on rack Lasagna &...
  • Page 21 TESTED RECIPES in compliance with IEC 60350-1:2011-12 and DIN 3360-12:07:07 Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) IEC 60350-1:2011-12 § 7.5.2 15-30 Drip-tray / baking tray Shortbread Level 4: baking tray 25-40 Level 1: drip tray/baking tray IEC 60350-1:2011-12 §...

  • Page 22: Recommended Use And Tips

    RECOMMENDED USE AND TIPS How to read the cooking table The table indicates the best function to use for any given food, to be cooked on one or more shelves at the same time. Cooking times start from the moment food is placed in the oven, excluding pre-heating (where required).
  • Page 24 Printed in Italy 03/2012 5019 300 03110...
